LISA: Linguistically-Informed Self-Attention

This is a work-in-progress, but much-improved, re-implementation of the linguistically-informed self-attention (LISA) model described in the following paper:

Emma Strubell, Patrick Verga, Daniel Andor, David Weiss, and Andrew McCallum. Linguistically-Informed Self-Attention for Semantic Role Labeling. Conference on Empirical Methods in Natural Language Processing (EMNLP). Brussels, Belgium. October 2018.

To exactly replicate the results in the paper at the cost of an unpleasantly hacky codebase, you can use the original LISA code here.

Requirements:

• >= Python 3.6
• >= TensorFlow 1.9 (tested up to 1.12)

Quick start:

Data setup (CoNLL-2005):

1. Get pre-trained word embeddings (GloVe):

   wget -P embeddings http://nlp.stanford.edu/data/glove.6B.zip
   unzip -j embeddings/glove.6B.zip glove.6B.100d.txt -d embeddings


2. Get CoNLL-2005 data in the right format using this repo. Follow the instructions all the way through further preprocessing.
3. Make sure the correct data paths are set in config/conll05.conf

Train a model:

To train a model with save directory model using the configuration conll05-lisa.conf:

bin/train.sh config/conll05-lisa.conf --save_dir model

Evaluate a model:

To evaluate the latest checkpoint saved in the directory model:

bin/evaluate.sh config/conll05-lisa.conf --save_dir model

Evaluate an exported model:

To evaluate the best<sup id="f1">1</sup> checkpoint so far, saved in the directory model (with id 1554216594):

bin/evaluate-exported.sh config/conll05-lisa.conf --save_dir model/export/best_exporter/1554216594

Training

The bin/train.sh script calls src/train.py with parameters specified in top-level configs (i.e. conll05-lisa.conf) which is the entry point for training. The following table describes the command line parameters that may be passed to src/train.py to configure training:

| Name |Type |Description | Default value |
|----------------|----------|------------------------|---| | train-files | string | Comma-separated list of training data files. | None | | dev-files | string | Comma-separated list of development data files. | None | | save-dir | string | Directory to save models, outputs, etc. If the directory already exists and contains a trained model, training will restart where it left off. Vocabularies will be re-used. | None | | transition_stats | string | File containing pre-computed transition statistics between labels. Tab-separated file with one label-label-probability triple per line. | None | | hparams | string | Comma separated list of name=value hyperparameter settings. | None | | debug | string | Whether to run in debug mode: a little faster and smaller. | False | | data_config | string | Path to data configuration json. | None | | model_configs | string | Comma-separated list of paths to model configuration json. | None | | task_configs | string | Comma-separated list of paths to data configuration json. | None | | layer_configs | string | Comma-separated list of paths to data configuration json. | None | | attention_configs | string | Comma-separated list of paths to attention configuration json. | None | | keep_k_best_models | int | Number of best models to keep. | 1 | | best_eval_key | string | Key corresponding to the evaluation to be used for determining early stopping. The value must correspond to a named eval under the eval_fns entry in a task config. | None |

Hyperparameters

The following table lists optimization/training hyperparameters that can be set through the hparams command line flag. Hyperparameters are initialized to the default values are defined in src/constants.py. Then, these are overridden by hyperparameters set in the model config (e.g., glove_basic.json). Finally, these are overridden by hyperparameters specified at the command line. Hyperparameter loading is implemented in src/train_utils.py.

| Name |Type |Description | Default value |
|---------------|----------|------------------------|---| | learning_rate | float | Initial learning rate. | 0.04 | | beta1 | float | Adam first moment decay rate. | 0.9 | | beta2 | float | Adam second moment decay rate. | 0.98 | | epsilon | float | Adam epsilon. | 1e-12 | | decay_rate | float | Exponential rate of decay for learning rate. | 1.5 | | use_nesterov | boolean | Whether to use Nesterov momentum in Adam. | true | | decay_steps | int | If warmup_steps is not set, perform stepwise decay of learning rate every this many steps. | 5000 | | warmup_steps | int | Number of training steps to linearly increase learning rate before exponential decay. | 8000 | | batch size | int | Approximate number of sentences per batch. | 256 | | shuffle_buffer_multiplier | int | Value to multiply by batch size to determine buffer size for efficient shuffling of examples during training. Higher means better shuffles, lower means less initial time required to fill shuffle buffer. | 100 | | eval_throttle_secs | int | Do not run evaluation unless at least this many seconds have passed since the last evaluation. | 1000 | | eval_every_steps | int | Evaluate every this many steps. | 1000 | | num_train_epochs | int | Iterate through the full training data this many times. | 10000 | | gradient_clip_norm | float | Clip gradients to this maximum value. | 5.0 | | label_smoothing | float |Amount of label corruption for smoothing. Smoothing not performed if this value is 0. | 0.1 | | moving_average_decay | float | Rate of decay for moving average of model parameters. Averaging not performed if this value is 0. | 0.999 | | average_norms | boolean | Whether to average variables representing norms in parameter averaging. | false | | input_dropout | float | Dropout rate on input layer (embeddings). | 1.0 | | bilinear_dropout | float | Dropout rate used in bilinear classifier. | 1.0 | | mlp_dropout | float | Dropout used in MLP layers | 1.0 | | attn_dropout | float | Dropout rate on attention in transformer. | 1.0 | | ff_dropout | float | Dropout rate in feed-forward layer in transformer. | 1.0 | | prepost_dropout | float | Dropout rate applied before and after the feed-forward part of transformer layer. | 1.0 | | random_seed | int | Random seed to use for training. | time.time() |

Model hyperparameters (e.g. layer size, number of self-attention heads) are set in the model config json.

Evaluation

TODO

Custom configuration [WIP]

LISA model configuration is defined through a combination of configuration files. A top-level config defines a specific model configuration and dataset by setting other configurations. Top-level configs are written in bash, and bottom-level configs are written in json. Here is an example top-level config, conll05-lisa.conf, which defines the basic LISA model and CoNLL-2005 data:

# use CoNLL-2005 data
source config/conll05.conf

# take glove embeddings as input
model_configs=config/model_configs/glove_basic.json

# joint pos/predicate layer, parse heads and labels, and srl
task_configs="config/task_configs/joint_pos_predicate.json,config/task_configs/parse_heads.json,config/task_configs/parse_labels.json,config/task_configs/srl.json"

# use parse in attention
attention_configs="config/attention_configs/parse_attention.json"

# specify the layers
layer_configs="config/layer_configs/lisa_layers.json"

And the top-level data config for the CoNLL-2005 dataset that it loads, conll05.conf:

data_config=config/data_configs/conll05.json
data_dir=$DATA_DIR/conll05st-release-new
train_files=$data_dir/train-set.gz.parse.sdeps.combined.bio
dev_files=$data_dir/dev-set.gz.parse.sdeps.combined.bio
test_files=$data_dir/test.wsj.gz.parse.sdeps.combined.bio,$data_dir/test.brown.gz.parse.sdeps.combined.bio

Note that $DATA_DIR is a bash global variable, but all the other variables are defined in these configs.

There are five types of bottom-level configurations, specifying different aspects of the model:

• data configs: Data configs define a mapping from columns in a one-word-per-line formatted file (e.g. the CoNLL-X format) to named features and labels that will be provided to the model as batches.
• model configs: Model configs define hyperparameters, both model hyperparameters, like various embedding dimensions, and optimization hyperparameters, like learning rate. Optimization hyperparameters can be reset at the command line using the hparams command line parameter, which takes a comma-separated list of name=value hyperparameter settings. Model hyperparameters cannot be redefined in this way, since this would invalidate a serialized model.
• task configs: Task configs define a task: label, evaluation, and how predictions are formed from the model. Each task (e.g. SRL, parse edges, parse labels) should have its own task config.
• layer configs: Layer configs attach tasks to layers, defining which layer representations should be trained to predict named labels (from the data
