J-Net: Multiresolution Neural Network for Semantic Segmentation

Multiresolution neural network for segmentic segmentation inspired by the U-net [1]. Since it consists of the expansive path only, it resembles the letter J (hence the name). The network is composed of several segments (one for each resolution level) such that the first one operates on the lowest resolution and the final one on the original image resolution. Each segment is a convolutional neural network (CNN) followed either by a deconvolution layer [2], which upsamples the output of the segment by factor two, or a final layer which outputs the segmentation. The input of the first segment is the image downsampled to the lowest resolution and the input of the other segments is the (upsampled) output of the previous segment concatenated with the image downsampled to the corresponding resolution level.

The figure shows an example of a J-net architecture. It consists of three segments, each being a CNN with 3×3 convolution filters and leaky ReLU activations. In order to maintain the spatial dimensions of the input throughout the segment the convolutions are preceded with a padding layer, which extends the tensor by reflecting the boundary pixels. The convolutions are furthermore followed by the batch normalization. The lowest resolution segment (128×128 px) has 16 convolution layers with 64 channels, the following segment (256×256 px) has 2 layers with 72 channels and the final full resolution segment (512×512 px) has 2 layers with 80 channels. The last layer has two output channels - one for binary segmentation (sigmoid activations) and the other predicts for each pixel its (truncated) distance to the nearest cell boundary (ReLU activation). In total (including the deconvolution and final layers) the network has 23 layers.

Dependencies

The code is known to work with

• Python 3.5, 3.6
• numpy 1.13, 1.14
• PyTorch 0.2.0, 0.3.1

Other versions may work too (and probably will) but they were not tested.

Example

This example demonstrates the J-net on segmentation of images from the DIC-C2DH-HeLa from the Cell Tracking Challenge [3]. The structure of the network was the same as described above. Since there are only 17 annotated images, data augmentation was used extensively when training the network (random flips and elastic transforms). The truncation threshold for the boundary-distance was set to 6 pixels. The optimizer was Adam, the initial learning rate was 0.00003 (decreased my multiplicative factor 0.75 if the training loss did not decrease for 30 epochs) and the training was stopped after 1850 epochs. The batch size was 8 and to make the size of the training set was artificially increased by replicating each training image 16 times (note that due to random augmentation the network never see the same image multiple times). The loss was sum of the BCE loss of the segmentation output and the MSE loss of the boundary-distance layer. The full command used to start the learning was as follows:

python3 main.py --cuda --images_idx '{"01":["002","005","021","031","033","034","039","054"],"02":["006","007","014","027","034","038","042","061","067"]}' --load_dataset_to_ram 1 --num_workers -1 --dataset_len_multiplier 16 --batch_size 8 --resolution_levels "[-2,-1,0]" --aug_rotation_flip --aug_elastic_params "[(50,5,5),(-1,-1,1)]" --structure "[[16,64,3],[2,8,3],[2,8,3]]" --dt_bound ${DT_BOUND} --validation_percentage 0.17 --learning_rate 0.00003 --mode train --dataset_root "/path/to/DIC-C2DH-HeLa_training" --output_dir results/DIC-C2DH-HeLa6

This command needs about 14 GB of GPU memory and one learning epoch takes about 30 seconds. Most of the time is spent on elastic transforms since they have to be done on the original resolution.

Segmentation results for all images in the challenge sequences can be obtained by

python3 main.py --cuda --resolution_levels '[-2,-1,0]' --dt_bound 6 --images_idx '{"01":[],"02":[]}' --mode vis --dataset_root /path/to/DIC-C2DH-HeLa_test --model_file results/DIC-C2DH-HeLa6/model_best_train_train --output_dir results/DIC-C2DH-HeLa6

One image takes about 0.12 seconds.

Results

Segmentation results on a training image from the DIC-C2DH-HeLa dataset (image 038 from sequence 02, same as in the U-net paper). From left to right: original image, segmentation, truncated distance to the cell boundary. The upper row are the images generated by the network and the lower row is the ground truth:

Segmentation results on an image from a challenge sequence (image 024 from sequence 01, no image from the challenge sequence was used during the training). From left to right: original image, segmentation, truncated distance to the cell boundary:

Toy Example

The previous example needs a GPU and substantial amount of memory. If you do not have proper HW, it is more convenient to experiment with smaller network, less images, etc. Directory toyexample contains scripts for training, evaluation and visualization and furthermore a subset of the DIC-C2DH-HeLa dataset. The network has two segments with three and two layers respectively, 16 and 24 channels, batch size is decreased to 2 and the training finishes after 100 epochs. All scripts run on CPU and do not need more than 1.5 GB RAM. Do not expect good results though, DIC-C2DH-HeLa is quite difficult dataset.

Input arguments

Required arguments are typed in bold face.

Main arguments

• --batch_size
  Size of the batch. Default value is 1.

• --dataset_len_multiplier
  Determines how many times is every training image replicated. Image replication allows to use bigger batch size and makes the training more stable. Default value is 1 (no replication)

• --dt_bound
  Truncation threshold for the boundary-distance output. Default value is 9.

• --dataset_root
  Directory with the Cell Tracking Challenge dataset (it contains subdirectories 01, 02 and optionally 01_GT and 02_GT).

• --images_idx
  Dictionary of lists of three digit ids of the input images from the Cell Tracking Challenge. The keys of the dictionary are the sequence numbers (including the leading zero). For example '{"01":["002","005","021"]'} means images 002, 005 and 021 from sequence 01 and '{"01":["002","005","021"],"02":["006","007"]}' means images 002, 005 and 021 from sequence 01 and images 006 and 007 from sequence 02. The images ids must be specified explicitely in train and eval mode. In vis mode the list of ids might be empty, e.g. '{"01":[]}', in which case the script takes all the images from the sequence(s).

• --learning_rate
  Learning rate. Default value is 0.0001.

• --load_dataset_to_ram
  If 1, the script preloads training images to RAM instead of loading them from HDD on demand. This saves some time when the training set is small and the images are replicated. Default value is 0.

• --mode
  Mode of the script. Possible values are "train", "eval" and "vis". The train mode is used for parameter learning, the eval mode is used for calculating the loss and accuracies for input images and the vis mode is used for visualization (similar to eval mode, but does not need ground truth for the input images). Default value is "train".

• --model_file
  File name of the model loaded in the eval or vis mode. Default value is ''.

• --num_epochs
  Number of training epochs. Default value is 5000.

• --output_dir
  Output directory, where the script saves the learned models (train mode) and segmentation results (vis, eval). If the directory does not exist, the script tries to create it.

• --resolution_levels
  List of resolution levels. Every level is a negative integer (or 0), such that the corresponding input is downscaled by factor 2^-lvl. For example 0 is the original resolution, for -1 the image is downscaled by factor 2, -2 is downscaled by factor 4 etc. The resolution levels must be consecutive numbers in ascending order. Last level can be smaller than zero (this is useful mainly for debugging). For example "[-3,-2,-1]" means, that the input to the initial segment is downscaled by factor 8 and the output of the network is half the size of the input images.

• --save_model_frequency
  Save model every save_model_frequency-th epoch. -1 means never. Default value is 200.

• --structure
  Structure of the network in the format "[[numof_layers1,numof_channels1,rf_size1],[numof_layers2,additional_numof_channels2,rf_size2],[numof_layers3,additional_numof_channels3,rf_size3],...]", where numof_layers is the number of convolution layers, numof_channels is the number of channels and rf_size is the size of the convolution filters in pixels. Number of channels is additive, i.e., number of channels in the second segment is given by numof_channels1+additional_numof_channels2. This argument is required in the train mode.

• --validation_percentage
  Percentage (number between 0 and 1) of the available training images used for validation during training. Default value is 0 (no validation is done).

Data augmentation

• --aug_elastic_params
  List of parameters for elastic transforms: [[alpha1, sigma1, weight1], [alpha2, sigma2, weight2],...], where alpha and sigma are parameters of the elastic transform and weight is the unnormalized probability of this combination. Parameter alpha is related to the scale of the transform and sigma to its smoothness (see
