PointPillars: Fast Encoders for Object Detection from Point Clouds

A Simple PointPillars PyTorch Implenmentation for 3D Lidar(KITTI) Detection. [Zhihu]

It can be run without installing Spconv, mmdet or mmdet3d.
Only one detection network (PointPillars) was implemented in this repo, so the code may be more easy to read.
Sincere thanks for the great open-source architectures mmcv, mmdet and mmdet3d, which helps me to learn 3D detetion and implement this repo.

News

2025-02 Making PointPillars a python package out of the code is supported.
2024-04 Exporting PointPillars to ONNX & TensorRT is supported on branch feature/deployment.

mAP on KITTI validation set (Easy, Moderate, Hard)

| Repo | Metric | Overall | Pedestrian | Cyclist | Car | | :---: | :---: | :---: | :---: | :---: | :---: | | this repo | 3D-BBox | 73.3259 62.7834 59.6278 | 51.4642 47.9446 43.8040 | 81.8677 63.6617 60.9126 | 86.6456 76.7439 74.1668 | | mmdet3d v0.18.1 | 3D-BBox | 72.0537, 60.1114, 55.8320 | 52.0263, 46.4037, 42.4841 | 78.7231, 59.9526, 57.2489 | 85.4118, 73.9780, 67.7630 | | this repo | BEV | 77.8540 69.8003 66.6699 | 59.1687 54.3456 50.5023 | 84.4268 67.1409 63.7409 | 89.9664 87.9145 85.7664 | | mmdet3d v0.18.1 | BEV | 76.6485, 67.7609, 64.5605 | 59.0778, 53.3638, 48.4230 | 80.9328, 63.3447, 60.0618 | 89.9348, 86.5743, 85.1967 | | this repo | 2D-BBox | 80.5097 74.6120 71.4758 | 64.6249 61.4201 57.5965 | 86.2569 73.0828 70.1726 | 90.6471 89.3330 86.6583 | | mmdet3d v0.18.1 | 2D-BBox | 78.4938, 73.4781, 70.3613 | 62.2413, 58.9157, 55.3660 | 82.6460, 72.3547, 68.4669 | 90.5939, 89.1638, 87.2511 | | this repo | AOS | 74.9647 68.1712 65.2817 | 49.3777 46.7284 43.8352 | 85.0412 69.1024 66.2801 | 90.4752 88.6828 85.7298 | | mmdet3d v0.18.1 | AOS | 72.41, 66.23, 63.55 | 46.00, 43.22, 40.94 | 80.85, 67.20, 63.63 | 90.37, 88.27, 86.07 |

Note: Here, we report mmdet3d v0.18.1 (2022/02/09-2022/03/01) performance based on the officially provided checkpoint. Much improvements were made in the mmdet3d v1.0.0rc1.

Detection Visualization

[Install]

Install PointPillars as a python package and all its dependencies as follows:

cd PointPillars/
pip install -r requirements.txt
python setup.py build_ext --inplace
pip install .

[Datasets]

Download

Download point cloud(29GB), images(12 GB), calibration files(16 MB)和labels(5 MB)。Format the datasets as follows:

kitti
    |- training
        |- calib (#7481 .txt)
        |- image_2 (#7481 .png)
        |- label_2 (#7481 .txt)
        |- velodyne (#7481 .bin)
    |- testing
        |- calib (#7518 .txt)
        |- image_2 (#7518 .png)
        |- velodyne (#7518 .bin)

Pre-process KITTI datasets First

cd PointPillars/
python pre_process_kitti.py --data_root your_path_to_kitti

Now, we have datasets as follows:

kitti
    |- training
        |- calib (#7481 .txt)
        |- image_2 (#7481 .png)
        |- label_2 (#7481 .txt)
        |- velodyne (#7481 .bin)
        |- velodyne_reduced (#7481 .bin)
    |- testing
        |- calib (#7518 .txt)
        |- image_2 (#7518 .png)
        |- velodyne (#7518 .bin)
        |- velodyne_reduced (#7518 .bin)
    |- kitti_gt_database (# 19700 .bin)
    |- kitti_infos_train.pkl
    |- kitti_infos_val.pkl
    |- kitti_infos_trainval.pkl
    |- kitti_infos_test.pkl
    |- kitti_dbinfos_train.pkl

[Training]

cd PointPillars/
python train.py --data_root your_path_to_kitti

[Evaluation]

cd PointPillars/
python evaluate.py --ckpt pretrained/epoch_160.pth --data_root your_path_to_kitti

[Test]

cd PointPillars/

# 1. infer and visualize point cloud detection
python test.py --ckpt pretrained/epoch_160.pth --pc_path your_pc_path

# 2. infer and visualize point cloud detection and gound truth.
python test.py --ckpt pretrained/epoch_160.pth --pc_path your_pc_path --calib_path your_calib_path  --gt_path your_gt_path

# 3. infer and visualize point cloud & image detection
python test.py --ckpt pretrained/epoch_160.pth --pc_path your_pc_path --calib_path your_calib_path --img_path your_img_path


e.g.
a. [infer on val set 000134]

python test.py --ckpt pretrained/epoch_160.pth --pc_path pointpillars/dataset/demo_data/val/000134.bin

or

python test.py --ckpt pretrained/epoch_160.pth --pc_path pointpillars/dataset/demo_data/val/000134.bin \
               --calib_path pointpillars/dataset/demo_data/val/000134.txt \
               --img_path pointpillars/dataset/demo_data/val/000134.png \
               --gt_path pointpillars/dataset/demo_data/val/000134_gt.txt

b. [infer on test set 000002]

python test.py --ckpt pretrained/epoch_160.pth --pc_path pointpillars/dataset/demo_data/test/000002.bin

or

python test.py --ckpt pretrained/epoch_160.pth --pc_path pointpillars/dataset/demo_data/test/000002.bin \
               --calib_path pointpillars/dataset/demo_data/test/000002.txt \
               --img_path pointpillars/dataset/demo_data/test/000002.png

Acknowledements

Thanks for the open source code mmcv, mmdet and mmdet3d.
