xgo

English | 简体中文

xgo provides all-in-one test utilities for golang, including:

• API:
  • Mock
  • Trace
  • Trap
• Tools:
  • Test Explorer
  • Incremental Coverage
• IDE Setup

As for the monkey patching part, xgo works as a preprocessor for go run,go build, and go test(see our blog).

See Quick Start and Documentation for more details.

By the way, I promise you this is an interesting project.

Installation

go install github.com/xhd2015/xgo/cmd/xgo@latest

Verify the installation:

xgo version
# output:
#   1.0.x

xgo help
# output: help messages

If xgo is not found, you may need to check if $GOPATH/bin is added to your PATH variable.

For CI jobs like github workflow, see doc/INSTALLATION.md.

Requirement

xgo requires at least go1.17 to compile.

There is no specific limitation on OS and Architecture.

All OS and Architectures are supported by xgo as long as they are supported by go. | | x86 | x86_64 (amd64) | arm64 | any other Arch... | |:---------|:-----------:|:-----------:|:-----------:|:-----------:| | Linux | Y | Y | Y | Y | | Windows | Y | Y | Y | Y | | macOS | Y | Y | Y | Y | | any other OS... | Y | Y | Y | Y|

Quick Start

Let's write a unit test with xgo:

1. Ensure you have installed xgo by following the Installation section, and verify the installation with:

xgo version
# output
#   1.0.x

2. Init a go project:

mkdir demo
cd demo
go mod init demo

3. Add demo_test.go:

package demo_test

import (
	"testing"

	"github.com/xhd2015/xgo/runtime/mock"
)

func MyFunc() string {
	return "my func"
}

func TestFuncMock(t *testing.T) {
	mock.Patch(MyFunc, func() string {
		return "mock func"
	})
	text := MyFunc()
	if text != "mock func" {
		t.Fatalf("expect MyFunc() to be 'mock func', actual: %s", text)
	}
}

4. Get the github.com/xhd2015/xgo/runtime dependency:

go get github.com/xhd2015/xgo/runtime

5. Test the code:

xgo test -v ./
# NOTE: xgo will take some time to setup for the first time

Output:

=== RUN   TestFuncMock
--- PASS: TestFuncMock (0.00s)
PASS
ok      demo

NOTE: xgo is used to test your code, not just go.

Under the hood, xgo preprocess your code to add mock hooks, and then calls go to do remaining jobs.

The above code can be found at doc/demo.

API

Patch

Patch given function within current goroutine.

The API:

• Patch(fn,replacer) func()

Cheatsheet:

// package level func
mock.Patch(SomeFunc, mockFunc)

// per-instance method
// only the bound instance `v` will be mocked
// `v` can be either a struct or an interface
mock.Patch(v.Method, mockMethod)

// per-TParam generic function
// only the specified `int` version will be mocked
mock.Patch(GenericFunc[int], mockFuncInt)

// per TParam and instance generic method
v := GenericStruct[int]
mock.Mock(v.Method, mockMethod)

// closure can also be mocked
// less used, but also supported
mock.Mock(closure, mockFunc)

Parameters:

• If fn is a simple function(i.e. a package level function, or a function owned by a type, or a closure(yes, we do support mocking closures)),then all call to that function will be intercepted,
• replacer another function that will replace fn

Scope:

• If Patch is called from init, then all goroutines will be mocked.
• Otherwise, Patch is called after init, then the mock interceptor will only be effective for current goroutine, other goroutines are not affected.

NOTE: fn and replacer should have the same signature.

Return:

• a func() can be used to remove the replacer earlier before current goroutine exits

Patch replaces the given fn with replacer in current goroutine. It will remove the replacer once current goroutine exits.

Example:

package patch_test

import (
	"testing"

	"github.com/xhd2015/xgo/runtime/mock"
)

func greet(s string) string {
	return "hello " + s
}

func TestPatchFunc(t *testing.T) {
	mock.Patch(greet, func(s string) string {
		return "mock " + s
	})

	res := greet("world")
	if res != "mock world" {
		t.Fatalf("expect patched result to be %q, actual: %q", "mock world", res)
	}
}

Patch(and Mock below) also works for package-level variables:

package patch

import (
    "testing"

    "github.com/xhd2015/xgo/runtime/mock"
)

var a int = 123

func TestPatchVarTest(t *testing.T) {
	mock.Patch(&a, func() int {
		return 456
	})
	b := a
	if b != 456 {
		t.Fatalf("expect patched variable a to be %d, actual: %d", 456, b)
	}
}

See runtime/mock/MOCK_VAR_CONST.md.

Mock

runtime/mock also provides another API called Mock, which is similar to Patch.

The the only difference between them lies in the the second parameter: Mock accepts an interceptor.

Mock can be used where Patch cannot be used, such as functions with unexported type.

API details: runtime/mock/README.md

The Mock API:

• Mock(fn, interceptor)

Parameters:

• fn same as described in Patch section
• If fn is a method(i.e. file.Read),then only call to the instance will be intercepted, other instances will not be affected

Interceptor Signature: func(ctx context.Context, fn *core.FuncInfo, args core.Object, results core.Object) error

• If the interceptor returns nil, then the target function is mocked,
• If the interceptor returns mock.ErrCallOld, then the target function is called again,
• Otherwise, the interceptor returns a non-nil error, that will be set to the function's return error.

There are other 2 APIs can be used to setup mock based on name, check runtime/mock/README.md for more details.

Method mock example:

type MyStruct struct {
    name string
}
func (c *MyStruct) Name() string {
    return c.name
}

func TestMethodMock(t *testing.T){
    myStruct := &MyStruct{
        name: "my struct",
    }
    otherStruct := &MyStruct{
        name: "other struct",
    }
    mock.Mock(myStruct.Name, func(ctx context.Context, fn *core.FuncInfo, args core.Object, results core.Object) error {
        results.GetFieldIndex(0).Set("mock struct")
        return nil
    })

    // myStruct is affected
    name := myStruct.Name()
    if name!="mock struct"{
        t.Fatalf("expect myStruct.Name() to be 'mock struct', actual: %s", name)
    }

    // otherStruct is not affected
    otherName := otherStruct.Name()
    if otherName!="other struct"{
        t.Fatalf("expect otherStruct.Name() to be 'other struct', actual: %s", otherName)
    }
}

Trace

Trace might be the most powerful tool provided by xgo, this blog has a more thorough example: https://blog.xhd2015.xyz/posts/xgo-trace_a-powerful-visualization-tool-in-go

It is painful when debugging with a deep call stack.

Trace addresses this issue by collecting the hierarchical stack trace and stores it into file for later use.

Needless to say, with Trace, debug becomes less usual:

package trace_test

import (
    "fmt"
    "testing"
)

func TestTrace(t *testing.T) {
    A()
    B()
    C()
}

func A() { fmt.Printf("A\n") }
func B() { fmt.Printf("B\n");C(); }
func C() { fmt.Printf("C\n") }

Run with xgo:

# run the test
# this will write the trace into TestTrace.json
# --strace represents stack trace
xgo test --strace ./

# view the trace
xgo tool trace TestTrace.json

Output:

Another more complicated example from runtime/test/stack_trace/update_test.go:

Real world examples:

• https://github.com/Shibbaz/GOEventBus/pull/11

Trace helps you get started to a new project quickly.

By default, Trace will write traces to a temp directory under current working directory. This behavior can be overridden by setting --strace-dir=<DIR>.

Besides the --strace flag, xgo allows you to define which span should be collected, using trace.Trace():

import "github.com/xhd2015/xgo/runtime/trace"

func TestTrace(t *testing.T) {
    A()
    trace.Trace(trace.Config{OutputFile:"demo.json"},nil,func() (interface{},error){
        B()
        C()
    return nil,nil
    })
}

The trace will only include B() and C().

Recorder

The following example logs function execution trace by adding a Recorder:

package main

import (
    "context"
    "fmt"

    "github.com/xhd2015/xgo/runtime/trace"
)

func main() {
    trace.RecordCall(A, func(){
        fmt.Printf("record A\n")
    })
    trace.RecordCall(B,func(){
        fmt.Printf("record B\n")
    })
    A()
    B()
}

func A() {
    fmt.Pri
