StackedVlnPlot

Demo data

The PMBC scRNA-seq demo data (*.rds) files are available in the data folder of this repository.

With VlnPlot and a Seurat object

Stacked violin plot functionality using the VlnPlot function is added to Seurat in version 3.2.1.

library(Seurat)
library(ggplot2)
library(cowplot)

# Load Seurat obj
pbmc <- readRDS("data/pbmc_2k_v3_Seurat.rds")

features <- c("CD79A", "MS4A1", "CD8A", "CD8B", "LYZ", "LGALS3", "S100A8", "GNLY",
              "NKG7", "KLRB1", "FCGR3A", "FCER1A", "CST3")

a <- VlnPlot(pbmc, features, stack = TRUE, sort = TRUE) +
        theme(legend.position = "none") + ggtitle("Identity on y-axis")

b <- VlnPlot(pbmc, features, stack = TRUE, sort = TRUE, flip = TRUE) +
        theme(legend.position = "none") + ggtitle("Identity on x-axis")

# Use plot_grid to join plots
plot_grid(a, b)

<img src="images/StackedVlnPlot_Seurat.png" width="80%" />

With ggplot2 and a data.frame object

Given a data.frame object and a vector of identity classes (cluster ID), a stacked violin plot can be created with the ggplot2 package.

Prepare data.frame

# Load data.frame obj
pbmc <- readRDS("data/pbmc_2k_v3_df.rds")
identity <- readRDS("data/pbmc_2k_v3_Seurat_Idents.rds")

features <- c("CD79A", "MS4A1", "CD8A", "CD8B", "LYZ", "LGALS3", "S100A8", "GNLY",
              "NKG7", "KLRB1", "FCGR3A", "FCER1A", "CST3")

# Subset data.frame
pbmc <- pbmc[,features]

# Add cell ID and identity classes
pbmc$Cell <- rownames(pbmc)
pbmc$Idents <- identity

# Use melt to change data.frame format
pbmc <- reshape2::melt(pbmc, id.vars = c("Cell","Idents"), measure.vars = features,
                       variable.name = "Feat", value.name = "Expr")
head(pbmc, 10)

##                  Cell Idents  Feat     Expr
## 1  AACAACCTCACCTCTG-1      0 CD79A 0.000000
## 2  AGGAGGTTCGCGGACT-1      0 CD79A 1.743733
## 3  AGGCATTCAAGACGGT-1      1 CD79A 0.000000
## 4  GCAACCGCAGTTTCGA-1      1 CD79A 0.000000
## 5  TTTCACATCGTCCTCA-1      1 CD79A 0.000000
## 6  CTGCCTAAGCGTTCAT-1      1 CD79A 0.000000
## 7  CCTCCTCAGCGTCAGA-1      5 CD79A 3.104723
## 8  AACCATGAGAGCCTGA-1      0 CD79A 0.000000
## 9  ATGAGTCTCACATTGG-1      2 CD79A 0.000000
## 10 AGTCATGCACTAACCA-1      4 CD79A 2.756005

Create plots

There are different ways to show the stacked violin plot:

| Plot | X-axis | Y-axis | Facet | |------|------------|------------|----------| | a | Identity | Expression | Feature | | b | Expression | Identity | Feature | | c | Feature | Expression | Identity | | d | Expression | Feature | Identity |

Identity on x-axis (A) or y-axis (B)

# Identity on x-axis
a <- ggplot(pbmc, aes(factor(Idents), Expr, fill = Feat)) +
        geom_violin(scale = "width", adjust = 1, trim = TRUE) +
        scale_y_continuous(expand = c(0, 0), position="right", labels = function(x)
                           c(rep(x = "", times = length(x)-2), x[length(x) - 1], "")) +
        facet_grid(rows = vars(Feat), scales = "free", switch = "y") +
        theme_cowplot(font_size = 12) +
        theme(legend.position = "none", panel.spacing = unit(0, "lines"),
          plot.title = element_text(hjust = 0.5),
              panel.background = element_rect(fill = NA, color = "black"),
              strip.background = element_blank(),
              strip.text = element_text(face = "bold"),
              strip.text.y.left = element_text(angle = 0)) +
        ggtitle("Identity on x-axis") + xlab("Identity") + ylab("Expression Level")

# Identity on y-axis
b <- ggplot(pbmc, aes(Expr, factor(Idents), fill = Feat)) +
        geom_violin(scale = "width", adjust = 1, trim = TRUE) +
        scale_x_continuous(expand = c(0, 0), labels = function(x)
                           c(rep(x = "", times = length(x)-2), x[length(x) - 1], "")) +
        facet_grid(cols = vars(Feat), scales = "free")  +
        theme_cowplot(font_size = 12) +
        theme(legend.position = "none", panel.spacing = unit(0, "lines"),
          plot.title = element_text(hjust = 0.5),
              panel.background = element_rect(fill = NA, color = "black"),
              strip.background = element_blank(),
              strip.text = element_text(face = "bold"),
              strip.text.x.top = element_text(angle = 90, hjust = 0, vjust = 0.5)) +
        ggtitle("Identity on y-axis") + xlab("Expression Level") + ylab("Identity")

# Use plot_grid to join plots
plot_grid(a, b, labels = c("A","B"))

<img src="images/StackedVlnPlot_dataframe1.png" width="80%" />

Features on x-axis (C) or y-axis (D)

# Features on x-axis
c <- ggplot(pbmc, aes(factor(Feat), Expr, fill = Feat)) +
        geom_violin(scale = "width", adjust = 1, trim = TRUE) +
        scale_y_continuous(expand = c(0, 0), position="right", labels = function(x)
                           c(rep(x = "", times = length(x)-2), x[length(x) - 1], "")) +
        facet_grid(rows = vars(Idents), scales = "free", switch = "y") +
        theme_cowplot(font_size = 12) +
        theme(legend.position = "none", panel.spacing = unit(0, "lines"),
          plot.title = element_text(hjust = 0.5),
              panel.background = element_rect(fill = NA, color = "black"),
              strip.background = element_blank(),
              strip.text = element_text(face = "bold"),
              strip.text.y.left = element_text(angle = 0),
              axis.text.x = element_text(angle = 90, hjust = 1, vjust = 0.5)) +
        ggtitle("Feature on x-axis") + xlab("Feature") + ylab("Expression Level")

# Features on y-axis
d <- ggplot(pbmc, aes(Expr, factor(Feat), fill = Feat)) +
        geom_violin(scale = "width", adjust = 1, trim = TRUE) +
        scale_x_continuous(expand = c(0, 0), labels = function(x)
                           c(rep(x = "", times = length(x)-2), x[length(x) - 1], "")) +
        facet_grid(cols = vars(Idents), scales = "free") +
        theme_cowplot(font_size = 12) +
        theme(legend.position = "none", panel.spacing = unit(0, "lines"),
          plot.title = element_text(hjust = 0.5),
              panel.background = element_rect(fill = NA, color = "black"),
              strip.background = element_blank(),
              strip.text = element_text(face = "bold")) +
        ggtitle("Feature on y-axis") + xlab("Expression Level") + ylab("Feature")

# Use plot_grid to join plots
plot_grid(c, d, labels = c("C","D"))

<img src="images/StackedVlnPlot_dataframe2.png" width="80%" />

Sort identity classes and features

Note: Some of the codes below are taken and modified from the Seurat package.

Below demonstrates how to recreate the reordering of the identity classes and features seen in Seurat’s stacked violin plots.

# Calculate average expression per Idents, output as wide format
avg <- sapply(X = split(x = pbmc, f = pbmc$Idents),
              FUN = function(df) { return(tapply(X = df$Expr, INDEX = df$Feat, FUN = mean)) })

# L2Norm (Euclidean norm) function
L2Norm <- function(mat, MARGIN){
        normalized <- sweep(x = mat, MARGIN = MARGIN,
                            STATS = apply(X = mat, MARGIN = MARGIN,
                                          FUN = function(x){ sqrt(x = sum(x ^ 2)) }), FUN = "/")
        normalized[!is.finite(x = normalized)] <- 0
        return(normalized)
}

# Performs hierarchical clustering
idents.order <- hclust(d = dist(t(L2Norm(mat = avg, MARGIN = 2))))$order
avg <- avg[,idents.order]
avg <- L2Norm(mat = avg, MARGIN = 1)
mat <- hclust(d = dist(avg))$merge

# Order feature clusters by position of their "rank-1 idents"
position <- apply(X = avg, MARGIN = 1, FUN = which.max)
orderings <- list()
for (i in 1:nrow(mat)) {
        x <- if (mat[i,1] < 0) -mat[i,1] else orderings[[mat[i,1]]]
        y <- if (mat[i,2] < 0) -mat[i,2] else orderings[[mat[i,2]]]
        x.pos <- min(x = position[x])
        y.pos <- min(x = position[y])
        orderings[[i]] <- if (x.pos < y.pos) { c(x, y) } else { c(y, x) }
}
features.order <- orderings[[length(orderings)]]

# Update Feature and Identity factor orders
pbmc$Idents <- factor(pbmc$Idents, levels = levels(pbmc$Idents)[idents.order])
pbmc$Feat <- factor(pbmc$Feat, levels = levels(pbmc$Feat)[features.order])

# Plot stacked violin plot with reordered identity classes and features
e <- ggplot(pbmc, aes(factor(Feat), Expr, fill = Feat)) +
        geom_violin(scale = "width", adjust = 1, trim = TRUE) +
        scale_y_continuous(expand = c(0, 0), position="right", labels = function(x)
                           c(rep(x = "", times = length(x)-2), x[length(x) - 1], "")) +
        facet_grid(rows = vars(Idents), scales = "free", switch = "y") +
        theme_cowplot(font_size = 12) +
        theme(legend.position = "none", panel.spacing = unit(0, "lines"),
          plot.title = element_text(hjust = 0.5),
              panel.background = element_rect(fill = NA, color = "black"),
              strip.background = element_blank(),
              strip.text = element_text(face = "bold"),
              strip.text.y.left = element_text(angle = 0),
              axis.text.x = element_text(angle = 90, hjust = 1, vjust = 0.5)) +
        ggtitle("Identity & feature ordered") + xlab("Feature") + ylab("Expression Level")

e

<img src="images/StackedVlnPlot_dataframe3.png" width="55%" />

Add gene grouping annotation

Below demonstrates how to add gene grouping annotation to sorted stacked violin plots.

# Create grouping info
df <- data.frame(x = levels(pbmc$Feat), group = c("A","A","B","B","B","B","B","C","C","C","D","D","D"),
                 stringsAsFactors = FALSE)
df$x <- factor(df$x, levels = levels(pbmc$Feat))
df$group <- factor(df$group)
df

##         x group
## 1   MS4A1     A
## 2   CD79A     A
## 3     LYZ     B
## 4    CST3
