Bknix

Deprecated

This repo is deprecated. The code is migrated to https://github.com/civicrm/civicrm-buildkit/tree/master/nix

bknix: Build/test environments for civicrm-buildkit

bknix is a highly opinionated environment for developing in PHP/JS -- esp for developing patches/add-ons for CiviCRM.

For discussion of strengths and weaknesses, see Critical comparison.

Profiles

A profile is list of packages (e.g. PHP 7.0 + MySQL 5.7 + Redis 4.0 + NodeJS 6.14). bknix includes a few profiles designed around the CiviCRM system-requirements:

• dfl: An in-between set of packages. This is a good default for middle-of-the-road testing/development.
• min: An older set of packages based on minimum system requirements.
• max: A newer set of packages based on maximum system requirements.
• old: An older set of packages for working with older versions of Civi (eg ESR versions and unsupported versions).
• edge: A newer set of packages that exceeds our current official support; a proposal for the next max.

Launchers

Given that you have several pieces of software (e.g. PHP + MySQL + Redis), the launcher or process manager is responsible for starting and stopping processes. bknix works with a few launchers:

• loco run: Loco runs local processes in the foreground. It can be configured by editing the YAML file (loco.yml), by setting environment variables (HTTPD_PORT et al), and/or by editing the configuration templates.
• bknix run (legacy/deprecated): The original, built-in launch script. This also runs local processes in the foreground. However, compared to loco, the configuration is quirkier and harder to adjust. (Ex: You have to reinstall after making a configuration change. Ex: It launches everything except mysqld.)
• systemd: This is a common process manager on Linux hosts. There are templates for using bknix run as a systemd unit. (These templates should be reworked. This is the main reason why bknix run still exists.)

Usage

For day-to-day usage, one must first launch the services (mysqld, php-fpm, etc). For example:

me@localhost:~$ cd bknix
me@localhost:~/bknix$ nix-shell -A min
[nix-shell:~/bknix]$ loco run
...
======================[ Startup Summary ]======================
[VOLUME] Loco data volume is a ram disk "/Users/myuser/bknix/.loco/var".
[redis] Redis is running on "127.0.0.1:6380".
[php-fpm] PHP-FPM is running on "127.0.0.1:9009"
[mailcatcher] Mailcatcher is running on "smtp://127.0.0.1:1025" and "http://127.0.0.1:1080"
[apache-vdr] Apache HTTPD is running at "http://127.0.0.1:8001" with content from "/Users/myuser/bknix/build".
[mysql] MySQL is running on "127.0.0.1:3307". The default credentials are user="root" and password="".
[buildkit] Buildkit (/Users/myuser/bknix/civicrm-buildkit) is configured to use these services. It produces builds in "/Users/myuser/bknix/build".

Services have been started. To shutdown, press Ctrl-C.
===============================================================

In this example, note that:

• We chose the profile min. This determines the specific software and versions that will be available.
• We opened a suitable shell with cd bknix and nix-shell -A min.
• We started the processes with loco run.
• The services are running in the foreground -- additional errors and log messages will be displayed on this console.

After launching the services, we can open another shell and do more development tasks -- such as building a test site:

me@localhost:~$ cd bknix
me@localhost:~/bknix$ nix-shell -A min
[nix-shell:~/bknix]$ civibuild create dmaster --civi-ver 5.8

Choose your own adventure

The example above used nix-shell and loco run. This is good for experimenting with bknix in the CLI. However, if you're using an IDE or continuous-testing server, then other approaches may work better. For a more complete tutorial, choose from below:

<table border="0"> <thead> <tr> <th>Goal</th> <th>Documentation</th> </tr> </thead> <tbody> <tr> <td> <ul> <li>Try bknix to see what it does</li> <li>Develop extensions or patches for Civi in a pure CLI environment</li> <li>Develop patches for <code>bknix.git</code></li> </ul> </td> <td> <ul> <li><a href="doc/requirements.md">System requirements</a></li> <li><a href="doc/nix-shell.md">Use a profile in a temporary subshell (<code>nix-shell</code>)</a></li> <li><a href="doc/usage-loco.md">Work with services and sites</a></li> </ul> </td> </tr> <tr> <td> <ul> <li>Develop extensions or patches for Civi in an IDE</li> </ul> </td> <td> <ul> <li><a href="doc/requirements.md">System requirements</a></li> <li><a href="doc/install-developer.md">Install all profiles for use by a single developer (<code>install-developer.sh</code>)</a></li> <li><a href="doc/usage-loco.md">Work with services and sites</a></li> </ul> </td> </tr> <tr> <td> <ul> <li>Run frequent tests in a mix of environments (continuous-integration)</li> </ul> </td> <td> <ul> <li><a href="doc/requirements.md">System requirements</a></li> <li><a href="doc/install-ci.md">Install all profiles and system services for concurrent usage (<code>install-ci.sh</code>)</a></li> </ul> </td> </tr> </tbody> </table>

Ports

With nix-shell or install-developer.sh, it is typical to only launch one "stack" of services. The services run on the following ports:

| Service | Typical Port | |-------------|--------------| | Apache HTTP | 8001 | | Memcached | 12221 | | MySQL | 3307 | | PHP FPM | 9009 | | PHP Xdebug | 9000 | | Redis | 6380 | | Mailcatcher (SMTP) (loco-only) | 1025 | | Mailcatcher (HTTP) (loco-only) | 1080 |

With install-ci.sh, the services use a wide range of ports.

<!-- FIXME: Document use of HTTPD_PORT, MYSQLD_PORT, etc --> <!-- FIXME: rewrite this for master-loco branch * A "build" is a collection of PHP/JS/CSS/etc source-code projects, with a database and an HTTP virtual host. You can edit/commit directly in the source-tree. * All builds are stored in the `build` folder. * All builds are given the URL `http://<name>.bknix:8001`. (Changeable) * All hostnames are registered in `/etc/hosts` using `sudo`. (Changeable) * All services run as the current, logged-in user. This means that files require no special permissions. * MySQL launches on-demand with all-ram-disk-based storage. Launching is triggered on-demand (`civibuild create ...`) or by calling `amp mysql:start` * PHP enables `xdebug`, which connects to a debugger UI on port 9000. (Changeable) -->

Some of these policies/opinions can be changed, as described below ("Extended installation")

TODO/Issues

• Sort out php-imap
• Make it easier to switch between php56, php70, php71. (Currently, you need to search/replace in default.nix.)
• Instead of putting most code in ./civicrm-buildkit, put it in $out. (Preferrably... without neutering git cache.)
• mysqld is spawned in the background via amp (b/c that has the automated ramdisk handling). However, it'd be conceptually cleaner to launch mysqld in the foreground via loco run.

Tips

(Stale: These tips should be rewritten to match the new "Quick Start" approach)

• To run Civi unit tests with xdebug in PHPStorm...
  • Lookup and register the PHP interpreter.
    • In CLI, run nix-shell and which php.
    • In PHPStorm, open "Preferences" and find list of PHP interpreters. Register this one.
  • Lookup and register the PATH.
    • In CLI, run nix-shell and echo $PATH.
    • In PHPStorm, open "Run => Edit Configurations". For the default PHPUnit, add an environment variable PATH with the given value.
    • If there are active PHPUnit configurations, update them or delete them (so they can be regenerated on-demand).
  • In the future -- whenever you upgrade the PHP runtime -- you may need to update these settings.
• If you don't already have git on your system, patch default.nix and add it to the list of buildInputs. However, if you already have it, then leave the default. (This would prevent potential concerns about different programs managing the same .git folders.)
• To open a MySQL command prompt with admin credentials, run amp sql -a.
• If you're doing development on the bknix service configuration, use loco clean or loco run -f (<s><code>bknix purge</code></s>) to produce a clean folder (without any data or config).
• When you shutdown, the mysql ramdisk remains in memory. To remove or reset it, unmount it with umount (in Linux) or Disk Utility (in OS X).

Updates

(Stale: These update steps should be rewritten to match the new "Quick Start" approach)

There are a few levels of updates. They run a spectrum from regular (daily) to irregular (once every months).

• (Most frequent; perhaps every day) Update the CiviCRM source: See CiviCRM Developer Guide: civibuild
• (Mid-level; perhaps every couple weeks) Update buildkit's CLI tools: Run cd civicrm-buildkit && git pull && civi-download-tools.
• (Least frequent; perhaps every couple months) Update the full bknix stack (mysqld/httpd/etc): This takes a few steps.
  • If you haven't already, shutdown any active services (Ctrl-C in the background terminal)
  • Exit any active nix-shell environments.
  • In t
