ILLC3

ILLC3 is a Visual Studio code extention that adds native support to Visual Studio Code for lc3 assembly. LC3 is a popular educational assembly language used to teach the fundamentals of computer engineering at various universities such as UIUC, UW Madison, UT Austin, UPenn and many more.

Installation

Final Product Installation (via Marketplace)

• Simply look for ILLC3 and hit install and you're good to go!

Repo install with Source Code

• Clone this repo and unzip the .zip file.
• Open VSCode and navigate File → Open → Choose the extension folder
• Press F5 to use the extension in a simulated environment.
• You're ready to go now!!!
• We expect to have the extension available on the VS Code Extensions marketplace very soon!

Features

• Syntax highlighting for LC3 including differentiation between operands, registers, comments, pseudo-ops, and data types

• Auto complete support in the form of RTL statements for operands and pseudo-ops

• Shortcuts implemented for various operands:

  1. shift + enter + a --> inserts ADD
  2. shift + enter + d --> inserts AND
  3. shift + enter + b --> inserts BR
  4. shift + enter + q --> inserts JMP
  5. shift + enter + j --> inserts JSR
  6. shift + enter + y --> inserts JSRR
  7. shift + enter + right --> inserts LD
  8. shift + enter + i --> inserts LDI
  9. shift + enter + r --> inserts LDR
  10. shift + enter + e --> inserts LEA
  11. shift + enter + n --> inserts NOT
  12. shift + enter + left --> inserts ST
  13. shift + enter + t --> inserts STI
  14. shift + enter + = --> inserts STR

Tip: The auto complete code pastes a template for registers that can be edited in succession using the Tab button <br> Note: When entering shortcuts press shift + enter together, then press the necessary key

Requirements

• Debugging requires LC3 tools to be installed in your unix terminal (supported only with linux/mac or a linux subsystem for windows): https://github.com/haplesshero13/lc3tools

Future Additions

• Native support for debugging LC3 is in the works! If you think you can help us out, feel free to submit a PR!

Release Notes

NOW LIVE IN THE VS CODE MARKETPLACE!!!

1.0.6

Initial release of ILLC3

---

Made with <3 @ HackIllinois 2019
