DeepDiagram AI: Agentic AI Visualization Platform

DeepDiagram AI is an open-source, intelligent visualization platform that leverages Agentic AI and multi-agent orchestration to transform natural language and multimodal inputs into professional diagrams. Unlike traditional tools, DeepDiagram employs a LangGraph-powered architecture where specialized agents handle different visualization domains—from interactive mind maps to complex infographics.

Demo: http://deepd.cturing.cn/

DeepDiagram AI Demo

DeepDiagram AI Demo1

DeepDiagram AI Demo2

DeepDiagram AI Demo3

DeepDiagram AI Demo4

🚀 Core Features

🧠 Mind Map Agent

Powered by: mind-elixir
Capabilities: Generates 4-5 level deep, structured, interactive mind maps in Markdown format
Use Cases: Knowledge mapping, brainstorming, concept organization
Workflow: Supports real-time preview, editing, and export to PNG

Mind Map Agent Demo

🔀 Flowchart Agent

Powered by: React Flow
Capabilities: Creates business process flows with intelligent auto-layout and custom node styling
Use Cases: Business processes, logic flows, step-by-step procedures
Workflow: Interactive canvas with drag-and-drop editing and high-quality image export

Flowchart Agent Demo

📊 Data Chart Agent

Powered by: Apache ECharts 6.0
Capabilities: Visualizes data using bar charts, line graphs, pie charts, gauges, and more with modern animations
Use Cases: Data visualization, dashboards, trend analysis
Workflow: Analyzes data or descriptions to generate rich, interactive ECharts configurations

Data Chart Agent Demo

✏️ Draw.io Agent

Powered by: Draw.io (Atlas Theme)
Capabilities: Produces professional-grade cloud architecture and network topology diagrams
Use Cases: Cloud infrastructure, system architecture, technical blueprints
Workflow: Advanced canvas with auto-centering and sidebar concealment for a focused drawing experience

Draw.io Agent Demo

🧜 Mermaid Agent

Powered by: Mermaid.js 11.12 + react-zoom-pan-pinch
Capabilities: Generates text-driven diagrams including Sequence, Gantt, Timeline, State, Class, and ER diagrams
Use Cases: Technical documentation, software design, project planning
Workflow: Native interactive canvas with adaptive scaling, zoom/pan controls, and high-resolution SVG/PNG export

Mermaid Agent Demo

🎨 Infographic Agent

Powered by: AntV Infographic
Capabilities: Creates professional digital infographics, data posters, and visual summaries using declarative DSL
Use Cases: Data storytelling, visual summaries, creative presentations
Workflow: Two-phase intelligent pipeline:
1. Template Selection: LLM analyzes user intent and selects optimal template from 50+ options (chart, compare, hierarchy, list, relation, sequence)
2. Code Generation: Template-specific prompts with syntax rules generate precise DSL code

Infographic Agent Demo

✨ Advanced Features

🤖 Intelligent Router & XML Tag Output

Context-Aware Routing: Automatically routes requests to the optimal agent based on:
- Explicit mentions (e.g., @mindmap, @flow, @charts)
- LLM intent recognition with full agent capability descriptions
- Conversation context (prefers last active agent for continuity)
XML Tag Output: Each agent outputs <design_concept>...</design_concept><code>...</code> directly without tool calls, enabling cleaner parsing and multi-line content support
Multimodal Support: Upload whiteboards, sketches, or technical diagrams for digitization

💡 Design Concept Streaming

AI Reasoning Visibility: See the AI's design thinking and architectural decisions in real-time
Collapsible Panel: Yellow-themed card auto-expands during streaming, collapses when complete
Markdown Rendering: Design concepts support rich formatting with headers, lists, and emphasis

📜 Persistent History & Message Branching

Session Management: Maintain multiple chat sessions with automatic state restoration (including diagrams and process traces)
Message Branching: Retry assistant responses to explore different visualization paths; navigate between versions via built-in pagination
Version Control: Git-like branching system with turn_index and parent_id tracking
Robust Storage: PostgreSQL-backed persistence ensures reliability for complex technical traces and multimodal content

📄 Intelligent Document Analysis

Deep Content Understanding: Automatically parses uploaded documents (PDF, DOCX, XLSX, PPTX, TXT, MD) with:
- Concurrent chunking for large files
- LLM extraction of temporal data, key entities, and relationships
- Structured information retrieval
Persistent Memory: Analysis results are database-persisted, allowing AI to retain context across sessions
Time-Aware: All agents are aware of the current date/time for accurate timeline generation and scheduling

🎯 Real-Time Streaming & Process Trace

Dual-Stream SSE: Design concept and code stream independently for optimal UX
Execution Trace Visualization:
- Agent selection tracking
- Design concept with AI reasoning
- Streaming code generation with syntax highlighting
- Contextual "Render" and "Retry" actions
Error Handling: Clear visual feedback for rendering failures with instant retry capability

🎨 Modern UI/UX Enhancements

Resizable Layout: Flexibly adjust canvas and chat panel widths using a draggable separator
Responsive Design: All tables and components adapt to container size without layout breaks
Visual Loading States: Clear feedback during history loading, document parsing, and content generation
Accessibility: Keyboard shortcuts, hover tooltips, and status indicators

🏗 System Architecture

DeepDiagram AI uses a React 19 + FastAPI architecture, orchestrated by LangGraph. Each specialized agent directly outputs structured content with XML-style <design_concept> and <code> tags, streamed to the frontend via SSE (Server-Sent Events) for real-time preview.

graph TD
    Input[User Request: Text/Images/Documents] --> Router[Intelligent Router]
    Router -- Intent Classification --> Graph[LangGraph Orchestrator]

    subgraph Agents [Specialized Agents - XML Tag Output]
        AgentMM[MindMap Agent<br/>Markdown/Markmap]
        AgentFlow[Flowchart Agent<br/>React Flow JSON]
        AgentChart[Data Chart Agent<br/>ECharts Config]
        AgentDraw[Draw.io Agent<br/>mxGraph XML]
        AgentMermaid[Mermaid Agent<br/>Mermaid Syntax]
        AgentInfo[Infographic Agent<br/>AntV DSL]
        AgentGeneral[General Agent<br/>Plain Text]
    end

    Graph -->|Route by Intent| Agents

    subgraph Output [Streaming XML Tag Output]
        Agents -->|LLM Generation| Tags["&lt;design_concept&gt;...&lt;/design_concept&gt;<br/>&lt;code&gt;...&lt;/code&gt;"]
        Tags -->|Parse & Stream| Parser[StreamingTagParser]
    end

    Parser -->|design_concept events| DC[Design Concept Stream]
    Parser -->|code events| Code[Code Stream]

    DC -->|SSE| Frontend[React 19 Frontend]
    Code -->|SSE| Frontend

    Frontend -->|Real-time Render| Canvas[Interactive Canvas]
    Frontend -->|Process Trace| Trace[Execution Trace UI]

    style Input fill:#f9f,stroke:#333
    style Router fill:#bbf,stroke:#333
    style Tags fill:#bfb,stroke:#333
    style Canvas fill:#fdf,stroke:#333
    style DC fill:#ffc,stroke:#333

Architecture Highlights

No Tool Calls: Agents directly output XML tags <design_concept>...</design_concept><code>...</code> without intermediate tool invocations
Streaming Tag Parser: Real-time parsing of XML-style tags with state machine for robust multi-line content handling
Dual-Stream Output: design_concept (AI reasoning) and code (diagram content) stream independently
Design Concept UI: Yellow collapsible panel shows AI's design thinking before rendering

Key Components

Backend (Python)

dispatcher.py: Intent-based routing with explicit @agent tags and LLM fallback
graph.py: LangGraph state machine with Router → Agent → END flow
routes.py: SSE endpoint with StreamingTagParser for real-time XML tag parsing
file_service.py: Concurrent document parsing and LLM extraction
chat.py: Session and message CRUD with branching support
SQLModel ORM with async PostgreSQL driver

Frontend (React)

ChatPanel.tsx: Message history, SSE handling, execution trace rendering
CanvasPanel.tsx: Dynamic agent component loading and rendering
ExecutionTrace.tsx: Visual process trace with DesignConceptItem component
chatStore.ts: Zustand state management for messages, sessions, and versions
Agent-specific renderers: MindmapAgent, FlowAgent, MermaidAgent, etc.

🛠 Tech Stack

Frontend

Framework: React 19 (concurrent rendering), Vite, TypeScript
Styling: TailwindCSS 4.1.17
State Management: Zustand 5.0.9
Visualization:
- React Flow 11.11.4 (flowcharts)
- Mind-elixir 5.3.8 (mind maps)
- Mermaid 11.12.2 (technical diagrams)
- ECharts 6.0.0 (data charts)
- AntV Infographic 0.2.6 (infographics)
UI Components: Lucide React (icons), react-resizable-panels, react-zoom-pan-pinch
Markdown: React Markdown + remark-gfm

Backend

Framework: Python 3.13, FastAPI (async), Uvicorn (ASGI)
AI Orchestration: LangGraph 1.0.4, LangChain 1.1.3, langchain-openai
Database: Post
