TexText - A TeX / typst extension for Inkscape

TexText is a Python plugin for the vector graphics editor Inkscape <http://www.inkscape.org/>__ providing the possibility to add and re-edit LaTeX and typst <https://typst.app/>__ generated SVG elements to your drawing (a installed LaTeX and/or typst distribution is required).

.. figure:: docs/source/images/textext-with-inkscape.png :alt: TexText dialog with Inkscape

Key features

• Windows/ Linux/ MacOS support
• LaTeX/ typst generated SVG elements can be re-edited later
• Multi-line editor with syntax highlighting (Read more... <usage-dialog-overview_>_)
• Compilation with PdfLaTeX, XeLaTeX, LuaLaTex or typst (Read more... <usage-tex-compilers_>_)
• Interoperable scaling in TexText and Inkscape (Read more... <usage-scaling_>_)
• Font size match with Inkscape text (Read more... <usage-font_>_)
• Customizable TeX preamble for e.g. additional packages, parskip, parindent, etc. (Read more... <usage-preamble-file_>_)
• Colorization via TeX/ typst commands/ Inkscape is kept after re-editing (Read more... <usage-colorization_>_)
• Alignment anchor of the produced output (Read more... <usage-alignment_>_)
• Preview images (Read more... <usage-preview_>_)
• Compatibility with TexText down to version 0.4.x

Download

Download of the most recent version (and older ones): https://github.com/textext/textext/releases

Compatibility chart:

+---------------------+---------------------------------------------------------------------+ | Inkscape | TexText | +=====================+=====================================================================+ | >= 1.4.3 | >=1.13.0 <https://github.com/textext/textext/releases>_ | +---------------------+---------------------------------------------------------------------+ | 1.4.0 - 1.4.2 | 1.12.0 <https://github.com/textext/textext/tag/1.12.0>_ | +---------------------+---------------------------------------------------------------------+ | 1.3.x | 1.10.2 <https://github.com/textext/textext/releases/tag/1.10.2>_ | +---------------------+---------------------------------------------------------------------+ | 1.2.x, 1.1.x, 1.0.x | 1.8.2 <https://github.com/textext/textext/releases/tag/1.8.2>_ | +---------------------+---------------------------------------------------------------------+ | 0.92.x | 0.11 <https://github.com/textext/textext/releases/tag/0.11.0>_ | +---------------------+---------------------------------------------------------------------+

Documentation

Documentation hosted at https://textext.github.io/textext. It contains installation <installation-toc_>_ and usage <usage-toc_>_ instructions.

History

This repository continues the development of the plugin which took place at https://bitbucket.org/pitgarbe/textext until January 2018. Originally, TexText had been developed by Pauli Virtanen <http://www.iki.fi/pav/software/textext/>__ based on the plugin InkLaTeX written by Toru Araki.
