Introduction

triSYCL_ is a research project to experiment with the specification of the SYCL_ standard and to give feedback to the Khronos_ Group SYCL_committee and also to the ISO C++_ committee.

More recently, this project has been used to experiment with high-level C++ programming for AMD_ AIE CGRA inspired by some SYCL concepts, as explained in ACAP++ & AIE++: C++ extensions for AMD Versal AIE CGRA architecture_.

Because of lack of resources this SYCL implementation is very incomplete and should not be used by a normal end-user. Fortunately there are now many other implementations of SYCL_ available, including some strong implementations like DPC++_ or hipSYCL_ that can be used on various targets.

This implementation is mainly based on C++23 features backed with OpenMP_ or TBB_ for parallel execution on the CPU, with Boost.Compute_ for the non single-source OpenCL_ interoperability layer and with an experimental LLVM_/Clang_ version for the device compiler (from 2017-2018 which is now obsolete) providing full single-source SYCL_ experience, typically targeting a SPIR_ device. Since in SYCL_ there is a host fall-back, this CPU implementation can be seen as an implementation of this fall-back too.

Since around 2018 Intel has put a lot of effort in their own oneAPI DPC++_ SYCL_ project to up-stream SYCL_ into LLVM_/Clang_, there is another project about merging the oneAPI DPC++_ SYCL_ implementation with triSYCL_ at https://github.com/triSYCL/sycl to give a greater user experience for AMD_ FPGA instead of using our obsolete experimental clunky device compiler. But this is still very experimental because the AMD_ tool-chain is based on old incompatible versions of LLVM_/Clang_ and nothing of these is supported by the AMD_ product teams.

triSYCL_ has been used to experiment and provide feedback for SYCL_ 1.2, 1.2.1, 2.2, 2020 and even the OpenCL_ C++ 1.0 kernel language from OpenCL_ 2.2.

This is provided as is, without any warranty, with the same license as LLVM_/Clang_.

Technical lead: Ronan at keryell point FR. Developments started first at AMD_, then was mainly funded by Xilinx_ and now again by AMD_ since Xilinx_ has been acquired by AMD_ in 2022.

It is possible to have a paid internship around triSYCL, if you have some skills related to this project. Contact the technical lead about this. AMD_ is also hiring in this area... :-)

SYCL

SYCL_ is a single-source modern C++-based DSEL_ (Domain Specific Embedded Language) and open standard from Khronos_ aimed at facilitating the programming of heterogeneous accelerators by leveraging existing concepts inspired by OpenCL_, CUDA_, C++AMP, OpenMP...

A typical kernel with its launch looks like this pure modern C++ code::

queue {}.submit([&](handler &h) { auto accA = bufA.get_accessaccess::mode::read(h); auto accB = bufB.get_accessaccess::mode::write(h); h.parallel_for<class myKernel>(myRange, [=](item i) { accA[i] = accB[i] + 1; }); });

Look for example at https://github.com/triSYCL/triSYCL/blob/master/tests/examples/demo_parallel_matrix_add.cpp for a complete example.

SYCL_ is developed inside the Khronos_ SYCL_ committee and thus, for more information on SYCL_, look at https://www.khronos.org/sycl

Note that even if the concepts behind SYCL_ are inspired by OpenCL_ concepts, the SYCL_ programming model is a very general asynchronous task graph model for heterogeneous computing targeting various frameworks and API and has no relation with OpenCL_ itself, except when using the OpenCL_ API interoperability mode, like any other target.

For the SYCL_ ecosystem, look at https://sycl.tech

ACAP++ & AIE++: C++ extensions for AMD Versal AIE CGRA architecture

Most of our current efforts are focused on extensions, such as targeting AMD_ FPGA and Versal ACAP AIE CGRA, providing a way to program CPU, GPU, FPGA and CGRA at the same time in a single-source C++ program.

This project is a work-in-progress and currently we target partially only the first generation of devices, AIE/AIE1, while current models of AMD_ RyzenAI such as the Ryzen 9 7940HS has an AIE-ML/AIE2 as the XDNA/NPU/IPU.

• The first generation programming model, ACAP++ was based on C++17/C++20 constructs.

  See https://github.com/triSYCL/sycl/blob/sycl/unified/master/sycl/test/acap/test_aie_mandelbrot.cpp and around, <tests/acap>_ and other directories starting with acap for some code samples running in pure C++ library CPU emulation with this project.

  Look at <doc/acap.rst>_ to know more about how to install/use the ACAP++ environment.

  The runtime for CPU emulation and AIE device is found in <include/triSYCL/vendor/Xilinx>_ which requires also a special compiler provided by https://github.com/triSYCL/sycl to run on VCK190 boards.

• The second generation programming model, AIE++ is based on C++23/C++26 constructs, allowing an even terser syntax.

  See around <https://github.com/triSYCL/sycl/blob/sycl/unified/master/sycl/test/aie/mandelbrot.cpp>_ for some examples.

  The runtime for CPU emulation and AIE device support is found in <include/aie>_ and the compiler for device support is https://github.com/triSYCL/sycl

Other open-source projects related to AIE which are interesting to program AIE:

• https://riallto.ai

• https://github.com/Xilinx/mlir-aie

• https://github.com/Xilinx/mlir-air

• https://github.com/nod-ai/iree-amd-aie

Some documentation about AMD AIE CGRA:

• AIE aka AIE1

  • Versal Adaptive SoC AI Engine Architecture Manual https://docs.xilinx.com/r/en-US/am009-versal-ai-engine/Overview

  • Versal Adaptive SoC Technical Reference Manual https://docs.xilinx.com/r/en-US/am011-versal-acap-trm/Introduction

  • AIE/AIE1 C++ API https://www.xilinx.com/htmldocs/xilinx2024_1/aiengine_api/aie_api/doc

• AIE-ML aka AIE2

  • AIE2/AIE-ML architecture https://docs.xilinx.com/r/en-US/am020-versal-aie-ml/Overview

  • AIE2/AIE-ML C++ API https://www.xilinx.com/htmldocs/xilinx2024_1/aiengine_ml_intrinsics/intrinsics

Documentation

Some reasons to use SYCL

Please see `about SYCL <doc/about-sycl.rst>`_ to have some context, a
list of presentations, some related projects.


Installation & testing
~~~~~~~~~~~~~~~~~~~~~~

SYCL_ is a template library, so no real installation is required.

There are some examples you can build however.

See `Testing <doc/testing.rst>`_.


Architecture of triSYCL runtime and compiler

Architecture of triSYCL runtime and compiler <doc/architecture.rst>_ describes the code base with some high-level diagrams but also how it was possible to compile and use the obsolete device compiler on some AMD_ FPGA for example. Now look at https://github.com/triSYCL/sycl instead.

CMake infrastructure

Some details about CMake configuration and organization can be found
in `CMake <doc/cmake.rst>`_.


Pre-processor macros used in triSYCL

Yes, there are some macros used in triSYCL! Look at Pre-processor macros used in triSYCL <doc/macros.rst>_ to discover some of them.

Environment variables used in triSYCL

See `Environment variables with triSYCL <doc/environment.rst>`_.


Possible futures
~~~~~~~~~~~~~~~~

See `Possible futures <doc/possible-futures.rst>`_.


triSYCL code documentation
~~~~~~~~~~~~~~~~~~~~~~~~~~

The documentation of the triSYCL_ implementation itself can be found
in https://trisycl.github.io/triSYCL/Doxygen/triSYCL/html and
https://trisycl.github.io/triSYCL/Doxygen/triSYCL/triSYCL-implementation-refman.pdf


News
----

- 2023/06/09: merge the 5-year old branch experimenting with ACAP++
  SYCL CPU model extensions for AMD_ Versal ACAP AIE1 CGRA like the
  XCVC1902 used in VCK190 or VCK5000 boards.

- 2018/03/12: the long-going device compiler branch has been merged in
  to provide experimental support for SPIR-df friendly devices, such
  as PoCL_ or Xilinx_ FPGA. This is only for the brave for now.

- 2018/02/01: there is now some documentation about the architecture of
  triSYCL on GPU and accelerators with its device compiler based on
  Clang_/LLVM_ in `<doc/architecture.rst>`_. While this is wildly
  experimental, there is a growing interest around it and it is
  always useful to get started as a contributor.

- 2018/01/05: there are some internship openings at Xilinx_ to work on
  triSYCL for FPGA
  https://xilinx.referrals.selectminds.com/jobs/compiler-engineer-intern-on-sycl-for-fpga-4685
  and more generally Xilinx_ is hiring in compilation, runtime, C++,
  SYCL_, OpenCL_, machine-learning...

- 2017/12/06: the brand-new SYCL 1.2.1 specification is out and
  triSYCL starts moving to it

- 2017/11/17: the presentations and videos from `SC17
  <https://sc17.supercomputing.org>`_ on SYCL and triSYCL are now
  online https://www.khronos.org/news/events/supercomputing-2017

- 2017/09/19: there is a prototype of device compiler based on
  Clang_/LLVM_ generating SPIR 2.0 "de facto" (SPIR-df) and working at least
  with PoCL_ and Xilinx_ SDx `xocc` for FPGA.

- 2017/03/03: triSYCL can use CMake & ``ctest`` and works on Windows 10 with
  Visual Studio 2017. It works also with Ubuntu WSL on Windows. :-)
  `More info <doc/cmake.rst>`_

- 2017/01/12: Add test case using the Xilinx_ compiler for FPGA

- 2016/11/18: If you missed the free SYCL_ T-shirt on the Kh
