CryptoMiniSat SAT solver

This system provides CryptoMiniSat, an advanced incremental SAT solver. The system has 3 interfaces: command-line, C++ library and python. The command-line interface takes a cnf as an input in the DIMACS format with the extension of XOR clauses. The C++ and python interface mimics this and also allows for incremental use: assumptions and multiple solve calls. A C and a Rust compatible wrapper is also provided.

When citing, always reference our SAT 2009 conference paper, bibtex record is here.

Compiling

Use of the release binaries is strongly encouraged. The second best thing to use is Nix. Simply install nix and then:

nix shell github:msoos/cryptominisat

Then you will have cryptominisat binary available and ready to use.

You can also run CryptoMiniSat from your web browser, without installing anything, here.

Building from source

Install system dependencies first:

# Debian/Ubuntu
sudo apt-get install build-essential cmake git libgmp-dev

# macOS (brew)
brew install cmake gmp

Then build — cadical and cadiback are fetched and built automatically:

git clone https://github.com/msoos/cryptominisat
cd cryptominisat
mkdir build && cd build
cmake ..
make -j8

If you already have cadical and cadiback built somewhere, point cmake at them to skip the auto-fetch:

cmake .. -Dcadical_DIR=/path/to/cadical/build -Dcadiback_DIR=/path/to/cadiback
make -j8

Building on Windows (MSYS2/MINGW64)

Install MSYS2, then from the MINGW64 shell install dependencies:

pacman -S mingw-w64-x86_64-gcc mingw-w64-x86_64-cmake mingw-w64-x86_64-ninja \
          mingw-w64-x86_64-make mingw-w64-x86_64-gmp mingw-w64-x86_64-zlib make

Then build:

git clone --recurse-submodules https://github.com/msoos/cryptominisat
cd cryptominisat
mkdir build && cd build
cmake -G Ninja -DCMAKE_BUILD_TYPE=Release ..
cmake --build . -v

For a fully static binary (no external DLL dependencies at runtime), add -DBUILD_SHARED_LIBS=OFF:

cmake -G Ninja -DCMAKE_BUILD_TYPE=Release -DBUILD_SHARED_LIBS=OFF ..
cmake --build . -v

Command-line usage

Let's take the file:

p cnf 3 3
1 0
-2 0
-1 2 3 0

The file has 3 variables and 3 clauses, this is reflected in the header p cnf 3 3 which gives the number of variables as the first number and the number of clauses as the second. Every clause is ended by '0'. The clauses say: 1 must be True, 2 must be False, and either 1 has to be False, 2 has to be True or 3 has to be True. The only solution to this problem is:

cryptominisat5 --verb 0 file.cnf
s SATISFIABLE
v 1 -2 3 0

Which means, that setting variable 1 True, variable 2 False and variable 3 True satisfies the set of constraints (clauses) in the CNF. If the file had contained:

p cnf 3 4
1 0
-2 0
-3 0
-1 2 3 0

Then there is no solution and the solver returns s UNSATISFIABLE.

Incremental Python Usage

The python module works with Python 3. Just execute:

pip3 install pycryptosat

You can then use it in incremental mode as:

>>> from pycryptosat import Solver
>>> s = Solver()
>>> s.add_clause([1])
>>> s.add_clause([-2])
>>> s.add_clause([-1, 2, 3])
>>> sat, solution = s.solve()
>>> print(sat)
True
>>> print(solution)
(None, True, False, True)
>>> sat, solution = s.solve([-3])  # assume var 3 = False → UNSAT
>>> print(sat)
False
>>> sat, solution = s.solve()      # without assumption → still SAT
>>> print(sat)
True
>>> s.add_clause([-3])             # permanently add -3
>>> sat, solution = s.solve()
>>> print(sat)
False

If you want to build the Python package from source, the build uses scikit-build-core which drives CMake — cadical and cadiback are fetched and compiled automatically, so no manual C++ dependency installation is needed beyond GMP.

# Debian/Ubuntu
sudo apt-get install build-essential cmake libgmp-dev python3-dev

# macOS
brew install cmake gmp

git clone https://github.com/msoos/cryptominisat
cd cryptominisat
python3 -m venv venv
source venv/bin/activate
pip install scikit-build-core cmake ninja build
pip install . --no-build-isolation

Or to produce a wheel file without installing:

python -m build --wheel --no-isolation   # wheel lands in dist/
pip install dist/pycryptosat-*.whl

Incremental Library Usage

The library uses a variable numbering scheme that starts from 0. Since 0 cannot be negated, the class Lit is used as: Lit(variable_number, is_negated). As such, the 1st CNF above would become:

#include <cryptominisat5/cryptominisat.h>
#include <assert.h>
#include <vector>
using std::vector;
using namespace CMSat;

int main()
{
    SATSolver solver;
    vector<Lit> clause;

    //Let's use 4 threads
    solver.set_num_threads(4);

    //We need 3 variables. They will be: 0,1,2
    //Variable numbers are always trivially increasing
    solver.new_vars(3);

    //add "1 0"
    clause.push_back(Lit(0, false));
    solver.add_clause(clause);

    //add "-2 0"
    clause.clear();
    clause.push_back(Lit(1, true));
    solver.add_clause(clause);

    //add "-1 2 3 0"
    clause.clear();
    clause.push_back(Lit(0, true));
    clause.push_back(Lit(1, false));
    clause.push_back(Lit(2, false));
    solver.add_clause(clause);

    lbool ret = solver.solve();
    assert(ret == l_True);
    std::cout
    << "Solution is: "
    << solver.get_model()[0]
    << ", " << solver.get_model()[1]
    << ", " << solver.get_model()[2]
    << std::endl;

    //assumes 3 = FALSE, no solutions left
    vector<Lit> assumptions;
    assumptions.push_back(Lit(2, true));
    ret = solver.solve(&assumptions);
    assert(ret == l_False);

    //without assumptions we still have a solution
    ret = solver.solve();
    assert(ret == l_True);

    //add "-3 0"
    //No solutions left, UNSATISFIABLE returned
    clause.clear();
    clause.push_back(Lit(2, true));
    solver.add_clause(clause);
    ret = solver.solve();
    assert(ret == l_False);

    return 0;
}

The library usage also allows for assumptions. We can add these lines just before the return 0; above:

vector<Lit> assumptions;
assumptions.push_back(Lit(2, true));
lbool ret = solver.solve(&assumptions);
assert(ret == l_False);

ret = solver.solve();   // no assumption → solution exists again
assert(ret == l_True);

Since we assume that variable 2 must be false, there is no solution. However, if we solve again, without the assumption, we get back the original solution. Assumptions allow us to assume certain literal values for a specific run but not all runs -- for all runs, we can simply add these assumptions as 1-long clauses.

Multiple solutions

To find multiple solutions to your problem, just run the solver in a loop and ban the previous solution found:

while(true) {
    lbool ret = solver->solve();
    if (ret != l_True) {
        assert(ret == l_False);
        //All solutions found.
        exit(0);
    }

    //Use solution here. print it, for example.

    //Banning found solution
    vector<Lit> ban_solution;
    for (uint32_t var = 0; var < solver->nVars(); var++) {
        if (solver->get_model()[var] != l_Undef) {
            ban_solution.push_back(
                Lit(var, (solver->get_model()[var] == l_True)? true : false));
        }
    }
    solver->add_clause(ban_solution);
}

The above loop will run as long as there are solutions. It is highly suggested to only add into the new clause (ban_solution above) the variables that are "important" or "main" to your problem. Variables that were only used to translate the original problem into CNF should not be added. This way, you will not get spurious solutions that don't differ in the main, important variables.

Rust bindings

To build the Rust bindings:

git clone https://github.com/msoos/cryptominisat-rs/
cd cryptominisat-rs
cargo build --release
cargo test

You can use it as per the README in that repository. To include CryptoMiniSat in your Rust project, add the dependency to your Cargo.toml file:

cryptominisat = { git = "https://github.com/msoos/cryptominisat-rs", branch= "master" }

You can see an example project using CryptoMiniSat in Rust here.

Preprocessing

If you wish to use CryptoMiniSat as a preprocessor, we encourage you to try out our model counting preprocessor, Arjun.

Gauss-Jordan elimination

Since CryptoMiniSat 5.8, Gauss-Jordan elimination is compiled into the solver by default. However, it will turn off automatically in case the solver observes GJ not to perform too well. To use Gaussian elimination, provide a CNF with xors in it (either in CNF or XOR+CNF form) and either run with default setup, or, tune it to your heart's desire:

Gauss options:
  --iterreduce arg (=1)       Reduce iteratively the matrix that is updated.We
                              effectively are moving the start to the last
                              column updated
  --maxmatrixrows arg (=3000) Set maximum no. of rows for gaussian matrix. Too
                              large matrixes should be discarded for reasons of
                              efficiency
  --autodisablegaus
