Deep Policy Dynamic Programming for Vehicle Routing Problems

This repository contains code for Deep Policy Dynamic Programming by Wouter Kool, Herke van Hoof, Joaquim Gromicho and Max Welling.

Table of contents

• Overview
• Install environment
• Generate instances (or download instances)
• Generate example solutions (or download example solutions)
• Train model (or download pretrained models)
• Generate heatmaps (or download heatmaps)
• Running Deep Policy Dynamic Programming
• Reproducing results from the paper
• Visualizing solutions

Overview

See below for the full training and testing pipeline, including shortcuts. The shortest path to results is to generate/download (test-)instances, download heatmaps and run DPDP. All data related to this repository can be found here. For TSP, we only provide instructions using the pre-trained model or downloading the heatmaps directly. For data/instructions for training the TSP model we refer to graph-convnet-tsp.

Install environment

It is recommended to use Anaconda and install PyTorch with the right cudatoolkit and install CuPy and PyTorch scatter with the same cuda toolkit versions:

# Create environment named 'dpdp' and activate
conda create -n dpdp python=3.8 scipy anaconda -y
conda activate dpdp
# Install some basic packages
conda install tqdm -y
pip install gdown
# Install PyTorch, see https://pytorch.org/get-started/locally/
conda install pytorch torchvision torchaudio cudatoolkit=10.2 -c pytorch -y
# If you want to train models, you need these packages
pip install tensorboardx==1.5 fastprogress==0.1.18
# We use cupy for some efficient operations
# Somehow conda installation fails
# conda install -c conda-forge cupy cudatoolkit=10.2 -y
pip install cupy-cuda102
# Also some efficient sparse operations using https://github.com/rusty1s/pytorch_scatter
pip install torch-scatter -f https://pytorch-geometric.com/whl/torch-1.10.0+cu102.html

Generate instances (or download)

Preferably generate instances as files are large but easy to generate, this may take a few minutes for 1 million training instances, but validation/test instances should be seconds. For TSP, we don't generate training instances as we used the pre-trained model from graph-convnet-tsp.

# Generate validation and test data for tsp and vrp
python generate_data.py --problem all --name validation --seed 4321
# Note, due to some subtle differences it is recommended to download the test data rather than generate (see below)
# python generate_data.py --problem all --name test --seed 1234
# Note: training data only needed if you want to train a model yourself (here only vrp)
python generate_data.py --problem vrp --name train --seed 42 --dataset_size 1000000 # May take some minutes, feel free to optimize!

Download instances

If generating instances fails, you can download the datasets from the folder data in here. The files should be saved as data/{tsp|vrp}/{dataset_name}.pkl. This can be done using the below commands.

pip install gdown

mkdir -p data/tsp
cd data/tsp

# Download tsp datasets (22mb each)
gdown --id 1tlcHok1JhOtQZOIshoGtyM5P9dZfnYbZ # tsp100_validation_seed4321.pkl
gdown --id 1woyNI8CoDJ8hyFko4NBJ6HdF4UQA0S77 # tsp100_test_seed1234.pkl

cd ../..

mkdir -p data/vrp
cd data/vrp

# Download nazari datasets (25mb, 25mb and 2.5 GB)
gdown --id 1FRzrf720xG-POPU220_Y_jfRoV9vpz8P # vrp_nazari100_validation_seed4321.pkl
gdown --id 1G5K4b1PzUdxjVmqxRXpamkbHolsxi8jv # vrp_nazari100_test_seed1234.pkl
gdown --id 1YzBRUIuuCTVzm2VbLUi7D2XquSO2ihd9 # vrp_nazari100_train_seed42.pkl

# Download uchoa datasets (25mb, 25mb and 2.5 GB)
gdown --id 1e6cUGCD5_iC3OQTA6NM38UDFEaKWsGGt # vrp_uchoa100_validation_seed4321.pkl
gdown --id 1Se_x7gfkeVNq-crGTCsOCtda97XiEwJr # vrp_uchoa100_test_seed1234.pkl
gdown --id 16nYaVr3cloxpVBeb3ueXYtnpdeCZCMkj # vrp_uchoa100_train_seed42.pkl

cd ../..

Generate example solutions (or download)

Note: this step can be skipped if you download a pre-trained model or heatmaps directly. If you only want to train a model, it is recommended to download example solutions (see below) as generating them takes very long (multiple weeks on a single machine for 1 million instances). These steps are included for full reproducibility or if you want to generate solutions for your own dataset.

To generate solutions for VRP using LKH3 for the validation/test sets, use the below commands. This will download and compile LKH automatically and use multiprocessing to run on all available CPUs in parallel (this can be disabled by adding --cpus=1).

python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_nazari100_validation_seed4321.pkl -f
python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_nazari100_test_seed1234.pkl -f

As the training set is very large (1 million instances), it is recommended to download example solutions as described below. If you really want to generate training data yourself, it may be desired to divide the computation in separate commands (which can be run on separate machines), e.g. in 100 batches of 10K instances. For the Uchoa et al. dataset we used 250K instances. Since results are cached, a single file with the results can then quickly be generated after all commands have finished.

# These commands can be run in parallel on different machines
for i in {0..99}; do python -m python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_nazari100_train_seed42.pkl -n 10000 --offset ${i}0000 -f; done
for i in {0..99}; do python -m python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_uchoa100_train_seed42.pkl -n 10000 --offset ${i}0000 -f; done
# Run this after all above commands have finished! Generate solutions using cache (--only_cache to not retry failed instances)
python -m python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_nazari100_train_seed42.pkl -f --only_cache
python -m python -m problems.vrp.vrp_baseline lkh data/vrp/vrp_uchoa100_train_seed42.pkl -n 250000 -f --only_cache

Download example solutions

Example solutions can be downloaded from the folder results in here and should be saved in results/vrp/{dataset_name}/{filename}.pkl, which can be achieved using below commands.

pip install gdown

mkdir -p results/vrp
cd results/vrp

# Download nazari example solutions (250mb, 2.5mb and 2.5mb)
mkdir -p vrp_nazari100_train_seed42 && gdown --id 1shWepqKxnCK1-xOWnkmj9T2iNHOP_lqg --output vrp_nazari100_train_seed42/vrp_nazari100_train_seed42-lkh.pkl
mkdir -p vrp_nazari100_validation_seed4321 && gdown --id 165bRSHpYGg9COILPDQEA1G_onpVDLaGl --output vrp_nazari100_validation_seed4321/vrp_nazari100_validation_seed4321-lkh.pkl
mkdir -p vrp_nazari100_test_seed1234 && gdown --id 1L_LFimzvKwOewva7KfDvh08sVhkcHXFW --output vrp_nazari100_test_seed1234/vrp_nazari100_test_seed1234-lkh.pkl

# Download uchoa example solutions (65mb, 2.5mb and 2.5mb)
mkdir -p vrp_uchoa100_train_seed42 && gdown --id 1HjBIX-eh6cY0f2hpEry6tnUh1GnTQMe8 --output vrp_uchoa100_train_seed42/vrp_uchoa100_train_seed42n250000-lkh.pkl
mkdir -p vrp_uchoa100_validation_seed4321 && gdown --id 1JdcrWcYKMWdvs-oud7juc3zeJpPcJkj3 --output vrp_uchoa100_validation_seed4321/vrp_uchoa100_validation_seed4321-lkh.pkl
mkdir -p vrp_uchoa100_test_seed1234 && gdown --id 1sMyxYOQhJ3uI2bIY09EisjvLz0lLBfX- --output vrp_uchoa100_test_seed1234/vrp_uchoa100_test_seed1234-lkh.pkl

# LKHU result for failed instance 6216 of validation set and 5099 and 9795 of test set
gdown --id 1sHIeO2J4z04q-tG1TzV87LxlLEZTSv0B --output vrp_uchoa100_validation_seed4321/vrp_uchoa100_validation_seed4321offs6216n1-lkhu.pkl
gdown --id 1DvbubTuTBisvGdRO2wjNy5W3tl7CfefL --output vrp_uchoa100_test_seed1234/vrp_uchoa100_test_seed1234offs5099n1-lkhu.pkl
gdown --id 18YKCss2AI8Bd-sZA9AzN8UlrTcNeuOG0 --output vrp_uchoa100_test_seed1234/vrp_uchoa100_test_seed1234offs9795n1-lkhu.pkl

cd ../..

Visualize example solutions

You can inspect if everything went well by visualizing the example solutions:

python visualize.py --problem vrp --instances data/vrp/vrp_nazari100_validation_seed4321.pkl \
 --solutions results/vrp/vrp_nazari100_validation_seed4321/vrp_nazari100_validation_seed4321-lkh.pkl

Train model

To train the model for TSP, see graph-convnet-tsp. For VRP, use the commands below:

python main_vrp.py --config configs/vrp_nazari100.json
python main_vrp.py --config configs/vrp_uchoa100.json

By default this will run on all GPUs. To run on specific GPUs, use

CUDA_VISIBLE_DEVICES=0,1 python main_vrp.py ...

With +-10GB of memory (1080Ti) you can run a batch size of 6 per GPU. A batch size of 48 takes about 80GB of memory (fits, e.g. 4x TitanRTX). If you get out-of-memory errors there are a number of options:

• Run on more/larger GPUs. :)
• Alternatively, reduce the value for batch_size (default 48) in the config, which will reduce performance (opt
