PASGAL

PASGAL: Parallel And Scalable Graph Algorithm Library.

Prerequisite

• g++ or clang with C++17 features support (tested with g++ 13.2.1 and clang 14.0.6) on Linux machines.
• We use ParlayLib to support fork-join parallelism and some parallel primitives. It is provided as a submodule in our repository.

Algorithms

We include the following four algorithms in our repository. The source code can be found under src/.

• BFS: Breadth-First Search.
• SSSP: Single-Source Shortest Paths. The SSSP algorithms are from the paper [1].
• BCC: Biconnected Components. The BCC algorithm is from the paper [2].
• SCC: Strongly Connected Components. The SCC algorithm is from the paper [3].
• basic_analytics: For computing no of vertices, edges, min_degree, max_degree, zero_degree_count.

Compilation

A Makefile is provided in each subdirectory. For example, to compile BFS:

cd src/BFS
make

Running the code

Instructions on running the code will be provided when running the executables without any command line options. A sample output from BFS:

Usage: ./bfs [-i input_file] [-s] [-v]
Options:
-i, input file path
-s, symmetrized input graph
-v, verify result

Graph Formats

The graphs tested in our papers can be found at: https://pasgal-bs.cs.ucr.edu/. The application can auto-detect the format of the input graph based on the suffix of the filename. Here is a list of supported graph formats:

• .bin The binary graph format from GBBS. It uses the compressed sparse row (CSR) format and is organized as follows:
  • $n$ - number of vertices (64-bit variable)
  • $m$ - number of edges (64-bit variable)
  • sizes - sizes of this file in bytes, which is equal to $3\times8+(n+1)\times8+m\times4$ (64-bit variable)
  • offset[] - offset[ $i$ ] (inclusive) and offset[ $i+1$ ] (exclusive) represents the range of neighbors list of the $i$-th vertex in the edges array (64-bit array of length $n+1$)
  • edges[] - edges list (32-bit array of length $m$)
• .adj The adjacency graph format from Problem Based Benchmark suite.

Running Examples

The graphs used in the paper are available here. They are in binary format, with _sym indicating undirected graphs, while others are directed.

For demonstration, we will use:

• Directed graph: soc-LiveJournal1.bin
• Undirected graph: soc-LiveJournal1_sym.bin

Since these graphs are large, a stack overflow may occur. To prevent this, run:

ulimit -s unlimited

Running BFS

After compilation, three executables will be available in src/BFS:

• bfs: Runs our BFS algorithm from 5 random sources, repeating 6 times (ignoring the first warmup round).
• seq-bfs: Runs the standard sequential BFS in the same manner. A specific source can be set using -r source.
• bfs_test: Runs both our parallel BFS and the sequential BFS from 10 random sources, recording the average runtime in bfs.tsv and seq-bfs.tsv.

Run on an undirected graph:

./bfs -i path_to_graph/soc-LiveJournal1_sym.bin -s

Run on a directed graph

./bfs -i path_to_graph/soc-LiveJournal1.bin

Running BCC

After compilation, three executables will be available in src/BCC:

• fast-bcc: Our parallel BCC algorithm [2]
• hopcroft-tarjan: Standard sequential BCC algorithm [HT73].
• tarjan-vishkin: A theoretically-efficient parallel BCC baseline [TV85].

BCC is only defined for undirected graphs:

./fast-bcc -i path_to_graph/soc-LiveJournal1_sym.bin -s

Running SCC

After compilation, two executables will be avaible in src/SCC:

• scc: Our parallel SCC algorithm [3]
• tarjan: Standard sequential SCC algorithm.

SCC is only defined for directed graphs.

./scc -i path_to_graph/soc-LiveJournal1.bin

Running SSSP

The SSSP algorithm supports weighted graphs, which are stored in the adjacency graph format and available here

After compilation, two executables will be avaible in src/SSSP:

• sssp: Our parallel SSSP algorithm [1]
• dijkstra: Standard sequential SSSP algorithm.

./sssp -i path_to_graph/soc-LiveJournal1_wgh18.adj

Running basic_analytics

After compilation, single executable will be available in src/basic_analytics. Run the executable as shown below:

./basic_analytics -i path_to_graph/soc-LiveJournal1_wgh18.adj

References

Xiaojun Dong, Yan Gu, Yihan Sun, Letong Wang. Brief Announcement: PASGAL: Parallel And Scalable Graph Algorithm Library. In ACM Symposium on Parallelism in Algorithms and Architectures (SPAA), pp. 439-442, 2024.

Xiaojun Dong, Yan Gu, Yihan Sun, Letong Wang. PASGAL: Parallel And Scalable Graph Algorithm Library. arXiv preprint: 2404.17101, 2024.

If you use our code, please cite our paper:

@inproceedings{dong2024pasgal,
  title = {Brief Announcement: PASGAL: Parallel And Scalable Graph Algorithm Library},
  author = {Dong, Xiaojun and Gu, Yan and Sun, Yihan and Wang, Letong},
  booktitle = {ACM Symposium on Parallelism in Algorithms and Architectures (SPAA)},
  year = {2024},
}

<a id="1">[1]</a> Xiaojun Dong, Yan Gu, Yihan Sun, and Yunming Zhang. 2021. Efficient Stepping Algorithms and Implementations for Parallel Shortest Paths. In ACM Symposium on Parallelism in Algorithms and Architectures (SPAA). 184–197.

<a id="2">[2]</a> Xiaojun Dong, Letong Wang, Yan Gu, and Yihan Sun. 2023. Provably Fast and Space-Efficient Parallel Biconnectivity. In ACM Symposium on Principles and Practice of Parallel Programming (PPOPP). 52–65.

<a id="3">[3]</a> Letong Wang, Xiaojun Dong, Yan Gu, and Yihan Sun. 2023. Parallel Strong Connectivity Based on Faster Reachability. ACM SIGMOD International Conference on Management of Data (SIGMOD) 1, 2 (2023), 1–29.
