📚 Arduino iButtonTag Library

An Arduino library handling iButton identification tags.

👍 Supported devices

| Model | Reading ID-code | Writing ID-code | |:-----------------------------------------|:---------------:|:---------------:| | DS1990, DS1990A, DS1990R, TM1990A | ✔️ | | | RW1990, RW1990.1, RW1990v1, TM08, TM08v2 | ✔️ | ✔️ | | RW1990.2, RW1990v2 | ✔️ | ✔️ | | RW2004, TM2004 | ✔️ | ✔️ | | TM01, TM01C | ✔️ | ✔️ | | Many other iButton tags | ✔️ | |

<img src="https://vdwulp.github.io/iButtonTag/iButtonTag-TM1990A.png" alt="iButton tags model TM1990A" width=220 height=220><img src="https://vdwulp.github.io/iButtonTag/iButtonTag-RW1990.png" alt="iButton tag model RW1990" width=220 height=220><img src="https://vdwulp.github.io/iButtonTag/iButtonProbe-OneLed.png" alt="iButton probe flat model with indicator LED" width=220 height=220>

✈️ Installation

Using Arduino IDE Library Manager - Recommended!

1. Open Arduino IDE
2. Go to Tools > Manage Libraries...
3. Search for "iButtonTag"
4. Click Install
5. Click Install All to also install required OneWire library

If you don't see the Install All button mentioned in step 5, you have an older Arduino IDE (<1.8.10). Consider upgrading the IDE, or repeat steps 1 to 4 above to install OneWire library. In step 3 search for "OneWire".

Manual installation

1. Download the latest release ZIP file from iButtonTag releases
2. In Arduino IDE, go to Sketch > Include Library > Add .ZIP Library...
3. Select the downloaded ZIP file
4. Repeat steps above to install required OneWire library; in step 1 download ZIP file from OneWire releases

🚶 Basic usage

Hardware setup

• Connect data line of iButton probe to an Arduino digital pin, this is the 1-Wire data line.
• Connect a 2200 Ω to 4700 Ω pull-up resistor between the 1-Wire data line and Arduino 5V pin.
• Connect ground line of iButton probe to an Arduino ground (GND) pin.

Code example

#include <iButtonTag.h>                     // Include the library

#define PIN_PROBE 2                         // Data line connected to pin 2

iButtonTag ibutton( PIN_PROBE );            // Setup iButtonTag on the pin

void setup(void) {
  Serial.begin(9600);
}

void loop(void) {
  iButtonCode code;                         // Variable to store ID-code

  Serial.println( "Reading... " );
  int8_t status = ibutton.readCode( code ); // Try to read ID-code

  if ( status > 0 ) {                       // Code read successfully
    Serial.print( "iButton code read: " );
    ibutton.printCode( code );              // ID-code is in variable _code_
    Serial.println();
  }
}

More examples are available after installation in the Arduino IDE via File-menu > Examples > iButtonTag.

🏃 Advanced features

• Writing new identification code to (re)writable iButton tag models
• Reading multiple iButton probes on the same 1-Wire data line

🛠️ Hardware notes

iButton identification tags

• iButton tags are used for many purposes, including as key to lock of office, hotel sauna or cabinet, also to (de)activate alarm systems and log attendance/time.
• Many iButton tags have their identification code engraved on them in hexadecimal: in the center the reversed tag specific 6-byte code, above it on the right side 1-byte family code and on the left side 1-byte checksum. When read by this library the order is: family code - tag specific code - checksum.
• Official iButton identification tags all have a unique identification code that cannot be changed. However, this library supports writing a new code to multiple types of (re)writable compatible tags.
• DS1990 (not DS1990A or DS1990R) can't be used with multiple identification tags on a single data line and requires special handling. For details see comments on function readCode in reference documentation.

iButton probes

• iButton probes come in many forms, some have LED-indicator(s) with one or two colors, see some examples.
• No probe? No problem... see instructions in probe documentation.

Pull-up resistor

• The official recommendation is to use a 4700 Ω pull-up resistor between the 1-Wire data line and Arduino 5V pin when reading from an iButton tag.
• Writing a new code to (re)writable iButton tags may require more power for a successful and persistent result. To get more power to the tag, a 2200 Ω pull-up resistor between the 1-Wire data line and Arduino 5V pin has been tested to be a good value.

🔗 Quick links

• General information (this file)
• Reference documentation
• GitHub repository
• Download latest release

📓 Documentation

Articles

• What is an iButton Device?
• How to Power the Extended Features of 1-Wire Devices

Data sheets

• Book of iButton Standards
• DS1990A
• DS1990R

🙏 Thanks

• The creator(s) of the OneWire library iButtonTag depends on. It's a very solid implementation of the 1-Wire protocol. I learned a lot by studying the protocol documentation in combination with the source of this library.
• The creator(s) of the DallasTemperature library. When studying the 1-Wire protocol, working with the Dallas DS18B20 Temperature Sensor made everything more practical. In this period I also tried to contribute to this library.

🗒️ License

MIT License, full text available in LICENSE file.

Copyright (c) 2025 SA van der Wulp
