robustSingleCell

This package is not maintained at the moment -- please contact if you're interested in collaborating and improving this project.

Overview

robustSingleCell is a pipeline designed to identify robust cell subpopulations using scRNAseq data and compare population compositions across tissues and experimental models via similarity analysis as described in Magen et al. (2019) bioRxiv [1].

Installation

Install the following dependencies before installing the package:

if(!require(devtools))
  install.packages("devtools")
if (!requireNamespace("BiocManager", quietly = TRUE))
  install.packages("BiocManager")

BiocManager::install("limma")
BiocManager::install("grimbough/biomaRt")

You can then install the stable version from CRAN:

install.packages("robustSingleCell")

To access the latest features or bug fixes, you can install the development version from GitHub.

devtools::install_github("asmagen/robustsinglecell")

This pipeline currently supports slurm for parallel batch jobs.

Getting help

If you identify a bug, please submit an issue with a reproducible example.

Tutorial

We used two replicates of CD44⁺ T cell data sets from Ciucci et al. 2019 [2] as an example to demonstrate the use of robustSingleCell. The analysis requires at least 8G of memory on slurm [3] high performance computing workload manager (for example, you can start by requesting srun --pty -p <partition> --mem=8G -t 1:00:00 bash to start an interactive session).

We first download the raw 10X data from GEO using GEOquery, which can be obtained using the following command if not already installed:

source("https://bioconductor.org/biocLite.R")
biocLite("GEOquery")

The two datasets LCMV1, LCMV2 will be downloaded into TMPDIR. Each folder will contain the matrix.mtx, gene.tsv and barcode.tsv files as in 10X genomics format.

library(robustSingleCell)
download_LCMV()

Note: when using your own data, the 10X genomics files (matrix.mtx, gene.tsv and barcode.tsv) will be typically located at ⁨outs⁩/⁨filtered_gene_bc_matrices⁩/⁨mm10⁩, depending on the genome used for alignment. Copy the contents of this directory to the working directory data.path specified in initialize.project below.

We cluster each dataset separately to account for dataset-specific technical and biological differences. Then, we measure the transcriptional similarity and divergence between the clusters identified in the two datasets using correlation analysis.

Individual analysis of LCMV1 and LCMV2

First, we set up the directory where the results of the analysis will be stored.

LCMV1 <- initialize.project(datasets = "LCMV1",
                          origins = "CD44+ cells",
                          experiments = "Rep1",
                          data.path = file.path(tempdir(), "LCMV"),
                          work.path = file.path(tempdir(), "LCMV/LCMV_analysis"))

read.data function reads the data in 10X genomics format and performs quality filtering as described in Magen et al 2019. We randomly downsampled the datasets to 500 cells for this tuutorial.

LCMV1 <- read.data(LCMV1, subsample = 500)

Next, we identify highly variable genes for the following PCA and clustering analyses. We also compute the activation of gene sets of interest, such as cell cycle genes, for confounder correction.

LCMV1 <- get.variable.genes(LCMV1)
exhaustion_markers <- c('Pdcd1', 'Cd244', 'Havcr2', 'Ctla4', 'Cd160', 'Lag3', 'Tigit', 'Cd96')
LCMV1 <- add.confounder.variables(LCMV1,
    ribosomal.score = ribosomal.score(LCMV1),
    mitochondrial.score = mitochondrial.score(LCMV1),
    cell.cycle.score = cell.cycle.score(LCMV1),
    Exhaustion = controlled.mean.score(LCMV1, exhaustion_markers))

Figure 1 shows the mitochondrial score versus number of UMIs, pre and post filtering.

<figure> <img src="vignettes/figs/pre_stats.png" width = "700"> <img src="vignettes/figs/post_stats.png" width = "700"> <figcaption>

Fig 1. Mitochondrial genes score vs. number of UMIs for pre (top) and post (bottom) quality control filtering.

</figcaption> </figure>

The PCA function performs multiple simulation analyses of shuffled data to determine the appropriate number of PCs. You can also run each simulation in parallel using the option local = F.

LCMV1 <- PCA(LCMV1, local = T)

We then perform clustering analysis for a range of clustering resolutions. The analysis is repeated multiple times over shuffled data to estimate the appropriate clustering resolution and control for false discovery of clusters. At the end of the clustering, the function will prompt you to choose an optimal clustering resolution. We choose 0.05 for our KNN ratio, which is the smallest value tested with mdlrty/mean.shfl > 2.

LCMV1 <- cluster.analysis(LCMV1, local = T)

<figure> <img src="vignettes/figs/Clustering.modularity.png" width = "700"> <figcaption>

Fig 2. Bar plot shows the clustering modularity of the original data versus shuffled data across multiple clustering resolutions. Numbers on top represent the fold change of original versus shuffled analysis for each resolution.

</figcaption> </figure>

We select the appropriate resolution, typically the one where there is more than two (2) fold change modularity difference relative to the shuffled analysis.

The summarize function which performs differential expression analysis, computes tSNE and visualizes the results in the analysis folder. After differential expression analysis, get.cluster.names assigns clusters with names using a customized set of marker genes which users should adapt to their own data.

types = rbind(
                data.frame(type='Tfh',gene=c('Tcf7','Cxcr5','Bcl6')),
                data.frame(type='Th1',gene=c('Cxcr6','Ifng','Tbx21')),
                data.frame(type='Tcmp',gene=c('Ccr7','Bcl2','Tcf7')),
                data.frame(type='Treg',gene=c('Foxp3','Il2ra')),
                data.frame(type='Tmem',gene=c('Il7r','Ccr7')),
                data.frame(type='CD8',gene=c('Cd8a')),
                data.frame(type='CD4', gene = c("Cd4")),
                data.frame(type='Cycle',gene=c('Mki67','Top2a','Birc5'))
)
summarize(LCMV1, local = T)
LCMV1_cluster_names <- get.cluster.names(LCMV1, types, min.fold = 1.0, max.Qval = 0.01)
LCMV1 <- set.cluster.names(LCMV1, names = LCMV1_cluster_names)
summarize(LCMV1, local = T)

Figure 3 shows violin plots indicating the activation of the cell cycle genes.

<figure> <img src="vignettes/figs/violin.png" width = "700"> <figcaption>

Fig 3. Violin plot pf cell cycle score.

</figcaption> </figure>

Figure 4 places individual cells on a two dimensional grid corresponding to the scores of the first two PCs (note that the PCA figures are created in the next step via summarize function below).

<figure> <img src="vignettes/figs/PCA.png" width = "700"> <figcaption>

Fig 4. Single cells placement on a 2D grid corresponding to the first two PCs.

</figcaption> </figure>

The genes driving the PCs are visualized in figure 5 according to the PCA loadings after removing the lowly ranked genes.

<figure> <img src="vignettes/figs/rotation.png" width = "700"> <figcaption>

Fig 5. Top ranked genes contribution to PC1 and PC2 scores.

</figcaption> </figure>

The average expression of genes driving the PCs can be visualized as a heatmap visualized in figure 6 according to the PCA loadings after removing the lowly ranked genes.

<figure> <img src="vignettes/figs/PC1_heatmap.png" width="700"> <figcaption>

Fig 6. Heatmap shows loadings of the first PC.

</figcaption> </figure>

Figure 7 shows the tSNE visualization of the cells, color coded by cluster assignment.

<figure> <img src="vignettes/figs/tsne.png" width="700"> <figcaption>

Fig 7. t-SNE plot colored by cluster assignment.

</figcaption> </figure>

We can also visualize the average expression of selected T cells marker genes for initial evaluation (Figure 8).

canonical_genes <- c("Cd8a", "Cd4", "Mki67", "Foxp3", "Il2ra", "Bcl6",
                     "Cxcr5", "Cxcr6", "Ifng", "Tbx21", "Id2", "Rora",
                     "Cxcr3", "Tcf7", "Ccr7", "Cxcr4", "Pdcd1", "Ctla4")
plot_simple_heatmap(LCMV1, name = "canonical", markers = canonical_genes, main = "Expression of marker genes")

<figure> <img src="vignettes/figs/diff.genes.png" width="700"> <figcaption>

Fig 8. Heatmap shows row-normalized average expression of selected marker genes per cluster.

</figcaption> </figure>

We repeat the same procedure for LCMV2 dataset.

LCMV2 <- initialize.project(datasets = "LCMV2",
                          origins = "CD44+ cells",
                          experiments = "Rep2",
                          data.path = file.path(tempdir(), "LCMV"),
                          work.path = file.path(tempdir(), "LCMV/LCMV_analysis"))
LCMV2 <- read.data(LCMV2, subsample = 500)
LCMV2 <- get.variable.genes(LCMV2)
LCMV2 <- add.confounder.variables(
  LCMV2,
  ribosomal.score = ribosomal.score(LCMV2),
  mitochondrial.score = mitochondrial.score(LCMV2),
  cell.cycle.score = cell.cycle.score(LCMV2),
  Exhaustion = controlled.mean.score(LCMV2, exhaustion_markers))

LCMV2 <- PCA(LCMV2, local = T)
LCMV2 <- cluster.analysis(LCMV2, local = T)
summarize(LCMV2, local = T)
LCMV2_cluster_names <- get.cluster.names(LCMV2, types, min.fold = 1.0, max.Qval = 0.01)
LCMV2 <
