ASCEND <img align="right" width="200" src="https://github.com/sunyatin/ASCEND/blob/master/7.jpeg">

ASCEND (Allele Sharing Correlation for the Estimation of Nonequilibrium Demography) is a method to estimate the age and intensity of founder events/bottlenecks using population genotype data and a recombination map.

:arrow_right: Current version: 10.1.1 [09.12.2022]

• Tutorial
• Installation
• Requirements
• Input
• Command line
• Full list of parameters
• Output files
• Full example
• Typical parameter file for an aDNA analysis
• Troubleshooting
• Version
• License
• Support
• References

:v: Tutorial

A series of examples/tutorials is present in the docs directory:

• for inferring founder events for present-day samples of a diploid species, click here.
• for inferring founder events for ancient samples of a diploid species, considering only the 5 five chromosomes, click here.

:point_down: Installation

ASCEND is a Python3 script and does not require prior installation apart specific modules (numpy, scipy) that you can install using the command:

pip3 install --user numpy

pip3 install --user pandas

pip3 install --user matplotlib

pip3 install --user scipy

:heavy_exclamation_mark: Requirements

For optimal use, ASCEND requires that your population is comprised of at least 5 samples. ASCEND is based on EIGENSTRAT-formatted input files and requires genetic positions, provided in the 3rd column of the .snp file (genetic positions can be given either in Morgans or centiMorgans). The method currently does not support packed formats like packedancestrymap, packedped, packedeigenstrat, etc. Please use convertf to convert the data to eigenstrat format before use.

Since ASCEND relies on the recombination map, make sure your SNPs have the most accurate genetic positions (see https://github.com/sunyatin/itara/blob/master/liftover.py to lift positions over a recombination map).

:dna: Input

ASCEND requires that the input data is in EIGENSTRAT format. See here for more details. Currently, ASCEND does not accept binary or packed EIGENSTRAT files (e.g. packedeigenstrat or packedancestrymap) (but we plan to handle this format soon). *If you have binary EIGENSTRAT .geno file, please convert them to non-binary format using CONVERTF.

The EIGENSTRAT format is comprised of three files:

• *.ind A 3-column file with each individual on one row, and columns are (1) individual name, (2) individual sex (note that sex is not used for the ASCEND analysis), (3) population label
• *.snp A 6-column file with each SNP on one row, and columns are (1) SNP name, (2) chromosome, (3) genetic position (in Morgans or centiMorgans), (4) physical position (in base pairs), 5th and 6th columns are the ancestral/derived or reference/alternate alleles but these 2 columns are not taken into account for the ASCEND analysis
• *.geno The genotype matrix with no delimiter between genotypes, each row is one SNP and each column is one individual, genotypes are encoded as 0 (= 1/1), 1 (=0/1) or 2 (=0/0). Missing genotypes are encoded as 9.

You can convert your file into EIGENSTRAT using the CONVERTF program (see https://github.com/argriffing/eigensoft/tree/master/CONVERTF).

Note that although the .geno file must not be binary, but it can be gzip-compressed.

:computer: Command line

To run an ASCEND analysis:

python3 ASCEND.py -p [NameOfTheParameterFile].par

Note that by default, ASCEND assumes that the genetic positions are in Morgans and that the samples are diploid.

For reliable estimation, use a minimum of 5 diploids in the target and outgroup populations.

For best performance, we advise to use ~15 individuals for the outgroup population.

:wrench: Full list of parameters

Note that you can comment any line and option using "#" (the software will ignore those lines). Also, the options can be written in any order.

Mandatory options

• genotypename: [STRING] name of the input .geno file
• snpname: [STRING] name of the input .snp file
• indivname: [STRING] name of the input .ind file
• outputprefix: [STRING] prefix of the output file, ASCEND will automatically append the appropriate extensions
• targetpop: [STRING] name of the target population to analyze

Optional options (if not provided, ASCEND will take the default values)

• outpop: [STRING] (recommended) add this option to correct the within-population allele sharing correlation by a cross-population correlation to remove background LD; you have two options: (1) write outpop: RANDOM and add the option outpopsize: n to pick n random individuals (random sampling without replacement of all individuals not annotated with population the label Ignore) from the dataset that are not in your target population (recommended) or (2) the name of the specific outgroup population to use. If this option is not provided, ASCEND will not compute the cross-population correlation and will instead output nan in the corresponding column. Note that outpop: RANDOM will generate a file with extension RandomOutpop.ind where the individuals picked up to form the outgroup population are annotated with the population label "OUTGROUP". Note that if outpop: RANDOM, individuals with the population label Ignore will not be considered for outgroup sampling.

• outpopsize: [INTEGER] if you provided the option outpop: RANDOM then add this option with the size of the outgroup population to create randomly (recommended: 15)

Related to genetic data

• chrom: [comma-separated list of integers] add this option with a comma-separated list of chromosomes on which to restrict the analysis (for instance, chrom: 1, 2, 3 to restrict the analysis to chromosomes 1, 2 and 3). Check if your dataset contains sexual chromosomes, in such case, we recommend to restrict the analyses only to the autosomes using this option
• haploid: YES/NO ASCEND assumes genotypes are diploid but if you set this option to YES it will interpret your genotypes as haploid (default: NO)
• dopseudohaploid: YES/NO set YES if your genotypes have to be pseudohaploidized (i.e. for heterozygous genotypes, one allele will be randomly picked and set in two copies) (default: NO). Note that even if the genotypes are already provided as pseudohaploid in the input .geno file, you still must set dopseudohaploid: YES so that ASCEND computes the allele sharing in an unbiased way.

Related to SNP filtering

• maxpropsharingmissing: 1.0 maximum proportion of missing allele sharing allowed (above this threshold the SNP will be discarded) (default: 1.0)
• minmaf: 0 minimum Minor Allele Frequency that is allowed for a SNP to be taken into account, i.e. if a SNP has MAF<minmaf or MAF=minmaf, it will be excluded (default: 0.0)

Related to the decay curve parameters

• mindis: 0.001 minimum genetic distance in Morgans (default: 0.001 M)
• maxdis: 0.3 maximum genetic distance in Morgans (default: 0.3 M)
• binsize: 0.001 size of the genetic distance bin in Morgans (default: 0.001 M)
• morgans: YES/NO set NO if your input genetic distances are in centiMorgans (by default ASCEND assumes Morgans) (default: YES)

Related to the algorithm

• usefft: YES/NO whether to use the Mesh + Fast Fourier Transforms (FFT) algorithm which speeds up the calculation by up to 8,000 times with only marginal approximations. In general, we advise to use the FFT instead of the Naïve implementation for reasons of speed and accuracy, especially in case of high rates of missing genotypes (FFT handles missingness better than the Naïve implementation).
• qbins: 100 number of mesh points within each bins of the decay curve to consider for the mesh-FFT approximation (a higher number increases the mesh resolution and hence the accuracy of the decay curve, but also slows down the computation - we found that 100 was a good compromise between speed and accuracy) (default: 100)
• randomhet: YES/NO by default, when two individuals are heterozygous at a site, we assume that they share only 1 allele (randomhet: NO) which is our way to handle phasing uncertainty; however if you set this option as YES then the number of alleles shared will be picked up randomly as either 0 (the reference allele is on different chromosomes between the two individuals) or 2 (the reference allele is on the same chromosome between the two individuals).
• calculation_mode: auto/correlation/weighted_covariance by default, ASCEND will automatically detect the format of your genotypes based on the haploid and dopseudodiploid options you provided, and run the (i) allele sharing correlation function for diploid or haploid data or (ii) run the allele sharing weighted covariance function for pseudohaploid data. This is to ensure that no bias is introduced when estimating the amplitude of the decay curve. Although we do not advise to do so, you can still force the use of a specific function using the values correlation or weighted_covariance, respectively. An error message will pop up if the nature of the input genotypes do not match the function you provided.

Related to the fitting

• onlyfit: YES/NO set YES if you want to do the estimation of the parameters directly, using the .out and .perchr.out files that have been already output by the script (using onlyfit: YES can be dangerous, if you have any doubt, we would advice to rerun the all analysis) (default: NO)
• blocksizename: [file path] add this option t
