Ryu & Ryu Printf

This project contains routines to convert IEEE-754 floating-point numbers to decimal strings using shortest, fixed %f, and scientific %e formatting. The primary implementation is in C, and there is a port of the shortest conversion to Java. All algorithms have been published in peer-reviewed publications. At the time of this writing, these are the fastest known float-to-string conversion algorithms. The fixed, and scientific conversion routines are several times faster than the usual implementations of sprintf (we compared against glibc, Apple's libc, MSVC, and others).

Generating scientific and fixed output format for 16 and 32 bit IEEE floating point numbers can be implemented by converting to 64 bit, and then using the 64 bit routines. Note that there is no 128 bit implementation at this time.

When converting to shortest, DO NOT CAST; shortest conversion is based on the precision of the source type, and casting to a different type will not return the expected output. There are highly optimized 32 and 64 bit implementations as well as a generic 128 bit implementation that can handle any IEEE format up to 128 bits.

These are the supported conversion modes for the C implementation:

| IEEE Type | Supported Output Formats | | -------------------- | -------------------------------- | | 16 Bit (half) | Shortest (via ryu_generic_128.h) | | 32 Bit (float) | Shortest | | 64 Bit (double) | Shortest, Scientific, Fixed | | 80 Bit (long double) | Shortest (via ryu_generic_128.h) | | 128 Bit (__float128) | Shortest (via ryu_generic_128.h) |

The code is continuously tested on Ubuntu 18.04, MacOS High Sierra, and Windows Server version 1803.

All code outside of third_party/ is copyrighted by Ulf Adams and contributors, and may be used freely in accordance with the Apache 2.0 license. Alternatively, the files in the ryu/ directory may be used freely in accordance with the Boost 1.0 license.

All contributions are required to maintain these licenses.

Ryu

Ryu generates the shortest decimal representation of a floating point number that maintains round-trip safety. That is, a correct parser can recover the exact original number. For example, consider the binary 32-bit floating point number 00111110100110011001100110011010. The stored value is exactly 0.300000011920928955078125. However, this floating point number is also the closest number to the decimal number 0.3, so that is what Ryu outputs.

This problem of generating the shortest possible representation was originally posed by White and Steele [1], for which they described an algorithm called "Dragon". It was subsequently improved upon with algorithms that also had dragon-themed names. I followed in the same vein using the japanese word for dragon, Ryu. In general, all these algorithms should produce identical output given identical input, and this is checked when running the benchmark program.

The C implementation of Ryu is in the ryu/ directory. The Java implementations are RyuFloat and RyuDouble under src/main/java/. Both cover 32 and 64-bit floating point numbers.

In addition, there is an experimental C implementation that can handle inputs of any size up to 128-bit, albeit with lower performance than the highly optimized 32-bit and 64-bit implementations. Furthermore, there is an experimental low-level C API that returns the decimal floating-point representation as a struct, allowing clients to implement their own formatting. These are still subject to change.

Note: The Java implementation differs from the output of Double.toString [2] in some cases: sometimes the output is shorter (which is arguably more accurate) and sometimes the output may differ in the precise digits output (e.g., see https://github.com/ulfjack/ryu/issues/83).

Note: While the Java specification requires outputting at least 2 digits, other specifications, such as for JavaScript, always require the shortest output. We may change the Java implementation in the future to support both.

My PLDI'18 paper includes a complete correctness proof of the algorithm: https://dl.acm.org/citation.cfm?doid=3296979.3192369

Other implementations of Ryu:

| Language | Author | Link | |------------------|--------------------|-----------------------------------------------| | Scala | Andriy Plokhotnyuk | https://github.com/plokhotnyuk/jsoniter-scala | | Rust | David Tolnay | https://github.com/dtolnay/ryu | | Julia | Jacob Quinn | https://github.com/JuliaLang/julia/tree/master/base/ryu | | Factor | Alexander Iljin | https://github.com/AlexIljin/ryu | | Go | Caleb Spare | https://github.com/cespare/ryu | | C# | Dogwei | https://github.com/Dogwei/RyuCsharp | | C# | Shad Storhaug | https://github.com/NightOwl888/J2N | | D | Ilya Yaroshenko | https://github.com/libmir/mir-algorithm | | Scala | Denys Shabalin | https://github.com/scala-native/scala-native | | Erlang/BEAM | Thomas Depierre | https://github.com/erlang/otp/tree/master/erts/emulator/ryu | | Zig | Marc Tiehuis | https://github.com/tiehuis/zig-ryu | | Haskell | Lawrence Wu | https://github.com/haskell/bytestring |

Ryu Printf

Since Ryu generates the shortest decimal representation, it is not immediately suitable for use in languages that have printf-like facilities. In most implementations, printf provides three floating-point specific formatters, %f, %e, and %g:

• The %f format prints the full decimal part of the given floating point number, and then appends as many digits of the fractional part as specified using the precision parameter.

• The %e format prints the decimal number in scientific notation with as many digits after the initial digit as specified using the precision parameter.

• The %g format prints either %f or %e format, whichever is shorter.

Ryu Printf implements %f and %e formatting in a way that should be drop-in compatible with most implementations of printf, although it currently does not implement any formatting flags other than precision. The benchmark program verifies that the output matches exactly, and outputs a warning if not. Any unexpected output from the benchmark indicates a difference in output.

Note that old versions of MSVC ship with a printf implementation that has a confirmed bug: it does not always round the last digit correctly.

Note that msys cuts off the output after ~17 digits, and therefore generally differs from Ryu Printf output for precision values larger than 17.

Note that the output for NaN values can differ between implementations; we use ifdefs in an attempt to match platform output.

According to our benchmarks, Ryu Printf compares favorably with the following implementations of printf for precision parameters 1, 10, 100, and 1000:

| OS | Libc | Ryu Printf is faster by | |----------------------|-----------------------------|-------------------------| | Ubuntu 18.04 | libc6 2.27-3ubuntu1 | 15x | | Ubuntu 18.04 | musl 1.1.19-1 | 4x | | Windows 10 Home 1803 | MSVC 19.14.26429.4 | 9x | | Windows 10 Home 1803 | msys-runtime-devel 2.10.0-2 | between 8x and 20x | | macOS Mojave 10.14 | Apple Libc | 24x |

In addition, Ryu Printf has a more predictable performance profile. In theory, an implementation that performs particularly badly for some subset of numbers could be exploited as a denial-of-service attack vector.

My OOPSLA'2019 paper provides a correctness proof: https://dl.acm.org/citation.cfm?doid=3366395.3360595

Building, Testing, Running

We use the Bazel build system (https://bazel.build) 0.14 or later, although we recommend using the latest release. You also need to install Jdk 8 (or later) to build and run the Java code, and/or a C/C++ compiler (gcc or clang on Ubuntu, XCode on MacOS, or MSVC on Windows) to build the C/C++ code.

To build Ryu, run

$ bazel build //ryu

To build Ryu Printf, run

$ bazel build //ryu:ryu_printf

Big-Endian Architectures

The C implementations should work on big-endian architectures provided that the floating point type and the corresponding integer type use the same endianness.

There are no concerns around endianness for the Java implementation.

Building with a Custom Compiler

You can select a custom C++ compiler by setting the CC environment variable, e.g., use these steps to build with clang-4.0 on Ubuntu:

$ export CC=clang-4.0
$ bazel build //ryu

Building Ryu Printf against musl and msys requires installing the corresponding packages. We only tested against the musl Debian package that installs a gcc wrapper and is enabled by setting CC. However, building against msys requires manually adjustin
