✨SimRecon: SimReady Compositional Scene Reconstruction from Real Videos✨

<a href="https://xiac20.github.io/">Chong Xia</a>1,2,*, Kai Zhu1,*, Zizhuo Wang1, <a href="https://liuff19.github.io/">Fangfu Liu</a>1, <a href="https://scholar.google.com/citations?user=X7M0I8kAAAAJ&hl=en">Zhizheng Zhang</a>2, <a href="https://duanyueqi.github.io/">Yueqi Duan</a>1,† 1Tsinghua University   2Galbot <h3 align="center">CVPR 2026 🔥</h3>

Teaser Visualization

</div>

SimRecon: We propose SimRecon,a novel compositional scene reconstruction framework that implements a "Perception-Generation-Simulation" pipeline with specialized bridging modules to ensure high visual fidelity and physical plausibility.

📢 News

🔥 [03/18/2026] We release the code of our Scene Graph Synthesizer (SGS) module, making our entire codebase fully open-sourced.
🔥 [03/18/2026] To accommodate diverse choices in 3D asset generation models and physical simulators, we leave their specific implementations open for user customization.
🔥 [03/03/2026] We release the code of our Active Viewpoint Optimization (AVO) module.
🔥 [03/03/2026] We release "SimRecon: SimReady Compositional Scene Reconstruction from Real Videos". Check our project page and arXiv paper.

🌟 Pipeline

Pipeline Visualization

The overall framework of our approach SimRecon. We propose a “Perception-Generation-Simulation” pipeline with object-centric scene representations towards compositional 3D scene reconstruction from cluttered video input. In this figure, we provide illustrative visualizations using the backpack as the example to introduce our two core modules: Active Viewpoint Optimization (AVO) and Scene Graph Synthesizer (SGS). There, we visualize a semantic-level graph for clarity, while our framework operates at the instance-level.

⚙️ Setup

1. Clone Repository

git clone https://github.com/xiac20/SimRecon.git
cd SimRecon

2. Environment Setup

Create conda environment

conda create -n simrecon python=3.9 -y
conda activate simrecon

Install dependencies


pip install torch==2.1.0+cu118 torchvision==0.16.0+cu118 torchaudio==2.1.0+cu118 --extra-index-url https://download.pytorch.org/whl/cu118

pip install --extra-index-url=https://pypi.nvidia.com "cudf-cu11==24.2.*" "cuml-cu11==24.2.*"

pip install -r requirements.txt

Additional Setup

Install CropFormer for instance-level segmentation.

cd semantic_modules/CropFormer
cd mask2former/modeling/pixel_decoder/ops
sh make.sh
cd ../../../../
git clone git@github.com:facebookresearch/detectron2.git
cd detectron2
pip install -e .
pip install git+https://github.com/cocodataset/panopticapi.git
pip install git+https://github.com/mcordts/cityscapesScripts.git
cd ..
pip install -r requirements.txt
pip install -U openmim
mim install mmcv
pip install transformers
mkdir ckpts

Manually download CropFormer checkpoint into semantic_modules/CropFormer/ckpts

💻Data Preprocessing

Please follow the steps below to process your custom dataset, or directly download our preprocessed datasets.

1. Get sparse reconstruction from video input

Follow the original repository from COLMAP or HLOC to get sparse reconstruction results. For scenes with poor image quality and severe occlusion, we strongly recommend using HLOC or other state-of-the-art methods to complete sparse reconstruction.

2. Run instance-level segmentation.

cd semantic_modules/CropFormer
bash run_segmentation.sh "$DATA_DIR"
cd ../..

3. Training 2DGS.

python train_2dgs.py -s data/scene0000_00 -m output/scene0000_00

Put the trained point_cloud.ply file into the $DATA_DIR directory. After successfully executing the above steps, the data directory should be structured as follows:

data
   |——————scene0000_00
      |——————point_cloud.ply
      |——————images
         ...
      |——————sam
         |——————mask
            ...
      |——————sparse
         |——————0
            |——————cameras.bin
            ...

💻Run Examples

We provide three example scenes to help you get started.

1. Generate 3D semantic segmentation

python train_semantic.py -s data/scene0000_00 \
                         -m train_semanticgs \
                         --use_seg_feature --iterations 2500 \
                         --load_filter_segmap --consider_negative_labels

It's normal to get stuck at the DBScan Filter Stage, since the backgrount gaussian points may be divided into multi-regions.
Use --consider_negative_labels to suppress floaters during background segmentation.
The generated instance labels are not accurate and just for reference, which would be further determined by the VLM in the SGS module.

2. Optimize best view by AVO

python optimize_by_avo.py --source_path data/scene0000_00 --label_dir output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500 --max_iterations 100

Use --instance_id to specify the optimized object number. If not specified all objects will be optimized.
Before optimization, you can view the point cloud of each object under output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500/label_pointclouds.
For situations where AVO results are not ideal, please adjust some hyperparameters, such as learning rates for rotation and translation, depth constraint coefficients, etc. The number of optimization rounds can also be adjusted up to 5000 rounds.
For cases where optimization fails due to artifact drift in the 2dgs output point cloud, check out some recent works dedicated to solving such problems.
The generated instance labels are not accurate and just for reference, which would be further determined by the VLM in the SGS module.

3. Generate 3D assets

Users can generate 3D assets by leveraging the optimized best views.

4. Generate instance projected frames

python coverage_sampling.py --scene_path data/scene0000_00 --num_frames 20 --copy_images

This step leverages VGGT to rapidly sample symbol views exhibiting the maximum voxel coverage.

python project_instances_to_frames.py --source_path data/scene0000_00 --label_dir output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500 --sampled_images_dir data/scene0000_00/sampled_images

Users can adjust specific hyperparameters within the script such as min_visible_pixels and min_num_points to ensure an appropriate number of instances.

5. Infer final scene graphs

python infer_scene_graph.py  --instance_project_dir output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500/instance_project  --output_dir output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500/scene_graphs

python merge_scene_graphs.py --scene_graphs_dir output/data/scene0000_00/train_semanticgs/point_cloud/iteration_2500/scene_graphs

Users can subsequently leverage the inferred scene graphs to ascertain relative object relationships within the simulator and activate the simulation to obtain final physically plausible scenes.

🔗Acknowledgement

We are thankful for the following great works when implementing SimRecon:

2DGS, InstaScene, Rodin, SAM, VGGT, Spatial-MLLM

📚Citation

@misc{xia2026simreconsimreadycompositionalscene,
  title={SimRecon: SimReady Compositional Scene Reconstruction from Real Videos},
  author={Chong Xia and Kai Zhu and Zizhuo Wang and Fangfu Liu and Zhizheng Zhang and Yueqi Duan},
  year={2026},
  eprint={2603.02133},
  archivePrefix={arXiv},
  primaryClass={cs.CV},
  url={https://arxiv.org/abs/2603.02133},
}
