TLA+ Ping Pong Example

This is the example model described in the paper S. Resch and M. Paulitsch, "Using TLA+ in the Development of a Safety-Critical Fault-Tolerant Middleware," 2017 IEEE International Symposium on Software Reliability Engineering Workshops (ISSREW), Toulouse, France, 2017, pp. 146-152. doi: 10.1109/ISSREW.2017.43

Model Description

Nodes use timeouts, ping and pong messages to determine whether the other nodes are on or off.

Each node initially starts a timeout with a long duration and listens for ping messages. If the timeout expires the node itself sends out a ping message with a sequence number, otherwise it answers to a received ping message with a pong message having the same sequence number. Afterwards it periodically restarts the timeout and sends ping messages with incrementing sequence numbers after reception of the timeout or a pong message with the next sequence number. A node sees the other nodes as on if it received a ping or pong message with the same sequence number it currently expects. Note, that this is algorithm is solely intended to showcase the framework.

All but one node can fail in the example.

Files

• README.md

  this file

• generic.cfg

  the generic config for the modelchecker - defines which system definition, invariants and properties are used for model checking

• pingpong.tla

  the pingpong state machine of the nodes in PlusCal

• pingpong_cfg.tla

  the configuration values in TLA+

• pingpong_env.tla

  the environment in TLA+

• pingpong_prop.tla

  the property definitions for modelchecking

• pingpong_trace.tla

  properties to get traces

• scn_1_node.tla

  the model checking scenario for one node

• scn_2_nodes.tla

  the model checking scenario for two nodes

• scn_3_nodes.tla

  the model checking scenario for three nodes

• seqnr.tla

  definitions for sequence numbers

Translating and Modelchecking

1. Prerequisite

1.1. Installed Java VM

1.2. Installed TLA+ tools at $BASE_INSTALL_DIR/tla

```
BASE_INSTALL_DIR=<install_path>

cd $BASE_INSTALL_DIR
wget https://github.com/tlaplus/tlaplus/releases/download/v1.5.3/tla.zip
unzip tla.zip
```

2. Translate PlusCal Code to TLA+

```
java -cp $BASE_INSTALL_DIR/tla pcal.trans -nocfg pingpong.tla
```

3. Execute TLC for scenarios

```
java -cp $BASE_INSTALL_DIR/tla tlc2.TLC -config generic.cfg scn_1_node.tla
java -cp $BASE_INSTALL_DIR/tla tlc2.TLC -config generic.cfg scn_2_nodes.tla
java -cp $BASE_INSTALL_DIR/tla tlc2.TLC -config generic.cfg scn_3_nodes.tla
```

Get an Example Trace

1. Uncomment a trace property, e.g. TraceAllNodesAreOnAndSeeAllAsOn, in generic.cfg:

   [...]
   \* Traces:
   \* Uncomment the corresponding trace property and run tlc to obtain a trace

   TraceAllNodesAreOnAndSeeAllAsOn
   \* TraceOneNodeIsOnAndOthersAreOffAndItSeesThemAsOff
   [...]


2. Run TLC

   java -cp $BASE_INSTALL_DIR/tla tlc2.TLC -config generic.cfg scn_2_nodes.tla
