mixemt - Deconvolving mtDNA Mixtures by Expectation Maximization

mixemt is a program for making sense of mixtures of human mitochondrial sequences. It takes as input a BAM file containing reads mapped to the human mitochondrial reference sequence and uses a representation of the mitochondrial haplogroup phylogeny from Phylotree.org to infer the haplogroups present in the mixture. mixemt scans each mapped read for variants described in Phylotree and estimates the probability of the read originating from each candidate haplotype (haplogroup). This information is used to estimate the mixture proportions for the sample and to identify the most likely haplogroups contributing to the sample. The program produces as output a table, written to standard output, that describes the detected haplogroups and their estimated percent contribution to the sample. The program can also produce new BAM files of input fragments partitioned by the most likely contributor of origin, tab-delimited files containing statistics for each reference position, and verbose output detailing the results from each step.

A detailed description and evaluation of the approach implemented in mixemt can be found in the article:

Samuel H. Vohr, Rachel Gordon, Jordan M. Eizenga, Henry A. Erlich, Cassandra D. Calloway, Richard E. Green. A phylogenetic approach for haplotype analysis of sequence data from complex mitochondrial mixtures. Forensic Science International: Genetics. Vol. 30, 93-105. 2017. [link]

If you would like to cite mixemt in a publication, please refer to this article.

Requirements

mixemt is written in Python and requires a few additional packages:

• NumPy/SciPy
• Biopython
• pysam

R and ggplot2 are required to use the plotting scripts included in the directory plot/.

Installation

mixemt can be installed from this repository using pip.

git clone https://github.com/svohr/mixemt.git
cd mixemt
pip install .

Missing requirements will be automatically downloaded and installed.

Usage

mixemt [options] <reads.bam>

Preparing input sequences

mixemt takes as input a BAM file containing alignments of sequences to a reference sequence. The Reconstructed Sapiens Reference Sequence (RSRS) is typically used the reference sequence, although reads may be mapped to the Revised Cambridge Reference Sequence (rCRS) as both share a common coordinate system.

Aligned sequences are provided to mixemt as a BAM file. Alignments should be filtered prior to input using samtools or a similar program. Internally, mixemt treats alignments sharing the same query template name as a single fragment and does not check read pairs for orientation, insert size, unaligned segments, or secondary alignments. The options -q and -Q allow for basic filtering of alignments and base calls based on map quality and base quality scores.

Since the mitochondrial genome is circular, it may be advantageous to align reads across the junction of the start and end of the reference sequence, split the reads, and correct the mapping coordinates. A basic implementation of these steps can be found in the repository circ_aln.

Options

Basic options

-h, --help

Print help message describing usage and options.

-v, --verbose

Print detailed status with useful information while running.

--ref ref.fasta

Specify a FASTA file containing the reference sequence. The first sequence in the file will be used. The reference sequence must match the variants contained in the Phylotree input to avoid unexpected behavior. The Reconstructed Sapiens Reference Sequence (RSRS) contained in mixemt/ref/RSRS.mtDNA.fa is used by default.

--phy phylotree.csv

Specify a Phylotree CSV file to use. By default, the file for Phylotree Build 17 (mixemt/phylotree/mtDNA_tree_Build_17.csv) is used.

Customization options

-H custom.tab, --haps custom.tab

Use the haplotypes described in the specified file along with the haplogroups from Phylotree. A haplotype file consists of lines representing haplotypes. Each line contains a distinct haplotype identifier, a tab character, and a comma-separated list of variants in the form [Ancestral/Reference Base][position][Derived/Variant Base].

custom_hap1	C152T,A2758G,C2885T,G7146A,T8468C
custom_hap2	C4670T,A5282G,C9007T,G12192A,T15604C

Positions that do not appear in the variant list are assumed to contain the reference base and positions that have been excluded from analysis are not used. Variants that appear at novel positions (i.e., no known variants in Phylotree) can be used, but it is assumed that all Phylotree haplogroups carry the reference base.

-e SITES, --exclude_pos SITES

Specify a comma-separated list of 1-based positions or 'start-end' ranges to be excluded from consideration.

-A, --anon-haps

Ignore Phylotree haplogroups without IDs. By default, a placeholder name is generated for these haplogroups using the parent haplogroup's ID and an integer number (e.g., H1[2] is a unnamed subgroup of haplogroup H1).

-U, --unstable

Ignore sites with variants listed as unstable in Phylotree.

Quality filters

These options provide basic filtering of mapped sequences and base observations.

-q INT, --min-MQ INT

Ignore alignments with mapping quality less than INT (default: 30).

-Q INT, --min-BQ INT

Ignore bases with base quality scores less than INT (default: 30).

Expectation-maximization

Options for setting the parameters used during the expectation-maximization step where the mixture proportions are inferred. The default values should work well most of the time, but adjusting these values may be useful in some situations.

-S N --seed N

Use value N to seed the random number generator that generates starting mixture proportions. Allows mixemt to be run multiple times using the same input and produce the same results each time. If unset, the starting mixture proportions will differ with each run.

-i ALPHA, --init ALPHA

Use parameter ALPHA to initialize haplogroup contributions from Dirichlet distribution. Set to 'inf' to give haplogroups equal priors. (default: 1.0)

-T TOLERANCE, --converge TOLERANCE

Stop EM iteration when absolute difference between current and previous contribution estimates is less than TOLERANCE (default: 0.0001)

-m N, --max-em-iter N

Maximum of number of EM iterations to run (default: 10000)

-M N, --multi-em N

Run EM until convergence multiple times and report the results averaged over all runs (default: 1)

Contributor detection options

Once the mixture proportions have been inferred, two filtering steps are applied to narrow the field of contributing to haplotypes to only the strongest candidates. First, we examine the read/haplogroup probabilities to find the haplogroup associated with the highest probability for each read. Haplogroups that have no or little read support are removed from consideration (see -r option). Second, using the haplogroups that pass the previous filter, we verify that the variants that define each contributor are in fact present in the mixture. This step removes haplotype signals that are most likely driven by one or two private mutations.

-C HAP1,HAP2,...,HAPN, --contributors HAP1,HAP2,...,HAPN

Skip contributor detection step and use the specified comma-separated list of haplogroups instead (be careful).

-r N, --min-reads N

Haplogroup must have N reads to be considered a contributor (default: 10). This value should be adjusted when coverage is high to avoid signals caused by sequencing errors and when coverage is low and allelic dropout may be likely.

-R N, --var-min-reads N

Variant base must be found in N reads to be considered as present in sample (default: 3). This value should be above the expected number of base errors given the sequence coverage.

-F F, --var-fraction-min-reads F

Variant base must be found in fraction F of reads to be considered as present in sample. A minimum of reads can be set with the -R option for when this is low or can be low (default: 0.02)

-f F, --var-fraction F

Fraction of unique defining variants that must be observed to call a haplogroup present (default: 0.5). This value should be adjusted based on the likelihood of allelic dropout and the number of variant differences between contributors.

-n N, --var-count N

Call haplogroup a contributor if it has at least N unique variants observed in the sample, regardless of total number of defining variants. Use when allelic dropout is likely (default: None).

-V, --no-var-check

Disable requirement that the majority of contributors' unique defining variants are present in the sample. Use when coverage is very low and dropout is likely.

-E

Skip contribution estimate refinement and report proportions from initial EM run.

Assembly options

-a ODDS, --assign-odds ODDS

Minimum odds ratio (probability between best and second best haplogroup) required to assign read to a contributor (default: 2.0)

-x, --extend-assemblies

Attempt to extend haplotype assemblies iteratively by identifying novel variants from contributor consensus sequences assigning reads based off of them.

-c N, --cons-cov N

When extending assemblies with -x, sets the depth of coverage required to call a base for a contributor (default: 2)

Output options
