What's withrottle?

This is truncated JMRI WiThrottle server implementation for DCC++ command station based on ESPDuino (ESP-13) shield

Adding support of ESP8266 board to Arduino IDE

Start Arduino and open Preferences window.
Enter http://arduino.esp8266.com/stable/package_esp8266com_index.json in to Additional Board Manager URLs field. You can add multiple URLs, separating them with commas.
Open Boards Manager from Tools > Board menu and find esp8266 platform.
Select the version you need from a drop-down box.
Click install button.

Sketch uploading

Connect USB to UART converter to ESP13 UART connector.
Don't forget swith it to 3.3 voltage level
Connect pin D0 of ESP13 side connector to Ground.
Connect USB to UART converter to PC.
Select ESPDuino (ESP-13 Module) form Tools > Board menu.
Select USB port from Tools > Port menu.
Click upload button or select Upload from Sketch menu.

Board installation

Disconnect USB to UART converter from ESP board.
Remove jumper wire between D0 and Ground pins.
Switch SW1 to ON.
Remove jumper wires from Motor Shield board.
Install ESP board atop of Motor Shield board.
Connect jumper wires to Arduino side connector between D5 and D13 pins, and between D10 and D12 pins if you use Arduino UNO DCC++, or between D2 and D13 pins for Arduino MEGA DCC++.

How to use

Turn power ON on DCC++.
Open WiFi settings on mobile device.
Find and connect to «withrottle» network.
Start Engine Driver or WiThrottle app on mobile device
On Engine Driver select ESPWTServer on Discovered Servers
On WiThrottle app go to Settings page, select «Server Configuration», and turn on «Use automatic network configuration». Restart WiThrottle app.
Enjoy!

Links

DCC++ https://github.com/DccPlusPlus ESP8266 Core https://github.com/esp8266/Arduino JMRI WiFi Throttle Communications Protocol http://jmri.sourceforge.net/help/en/package/jmri/jmrit/withrottle/Protocol.shtml WiThrottle official site http://www.withrottle.com/WiThrottle/Home.html Download WiThrottle on the AppStore https://itunes.apple.com/us/app/withrottle-lite/id344190130 Engine Driver official site https://enginedriver.mstevetodd.com/ Download Engine Driver on the GooglePlay https://play.google.com/store/apps/details?id=jmri.enginedriver

Change log

2017-09-10 Fixed release responce for WiThrottle.app Fixed synchronize power status on clients
2017-09-24 Added mDNS responder Added start delay to fix connection problem with DCC++
2018-12-11 Fixed Engine Driver v2.19+ throttle numbers
