TopoSort - Set Based Topological Sort

Note: TopoSort has been migrated to use Zig 0.15.1. See Zig 0.15.1 release notes for any breaking changes.

TopoSort is a highly efficient Zig library for performing topological sort on dependency graph. It uses a novel set based approach for finding the topological order. This small library is packed with the following features:

Building dependency graph from dependency data.
Performing set based topological sort on the graph.
Partitioning the graph in topological ordered subsets.
Generating dependence-free subsets for parallel processing.
Generating topological order on the nodes.
Cycle detection and cycle reporting.
Support different node types.

Algorithm description

Installation

Go to the Releases page. Pick a release to add to your project. Identify the file asset URL for the release version. E.g. https://github.com/williamw520/toposort/archive/refs/tags/1.0.2.tar.gz

Use zig fetch to add the TopoSort package to your Zig project. Run the following command to fetch the TopoSort package:

  zig fetch --save https://github.com/williamw520/toposort/archive/refs/tags/<VERSION>.tar.gz

zig fetch updates your build.zig.zon file with the URL with file hash added in the .dependency section of the file.

.{
    .name = "my-project",
    ...
    .dependencies = .{
+       .toposort = .{
+           .url = "zig fetch https://github.com/williamw520/toposort/archive/refs/tags/<VERSION>.tar.gz",
+           .hash = "toposort-...",
+       },
    },
}

Update your build.zig with the lines for toposort.

  pub fn build(b: *std.Build) void {
      ...
+     const opts = .{ .target = target, .optimize = optimize };
+     const toposort_module = b.dependency("toposort", opts).module("toposort");
      ...
      const exe = b.addExecutable(.{
          .name = "my_project",
          .root_module = exe_mod,
      });
+     exe.root_module.addImport("toposort", toposort_module);

The .addImport("toposort") call let you import the module into your Zig source files.

const toposort = @import("toposort");

Usage

Usage typically follows the following steps in your Zig source file.

Import

const toposort = @import("toposort");
const TopoSort = toposort.TopoSort;
const SortResult = toposort.SortResult;

Initialization and memory management.

    const T = usize;  // node data type
    var tsort = try TopoSort(T).init(allocator, .{});
    defer tsort.deinit();

The data type of the node value is provided as a comptime type to TopoSort(T).

Adding dependency data.

    try tsort.add(101, 102);    // node 102 depends on the leading node 101
    try tsort.add(102, 103);
    try tsort.add(101, 104);

Performing the topological sort

    const result = try tsort.sort();

Checking for cycles

    if (result.has_cycle()) {
        for (result.get_cycle_set().items) |id| {
            const cyclic_node = result.get_node(id);
            ...
        }
    }

Otherwise, process the sorted non-cyclic result

    const sets: ArrayList(ArrayList(T)) = result.get_sorted_sets();
    for (sets.items) |subset| {     // the node sets are in topological order
        for (subset.items) |node| { // nodes within each set are dependence free from each other.
            ...
        }
    }

TopoSort figures out the nodes that have no dependence with each other in the linear order of the topological sequence and groups them together as subsets. This allows you to run/process the nodes of each subset in parallel.

The subsets themselves are in topological order. If there's no need for parallel processing, the nodes in each subset can be processed sequentially, which fit in the overall topological order of all the nodes.

Memory Ownership

Nodes are passed in by value in add() and are stored by value in the TopoSort's Data struct. For simple type like integer (e.g. u16, u32), the node values are simply copied. For slice and pointer node type (e.g. []const u8), the memory for the nodes are not duplicated. Memory is owned and managed by the caller.

Configuration

The Toposort.init() function takes in optional configurations. E.g.

    const T = usize;  // node data type
    var tsort = try TopoSort(T).init(allocator, .{
        verbose = true,
        max_range = 4000,
    });

Setting the verbose flag prints internal messages while sorting.

The max_range property sets the maximum value of the node item value. E.g. For node values ranging from 1, 2, 3, 20, 75, ... 100, 100 is the maximum value. If all your node values are positive integers, passing in a number type (u16, u32, u64, etc) for the node data type and setting the max_range let TopoSort use a simpler data structure with faster performance. Building a dependency tree can be more than 3X or 4X faster. Compare the 3rd benchmark and 4th benchmark in tests.zig.

More Usage

To use a slice/string for the node type,

    const T = []const u8;
    var tsort = try TopoSort(T).init(allocator, .{});

To get a list of topologically sorted nodes.

    const T = []const u8;
    var list = ArrayList(T).init(allocator);    // list to hold the returned nodes.
    defer list.deinit();
    for ((try result.get_sorted_list(&list)).items) |node| {
        ...
    }

To add dependency similar to the Makefile rule format,

Add the dependent node A to the leading B node. A: B
Add the dependent node B to the leading C node. B: C
Add the dependent node B to a list of leading nodes. B: E F G

    const T = []const u8;
    var tsort = try TopoSort(T).init(allocator, .{});
    try tsort.add_dep("A", "B");    // A: B
    try tsort.add_dep("B", "C");    // B: C
    try tsort.add_dep("B", "D");    // B: D
    try tsort.add_deps("B", &[_]T{ "E", "F", "G" });    // B: E F G

    var nodes = ArrayList(T).init(allocator);
    try nodes.append("E");
    try nodes.append("F");
    try nodes.append("G");
    try tsort.add_deps("B", nodes.items);

To add a graph in one shot in text string,

    var tsort = try TopoSort([]const u8).init(allocator, .{});
    try tsort.add_graph("(a b) (a c) (d) (c e f g)");

The format of the graph data is a series of "(dep lead)" rules in a string. In the example above, a depends on b, a depends on c, d depends on none, and c depends on e, f, and g.

This can be called multiple times with different parts of the graphs to build the whole thing.

To traverse the list of nodes in the graph,

    for (result.get_nodes().items) |node| {
        ...
    }

To traverse the dependency graph recursively,

    const T = usize;  // node data type
    var tsort = try TopoSort(T).init(allocator, .{});
    ...
    const result = try tsort.sort();
    visit_tree(result, null, result.get_root_set());

    fn visit_tree(result: SortResult(T), lead_id: ?u32, dependent_ids: ArrayList(u32)) {
        if (lead_id) |id| { // lead_id is optional since the root nodes have no leading nodes.
            const lead_node = result.get_node(id);
            ...
        }
        for (dependent_ids.items) |node_id| {
            const dependent_node = result.get_node(node_id);
            ...
            visit_tree(result, node_id, result.get_dependents(node_id));
        }
    }

Command Line Tool

TopoSort comes with a command line interface (CLI) tool toposort-cli, which uses the TopoSort library internally. The data file it used follows the simple dependent rule format of Makefile. E.g.

  A: B
  B: C D
  C: E F G

Sample invocations on the test data:

  zig-out/bin/toposort-cli --data data/data.txt
  zig-out/bin/toposort-cli --data data/data.txt --verbose
  zig-out/bin/toposort-cli --data data/data2.txt
  zig-out/bin/toposort-cli --data data/data_cycle1.txt
  zig-out/bin/toposort-cli --data data/data_cycle2.txt
  zig-out/bin/toposort-cli --data data/data_num.txt --int

Specify the whole graph in the command line.

  zig-out/bin/toposort-cli --graph "(a b) (b d) (b c) (c d)"
  zig-out/bin/toposort-cli --graph "(a b) (a c) (d) (c e f g)"

Standalone Build

To build the project itself, git clone the repository, then run the standard zig build commands. The binary output is in zig-out/bin/toposort-cli

zig build

This runs the CLI from the zig build directly.

zig build run -- --data data/data.txt

This runs the CLI with graph input on the command line.

zig build run -- --graph "(a b) (a c) (b d) (c d)"

Benchmarks

TopoSort comes with some benchmark tests.

Run zig build test -Doptimize=ReleaseFast to run the benchmarks.

Note that the benchmarks take a number of minutes to run, especially for the debug mode build. Comment out some benchmarks in the test section of toposort.zig for faster run.

Benchmark Runs

Benchmarks ran on a ThinkPad T14 Gen 2 (year 2021), with an AMD Ryzen 7 PRO 5850U CPU, plugged-in with the max power plan, on a single core since the benchmarks are single threaded.

The first two sets of benchmarks check the effect of increasing the node counts in 10X factor, with 1 link between nodes. Notice the times scaling up in locked steps with the node counts. The observation fits the asymptotic complexity predication of O(|N| + |E|). See Algorithm.

Benchmark increasing node in 10X scale on branching 1, with max_range
