Storymaps

This package generates a 3D city using geojson data from OpenStreetMaps, generated by overpass-turbo. The package comes with a sample dataset of Bruges, however you will need to get your own data if you want another city.

Thesis I wrote about this project is available at: https://lavrenov.io/thesis/thesis.pdf

DEMO

• list of demos available at https://tania.tours/demo

Getting GeoJSON data

Get the geojson data from overpass-turbo;

Select the area you want to display on the website, and copy and run the query below. Click on Export and save as geojson.

[out:json]
[bbox:{{bbox}}]
[timeout:30];

(
way["building"]({{bbox}});
relation["building"]["type"="multipolygon"]({{bbox}});

way["highway"]({{bbox}});
relation["highway"]["type"="polygon"]({{bbox}});

way["natural"="water"]({{bbox}});
way["water"="lake"]({{bbox}});
way["natural"="coastline"]({{bbox}});
way["waterway"="riverbank"]({{bbox}});

way["leisure"="park"]({{bbox}});
way["leisure"="garden"]({{bbox}});
);

out;
>;
out qt;

You also need the latitude and longitude coordinates of the center of the selected area. You can use Google Maps to get this data.

Configuration

after installing this package following the steps in INSTALLATION.md, you can start configuring it in main.js before you run the setup() or start() functions, create a configuration.

import * as storymaps from "storymap";

storymaps.global.config = {
	debug: true,
	data: "/node_modules/storymap/sample/bruges.geojson",
	path: "/node_modules/storymap/sample/path.json",
	container: "container",
	citycenter: [3.227183, 51.209651],
	color_background: 0x222222,
	color_buildings: 0xfafafa,
	grid: { primary: 0x555555, secondary: 0x333333 },
	color_ground: 0x00ff00,
	opacity_ground: 0.25,
};

storymaps.setup();

This will overwrite the default configuration values.

• data: points to the geojson data you can get from overpass.turbo.eu
• path: points to a path you can create in .setup() mode.
• container: the ID of the div in which your canvas will sit.
• citycenter: the latitude/longitude of the centerpoint of your geojson data.

ANIMATION

To exit "create a path mode", use the .start() function.

// storymaps.setup()
storymaps.start();

This will create an on-scroll animation for the camera that follows the path you created on scroll.
