This prototype is no longer being developed!

This version has become an unmanagable mess of spaghetti code, so we have decided to start over with rust and webgpu <br> See the first rust prototype here

Bio-Spheres

A real-time 3D cellular simulation and visualization engine built with OpenGL and GPU compute shaders. Bio-Spheres simulates the behavior of biological cells in a 3D environment with physics, genetics, and interactive visualization.

🎯 Features

Core Simulation

GPU-Accelerated Physics: Real-time simulation of up to 100,000 cells using OpenGL compute shaders
Spatial Partitioning: Efficient 64³ grid system for collision detection and neighbor queries
Cell Lifecycle: Complete cell simulation including growth, division, death, and genetic inheritance
Genetic System: Genome-based behavior with multiple cellular modes and inheritance patterns
Unique ID System: Hierarchical cell identification with parent-child relationships

Visualization & Rendering

Level-of-Detail (LOD): Dynamic mesh complexity based on camera distance
Frustum Culling: GPU-accelerated visibility culling for performance
Interactive Gizmos: Visual indicators for cell orientation, adhesion, and ring structures
Wireframe Mode: Toggle between solid and wireframe rendering
Real-time Camera Control: Orbit, pan, and zoom with mouse and keyboard

User Interface

ImGui Integration: Real-time parameter adjustment and simulation control
Performance Monitoring: Live FPS, frame time, and GPU utilization metrics
Scene Management: Switch between preview and main simulation modes
Cell Selection: Click and drag individual cells for manual manipulation

Audio System

Real-time Synthesis: Procedural audio generation based on simulation state
Miniaudio Integration: Low-latency audio playback with 44.1kHz sample rate

🚀 Getting Started

Prerequisites

Windows 10 or later
Visual Studio 2022 with C++20 support
OpenGL 4.6 compatible graphics card
DirectX 11 or later

Installation

Clone the repository

git clone https://github.com/yourusername/bio-spheres.git
cd bio-spheres

Open the project
- Open Biospheres.sln in Visual Studio 2022
- Select your preferred configuration (Debug/Release) and platform (x64 recommended)
Build the project
- Press Ctrl+Shift+B or go to Build → Build Solution
- The executable will be generated in x64/Debug/ or x64/Release/
Run the application
- Press F5 to run with debugging or Ctrl+F5 to run without debugging
- The application will launch with a default simulation of 100,000 cells

Quick Start

Launch the application - You'll see a 3D view with spherical cells
Camera Controls:
- Left Mouse: Orbit camera around the simulation
- Right Mouse: Pan camera
- Mouse Wheel: Zoom in/out
- WASD: Move camera position
UI Controls:
- Performance Panel: Monitor FPS and system metrics
- Simulation Panel: Adjust physics parameters and cell behavior
- Rendering Panel: Toggle visualization options
Cell Interaction:
- Click: Select individual cells
- Drag: Move selected cells manually

🎮 Controls

Camera Controls

| Input | Action | |-------|--------| | Left Mouse + Drag | Orbit camera around center | | Right Mouse + Drag | Pan camera | | Mouse Wheel | Zoom in/out | | W/A/S/D | Move camera forward/left/backward/right | | Q/E | Move camera up/down | | R | Reset camera to default position |

UI Controls

| Panel | Function | |-------|----------| | Performance | Monitor FPS, frame time, cell count | | Simulation | Adjust physics timestep, cell limits | | Rendering | Toggle wireframe, gizmos, LOD | | Audio | Control synthesis parameters |

Cell Interaction

| Action | Description | |--------|-------------| | Left Click | Select cell at cursor position | | Left Click + Drag | Move selected cell | | Scroll Wheel | Adjust cell properties (when selected) |

🏗️ Architecture

Core Systems

Cell Manager (`src/simulation/cell/cell_manager.h`)

GPU-accelerated cell simulation using compute shaders
Spatial partitioning with 64³ grid system
Unique ID management for cell tracking
LOD and frustum culling for performance

Rendering Pipeline (`src/rendering/`)

OpenGL 4.6 with compute shader support
Instanced rendering for efficient cell display
Dynamic LOD system with distance-based mesh complexity
Real-time gizmo generation and rendering

Audio Engine (`src/audio/`)

Real-time procedural synthesis
Miniaudio integration for low-latency playback
Simulation-driven audio generation

UI System (`src/ui/`)

ImGui-based interface
Real-time parameter adjustment
Performance monitoring and debugging tools

GPU Compute Pipeline

Physics Compute → Update Compute → Internal Update → Spatial Grid → Rendering

Physics Compute: Position, velocity, and collision calculations
Update Compute: Cell lifecycle and genetic behavior
Internal Update: Signaling substances and internal state
Spatial Grid: Neighbor queries and spatial organization
Rendering: LOD calculation, frustum culling, and draw calls

📊 Performance

Target Specifications

Minimum: GTX 1060 / RX 580 (OpenGL 4.6)
Recommended: RTX 3060 / RX 6600 or better
Optimal: RTX 4070 / RX 7700 XT or better

Performance Metrics

100,000 cells: 60+ FPS on recommended hardware
GPU Memory: ~500MB for maximum cell count
CPU Usage: <5% (GPU-accelerated simulation)
Memory Usage: ~2GB total application memory

Optimization Features

GPU Compute Shaders: Parallel physics simulation
Spatial Partitioning: O(1) neighbor queries
Level-of-Detail: Distance-based mesh complexity
Frustum Culling: Only render visible cells
Instanced Rendering: Efficient batch drawing

🔧 Configuration

Key Parameters (`src/core/config.h`)

// Simulation Limits
constexpr int MAX_CELLS{100000};
constexpr int DEFAULT_CELL_COUNT{100000};
constexpr float DEFAULT_SPAWN_RADIUS{50.0f};

// World Configuration
constexpr float WORLD_SIZE{100.0f};
constexpr int GRID_RESOLUTION{64};
constexpr int MAX_CELLS_PER_GRID{32};

// Rendering
constexpr int INITIAL_WINDOW_WIDTH{800};
constexpr int INITIAL_WINDOW_HEIGHT{600};
constexpr int OPENGL_VERSION_MAJOR{4};
constexpr int OPENGL_VERSION_MINOR{6};

Runtime Configuration

Physics Timestep: Adjust simulation accuracy vs performance
Cell Limits: Control maximum cell count
LOD Distances: Fine-tune rendering performance
Audio Parameters: Modify synthesis behavior

🧬 Simulation Details

Cell Structure

Each cell contains:

Physics: Position, velocity, mass, orientation
Internal State: Age, toxins, nitrates, signaling substances
Genetics: Mode index, unique ID, parent-child relationships
Behavior: Growth, division, death, and interaction patterns

Genetic System

Genome Modes: Multiple behavioral states per cell
Inheritance: Parent-to-child genetic transfer
Mutation: Random genetic changes during division
Selection: Environmental pressure on survival

Spatial System

64³ Grid: Efficient spatial partitioning
Neighbor Queries: Fast proximity detection
Collision Detection: GPU-accelerated physics
Adhesion: Cell-to-cell interaction simulation

🛠️ Development

Project Structure

Bio-Spheres/
├── src/
│   ├── audio/          # Audio engine and synthesis
│   ├── core/           # Configuration and common utilities
│   ├── input/          # Input handling and camera controls
│   ├── rendering/      # OpenGL rendering pipeline
│   ├── simulation/     # Cell simulation and genetics
│   ├── ui/            # ImGui interface
│   └── utils/         # Utility functions and timing
├── shaders/           # GLSL compute and rendering shaders
├── third_party/       # External libraries (GLFW, GLM, ImGui)
└── docs/             # Documentation and guides

Building from Source

Ensure Visual Studio 2022 is installed with C++20 support
Open Biospheres.sln
Select x64 platform and Release configuration
Build solution (Ctrl+Shift+B)
Run the application (F5)

Debugging

Debug Configuration: Includes debug symbols and validation
Performance Monitoring: Built-in FPS and timing metrics
GPU Debugging: OpenGL error checking and validation
Cell Inspection: Real-time cell data viewing

🤝 Contributing

Development Guidelines

Code Style: Follow existing C++20 patterns
Performance: Maintain 60+ FPS target
Documentation: Update relevant documentation
Testing: Test on multiple GPU configurations

Areas for Contribution

New Cell Behaviors: Additional genetic modes and interactions
Visual Effects: Enhanced rendering and particle systems
Audio Features: More sophisticated synthesis algorithms
UI Improvements: Additional controls and visualization options
Performance: Optimization and profiling improvements

📝 License

This project is licensed under the MIT License - see the LICENSE file for details.
