NTransformer

High-efficiency C++/CUDA LLM inference engine. Runs Llama 70B on a single RTX 3090 (24GB VRAM) by streaming model layers through GPU memory via PCIe, with optional NVMe direct I/O that bypasses the CPU entirely.

Key Results

| Model | Mode | Decode | VRAM | Notes | |-------|------|--------|------|-------| | Llama 3.1 8B Q8_0 | Resident | 48.9 tok/s | 10.0 GB | All layers in VRAM | | Llama 3.1 8B Q8_0 | Tiered (auto) | 48.8 tok/s | 10.3 GB | 32/32 layers auto-promoted to VRAM | | Llama 3.1 70B Q6_K | Streaming (mmap) | 0.006 tok/s | 7.3 GB | Page cache thrashing (53 GB > 48 GB RAM) | | Llama 3.1 70B Q6_K | Tiered (auto) | 0.2 tok/s | 23.1 GB | 26 VRAM + 54 RAM + 0 NVMe | | Llama 3.1 70B Q4_K_M | Tiered (auto) | 0.3 tok/s | 22.9 GB | 36 VRAM + 44 RAM (50% faster) | | Llama 3.1 70B Q4_K_M | Tiered + layer skip | 0.5 tok/s | 22.9 GB | 36 VRAM + 44 RAM, 20 layers skipped |

3-tier adaptive caching auto-sizes from hardware: VRAM-resident layers (zero I/O) + pinned RAM (H2D only) + NVMe/mmap fallback. Achieves 83x speedup over mmap baseline for 70B on consumer hardware (RTX 3090 + 48 GB RAM).

Bottleneck is PCIe H2D bandwidth at Gen3 x8 (~6.5 GB/s). Q4_K_M fits 10 more layers in VRAM (36 vs 26), reducing tier B transfers. Layer skip (cosine similarity calibration) eliminates 20/80 layers per token with minimal quality loss.

Features

Zero external dependencies beyond CUDA Toolkit (no PyTorch, no cuBLAS)
GGUF model format with Q4_0, Q8_0, Q4_K_M, Q5_K, Q6_K, F16, F32 quantization
3-Tier Adaptive Caching: auto-sized VRAM resident + pinned RAM + NVMe/mmap tiers
SLEP streaming: double-buffered layer pipeline overlaps NVMe reads, PCIe DMA, and GPU compute
gpu-nvme-direct backend: userspace NVMe driver reads model weights directly to pinned GPU-accessible memory
Layer skip: cosine-similarity calibration skips redundant layers (20/80 skipped at threshold 0.98)
Self-speculative decoding: VRAM-resident layers as draft model (no extra model needed)
Four data paths (auto-selected): VRAM resident > pinned RAM H2D > mmap pinned > CPU worker memcpy
Llama architecture: RoPE, GQA, SwiGLU, RMSNorm, KV cache

Requirements

Linux (tested on Ubuntu, kernel 6.17+)
CUDA Toolkit 13.1
gcc-14 / g++-14
NVIDIA GPU with Compute Capability 8.0+ (RTX 3090 tested)
CMake 3.24+
(Optional) NVMe SSD on separate PCIe slot + gpu-nvme-direct library

Quick Start

# Build
mkdir build && cd build
cmake .. -DCMAKE_BUILD_TYPE=Release \
  -DCMAKE_C_COMPILER=gcc-14 \
  -DCMAKE_CXX_COMPILER=g++-14 \
  -DCMAKE_CUDA_COMPILER=/usr/local/cuda-13.1/bin/nvcc
cmake --build . -j

# Run (resident mode — model fits in VRAM)
./ntransformer -m /path/to/llama-8b-q8_0.gguf -p "Hello" -n 128

# Run (streaming mode — model larger than VRAM)
./ntransformer -m /path/to/llama-70b-q6_k.gguf -p "Hello" -n 32 --streaming

# Run with layer skip (fastest for 70B)
./ntransformer -m /path/to/llama-70b-q4_k_m.gguf -p "Hello" -n 32 --streaming --skip-threshold 0.98

# Self-speculative decoding (VRAM layers as draft, no extra model)
./ntransformer -m /path/to/llama-70b-q6_k.gguf -p "Hello" -n 32 --self-spec --draft-k 3

# Chat mode
./ntransformer -m /path/to/model.gguf --chat

# Benchmark
./ntransformer -m /path/to/model.gguf --benchmark -n 64

System Setup

Running ntransformer with NVMe direct I/O requires system-level modifications. An automated setup script handles all of them:

# Full first-time setup (interactive, creates backups)
sudo ./scripts/setup_system.sh

# Check current system state (no changes)
sudo ./scripts/setup_system.sh --check

# NVMe-only (run after every reboot)
sudo ./scripts/setup_system.sh --nvme-only

What the script modifies and why

| Phase | What | Why | Risk | Rollback | |-------|------|-----|------|----------| | 1 | Installs gcc-14, cmake, kernel headers | CUDA 13.1 is incompatible with gcc-15 (Ubuntu 25.10 default) | Low — standard packages | apt remove | | 2 | Adds amd_iommu=off to GRUB | AMD root complex drops GPU→NVMe P2P reads if IOMMU is on. Disabling IOMMU lets posted PCIe writes (doorbells) through | Medium — removes hardware DMA isolation between all PCIe devices. Don't run on multi-tenant/server systems | Remove amd_iommu=off from /etc/default/grub, run update-grub, reboot | | 3 | Patches NVIDIA DKMS (os-mlock.c) | follow_pfn() was removed in kernel 6.12+. Without the patch, cudaHostRegisterIoMemory fails and the GPU can't map NVMe BAR0 for MMIO writes | High — bad patch prevents GPU driver from loading (black screen on reboot). Backup .orig created automatically | cp os-mlock.c.orig os-mlock.c in DKMS source dir, dkms remove/install nvidia/VERSION | | 3b | Patches CUDA header (math_functions.h) | glibc 2.42+ (Ubuntu 25.10) declares rsqrt()/rsqrtf() with noexcept. CUDA 13.1 declares without, causing build failure | Low — only affects one header, backup created | cp math_functions.h.orig math_functions.h | | 4 | Loads VFIO modules (vfio, vfio-pci) | NVMe must be bound to VFIO for userspace access. Consumer GPUs (GeForce) require enable_unsafe_noiommu_mode=1 | Low — modules unload on reboot. "Unsafe noiommu" means no IOMMU DMA protection for VFIO devices | Reboot (or modprobe -r vfio-pci vfio) | | 5 | Unbinds NVMe from kernel, binds to VFIO | gpu-nvme-direct needs raw PCIe access. The NVMe disappears from /dev/ while bound to VFIO | High if wrong device — never run on your boot drive. Script auto-detects and refuses boot devices | sudo ./scripts/restore_nvme.sh |

BIOS settings (manual, before running the script)

Above 4G Decoding: ON (required for 64-bit BAR mapping)
IOMMU: OFF (or leave on — the script adds the kernel parameter)
Secure Boot: OFF (required for unsigned/patched kernel module loading)

Hardware disclaimer

WARNING: This project performs low-level PCIe operations (GPU MMIO writes to NVMe controller registers, userspace NVMe command submission, VFIO device passthrough). While tested extensively on RTX 3090 + WD SN740, incorrect configuration or hardware incompatibilities could theoretically cause:

NVMe link failure requiring power cycle (observed during development with GPU reads)

Data loss on the NVMe device used for raw block storage

System instability from disabled IOMMU or patched kernel modules

Never use your boot drive for NVMe direct I/O. Always use a dedicated secondary NVMe. The authors are not responsible for hardware damage or data loss. Use at your own risk.

Scripts reference

| Script | Purpose | When to run | |--------|---------|-------------| | scripts/setup_system.sh | Full system configuration (7 phases) | First-time setup | | scripts/setup_system.sh --nvme-only | VFIO + NVMe bind only | After every reboot | | scripts/setup_system.sh --check | Verify system state | Debugging | | scripts/setup_nvme.sh [BDF] | Bind single NVMe to VFIO | After reboot (standalone) | | scripts/restore_nvme.sh [BDF] | Restore NVMe to kernel driver | When done with NVMe direct |

NVMe Direct Streaming

For models that don't fit in VRAM, the NVMe backend eliminates the CPU from the data path:

NVMe SSD → (DMA) → Pinned Staging → (PCIe H2D) → GPU Buffers → Compute

Setup

# Build with NVMe support (requires gpu-nvme-direct library)
cmake .. -DCMAKE_BUILD_TYPE=Release -DUSE_GPUNVME=ON \
  -DCMAKE_C_COMPILER=gcc-14 -DCMAKE_CXX_COMPILER=g++-14 \
  -DCMAKE_CUDA_COMPILER=/usr/local/cuda-13.1/bin/nvcc
cmake --build . -j

# Write GGUF model to NVMe raw device
sudo ./scripts/restore_nvme.sh           # ensure kernel driver is bound
sudo dd if=model.gguf of=/dev/nvme0n1 bs=1M oflag=direct status=progress

# Bind NVMe to VFIO for userspace access
sudo ./scripts/setup_nvme.sh             # loads VFIO, forces D0, enables BusMaster

# Run with NVMe backend
sudo GPUNVME_PCI_BDF=0000:01:00.0 GPUNVME_GGUF_LBA=0 \
  ./build/ntransformer -m /path/to/model.gguf -p "Hello" -n 32 --streaming

# Restore NVMe to kernel driver when done
sudo ./scripts/restore_nvme.sh

How It Works

The GGUF model file is written to raw NVMe blocks via dd
setup_nvme.sh binds the NVMe to VFIO, forces PCIe D0 power state, enables BusMaster
gpu-nvme-direct initializes the NVMe controller from userspace (admin queues, I/O queues)
During inference, each layer (~670 MB for 70B Q6_K) is read via 670 NVMe commands in ~202 ms
Data lands in CUDA pinned staging memory, then async DMA to GPU compute buffers
Pipeline overlaps NVMe reads, H2D DMA, and GPU compute across double buffers

Architecture

src/
├── core/           # Tensor, allocator, GPU device management
├── cuda/           # CUDA kernels: GEMV, RMSNorm, RoPE, SwiGLU, softmax
├── memory/         # SLEP layer streaming engine (NVMe + mmap backends)
├── model/          # Transformer: config, GGUF loader, attention, FFN, norms
├── inference/      # Tokenizer, sampler, engine
├── utils/          # Timer, logger
├── main.cpp        # CLI entry point
scripts/
├── setup_system.sh # Full system setup (GRUB, NVIDIA patch, CUDA patch, VFIO, NVMe)
├── setup_nvme.sh   # Bind NVMe to VFIO, configure for gpu-nvme-direct
├── restore_nvme.sh # Restore NVMe to kernel driver
tests/              # Unit tests (tensor, GEMM kernels, NVMe layer loader)

3-Tier Adaptive Caching

forward_tiered() — hybrid pipeline:

Tier A (VRAM resident, layers 0..28):
  GPU Compute:  [layer 0][layer 1]...[layer 28]     (zero I/O, weights permanent)

Tier B (pinned RAM, layers 29..79, double-buffered):
  H2D DMA:     [L29→gpu0][L30→gpu1][L31→gpu0]...   (async from pinned RAM)
  GPU Compute: [         ][layer 29][layer 30]...    (overlapped with H2D)

Tier C (NVMe/mmap fallback, if needed):
  NVMe/memcpy: [read L→stg0][read L→stg1]...
  H2D DMA:     [            ][stg0→gpu0  ]
