Taskflow <img align="right" width="10%" src="images/taskflow_logo.png">

<!--[](https://travis-ci.com/taskflow/taskflow)-->

[][documentation] [][TPDS22]

Taskflow helps you quickly write task-parallel programs using modern C++

Why Taskflow?

Taskflow is faster, more expressive, and easier to integrate than many existing task programming frameworks when handling complex parallel workloads.

Taskflow lets you quickly implement task decomposition strategies that incorporate both regular and irregular compute patterns, together with an efficient work-stealing scheduler to optimize your multithreaded performance.

| Static Tasking | Subflow Tasking | | :------------: | :-------------: | | | <img align="right" src="images/dynamic_graph.svg" width="100%"> |

Taskflow supports conditional tasking for you to make rapid control-flow decisions across dependent tasks to implement cycles and conditions that were otherwise difficult to do with existing tools.

| Conditional Tasking | | :-----------------: | | |

Taskflow is composable. You can create large parallel graphs through composition of modular and reusable blocks that are easier to optimize at an individual scope.

| Taskflow Composition | | :---------------: | ||

Taskflow supports heterogeneous tasking for you to accelerate a wide range of scientific computing applications by harnessing the power of CPU-GPU collaborative computing.

| Concurrent CPU-GPU Tasking | | :-----------------: | | |

Taskflow provides visualization and tooling needed for profiling Taskflow programs.

| Taskflow Profiler | | :-----------------: | | |

We are committed to support trustworthy developments for both academic and industrial research projects in parallel computing. Check out Who is Using Taskflow and what our users say:

• "Taskflow is the cleanest Task API I've ever seen." Damien Hocking @Corelium Inc
• "Taskflow has a very simple and elegant tasking interface. The performance also scales very well." [Glen Fraser][totalgee]
• "Taskflow lets me handle parallel processing in a smart way." Hayabusa @Learning
• "Taskflow improves the throughput of our graph engine in just a few hours of coding." Jean-Michaël @KDAB
• "Best poster award for open-source parallel programming library." [Cpp Conference 2018][Cpp Conference 2018]
• "Second Prize of Open-source Software Competition." ACM Multimedia Conference 2019

See a quick poster presentation below and visit the [documentation][documentation] to learn more about Taskflow. Technical details can be referred to our [IEEE TPDS paper][TPDS22].

Start Your First Taskflow Program

The following program (simple.cpp) creates a taskflow of four tasks A, B, C, and D, where A runs before B and C, and D runs after B and C. When A finishes, B and C can run in parallel. Try it live on Compiler Explorer (godbolt)!

#include <taskflow/taskflow.hpp>  // Taskflow is header-only

int main(){

  tf::Executor executor;
  tf::Taskflow taskflow;

  auto [A, B, C, D] = taskflow.emplace(  // create four tasks
    [] () { std::cout << "TaskA\n"; },
    [] () { std::cout << "TaskB\n"; },
    [] () { std::cout << "TaskC\n"; },
    [] () { std::cout << "TaskD\n"; }
  );

  A.precede(B, C);  // A runs before B and C
  D.succeed(B, C);  // D runs after  B and C

  executor.run(taskflow).wait();

  return 0;
}

Taskflow is header-only and there is no wrangle with installation. To compile the program, clone the Taskflow project and tell the compiler to include the headers.

~$ git clone https://github.com/taskflow/taskflow.git  # clone it only once
~$ g++ -std=c++20 examples/simple.cpp -I. -O2 -pthread -o simple
~$ ./simple
TaskA
TaskC
TaskB
TaskD

Visualize Your First Taskflow Program

Taskflow comes with a built-in profiler, TFProf, for you to profile and visualize taskflow programs in an easy-to-use web-based interface.

# run the program with the environment variable TF_ENABLE_PROFILER enabled
~$ TF_ENABLE_PROFILER=simple.json ./simple
~$ cat simple.json
[
{"executor":"0","data":[{"worker":0,"level":0,"data":[{"span":[172,186],"name":"0_0","type":"static"},{"span":[187,189],"name":"0_1","type":"static"}]},{"worker":2,"level":0,"data":[{"span":[93,164],"name":"2_0","type":"static"},{"span":[170,179],"name":"2_1","type":"static"}]}]}
]
# paste the profiling json data to https://taskflow.github.io/tfprof/

In addition to execution diagram, you can dump the graph to a DOT format and visualize it using a number of free [GraphViz][GraphViz] tools.

// dump the taskflow graph to a DOT format through std::cout
taskflow.dump(std::cout);

<p align="center"><img src="doxygen/images/simple.svg"></p>

Express Task Graph Parallelism

Taskflow empowers users with both static and dynamic task graph constructions to express end-to-end parallelism in a task graph that embeds in-graph control flow.

1. Create a Subflow Graph
2. Integrate Control Flow to a Task Graph
3. Offload a Task to a GPU
4. Compose Task Graphs
5. Launch Asynchronous Tasks
6. Execute a Taskflow
7. Leverage Standard Parallel Algorithms

Create a Subflow Graph

Taskflow supports dynamic tasking for you to create a subflow graph from the execution of a task to perform dynamic parallelism. The following program spawns a task dependency graph parented at task B.

tf::Task A = taskflow.emplace([](){}).name("A");
tf::Task C = taskflow.emplace([](){}).name("C");
tf::Task D = taskflow.emplace([](){}).name("D");

tf::Task B = taskflow.emplace([] (tf::Subflow& subflow) {
  tf::Task B1 = subflow.emplace([](){}).name("B1");
  tf::Task B2 = subflow.emplace([](){}).name("B2");
  tf::Task B3 = subflow.emplace([](){}).name("B3");
  B3.succeed(B1, B2);  // B3 runs after B1 and B2
}).name("B");

A.precede(B, C);  // A runs before B and C
D.succeed(B, C);  // D runs after  B and C

<p align="center"><img src="doxygen/images/subflow_join.svg"></p>

Integrate Control Flow to a Task Graph

Taskflow supports conditional tasking for you to make rapid control-flow decisions across dependent tasks to implement cycles and conditions in an end-to-end task graph.

tf::Task init = taskflow.emplace([](){}).name("init");
tf::Task stop = taskflow.emplace([](){}).name("stop");

// creates a condition task that returns a random binary
tf::Task cond = taskflow.emplace(
  [](){ return std::rand() % 2; }
).name("cond");

init.precede(cond);

// creates a feedback loop {0: cond, 1: stop}
cond.precede(cond, stop);

<p align="center"><img src="doxygen/images/conditional-tasking-1.svg"></p>

Offload a Task to a GPU

Taskflow supports GPU tasking for you to accelerate a wide range of scientific computing applications by harnessing the power of CPU-GPU collaborative computing using Nvidia CUDA Graph.

__global__ void saxpy(size_t N, float alpha, float* dx, float* dy) {
  int i = blockIdx.x*blockDim.x + threadIdx.x;
  if (i < N) {
    y[i] = alpha*x[i] + y[i];
  }
}

// create a CUDA Graph task
tf::Task cudaflow = taskflow.emplace([&]() {
  tf::cudaGraph cg;
  tf::cudaTask h2d_x = cg.copy(dx, hx.data(), N);
  tf::cudaTask h2d_y = cg.copy(dy, hy.data(), N);
  tf::cudaTask d2h_x = cg.copy(hx.data(), dx, N);
  tf::cudaTask d2h_y = cg.copy(hy.data(), dy, N);
  tf::cudaTask saxpy = cg.kernel((N+255)/256, 256, 0, saxpy, N, 2.0f, dx, dy);
  saxpy.succeed(h2d_x, h2d_y)
       .precede(d2h_x, d2h_y);

  // instantiate an executable CUDA graph and run it through a stream
  tf::cudaGraphExec exec(cg);
  tf::cudaStream stream;
  stream.run(exec).synchronize();
}).name("CUDA Graph Task");

<p align="center"><img src="doxygen/images/saxpy_1_cudaflow.svg"></p>

Compose Task Graphs

Taskflow is composable. You can create large parallel graphs through composition of modular and reusable blocks that are easier to optimize at an individual scope.

tf::Taskflow f1, f2;

// create taskflow f1 of two tasks
tf::Task f1A = f1.emplace([]() { std::cout << "Task f1A\n"; })
                 .name("f1A");
tf::Task f1B = f1.emplace([]() { std::cout << "Task f1B\n"; })
                 .name("f1B");

// create taskflow f2 with one module task composed of f1
tf::Task f2A = f2.emplace([]() { std::cout << "Task f2A\n"; })
                 .name("f2A");
tf::Task
