audion

An audio visualization and processing framework for WPF

Audion is powered by the awesome CSCore .NET Audio Library

Included in Audion (so far):

• Waveform
• Timeline
• Spectrum Analyzer
• Intuitive wrapper for managing an audio/video file

Future Road Map

• Equalizer
• Dynamic Waveform
• Time Clock (Counters)
• and more tba...

Source

The Source classes in audion makes it simple to load media and start playing with it. Every visualization simply subscribes to a Source. There are two versions, OutputSource to play media out of a device and InputSource to record media from a device. It is common to have one Source instance powering multiple different visualizations. Here is a simple example of loading a media file and playing it.

var output = new OutputSource();

// Open a file dialog to choose a media file
OpenFileDialog openFileDialog = new OpenFileDialog
{
    Filter = Audion.Source.SupportedFiles
};

// Load the media file into the source
if (openFileDialog.ShowDialog() == true)
{
    output.Load(openFileDialog.FileName);
}

output.Play();

Waveform

XAML

<audion:Waveform Name="waveform"
                 Resolution="2048"
                 LeftBrush="LightBlue"
                 LeftStroke="Transparent"
                 LeftStrokeThickness="0"
                 CenterLineBrush="White"/>

Code

var output = new OutputSource();
waveform.Source = output;

Timeline

XAML

<audion:Timeline Name="timeline"
                 FontSize="12"
                 ProgressBrush="#9900C3FF"
                 Position="{Binding TrackPosition}"
                 TickBrush="Silver"
                 TimeBrush="Silver"
                 ProgressLineBrush="White"
                 ProgressBrush="#772200EE"/>

Code

var output = new OutputSouce();
timeline.Source = output;

Spectrum Analyzer

XAML

<audion:SpectrumAnalyzer Name="spectrum"
                         SpectrumScalingStrategy="Decibel"
                         FrequencyBarCount="100"
                         FrequencyBarSpacing="2"
                         FrequencyBarBrush="{StaticResource BarBrush}" />

Code

var output = new OutputSource();
spectrum.Source = output;

Sample Application

(This is a work in progress)
