Android Kernel Vulnerability

Overview

In November 2017 a use-after-free bug to linux kernel was detected by syzkaller system. In February 2018 this was patched in some linux kernels and android versions.

This fix was never included in Android monthly security bulletins, so it was not patched in many newly released devices such as Pixel and Pixel2.

In September 2019 android was informed of the security implications of this bug by Project Zero. Then android assigned CVE-2019-2215 to this vulnerability to make it more formal and known.

CVE-2019-2215 is a use-after-free in binder.c that allows evaluation of privilege (getting root access) from an android application. There is no need to user’s interaction, to exploit this vulnerability. It only requires the installation of a malicious local application.

Here we are going to introduce this android kernel vulnerability in more details and use this vulnerability to get root access (privilege escalation) of the whole android device.

We will use this Proof of Concept (PoC):

https://github.com/cloudfuzz/android-kernel-exploitation

Triggering vulnerability

We will first show you a way to trigger this vulnerability on an android emulator and make a kernel crash. Then to see how it would be dangerous, we continue using PoC to get root access in the simulated android device. Then we will analyze the kernel code to see what is the reason (static and dynamic analysis).

After analysis, we will see how we got the root access. At last we see how this vulnerability is mitigated using patches.

To make a kernel crash by triggering this vulnerability we use this steps:

1. First of all, you need a linux OS with 'gdb' and 'python' installed.
2. Clone the PoC repository. (https://github.com/cloudfuzz/android-kernel-exploitation)
3. Install android emulator and android NDK (By Installing Android Studio)
4. Clone the android Kernel source code. (The 'q-goldfish-android-goldfish-4.14-dev' branch will be used)
5. This kernel is already patched, we change it to reintroduce the vulnerability in this kernel code.
6. Now We should build the kernel from source code. We build our kernel with KASan.
7. We boot the built kernel and run our emulator with it.
8. Then by using 'trigger.cpp' in the PoC repository, we trigger a crash (using 'adb' cmd).
9. We will use 'root-me.py' in PoC and 'gdb' cmd to get root access in the emulated device.

Watch the following video:

[video]

Static analysis

In This (and next) section we are going to understand why the crash happens by using static and dynamic analysis.

Here we will analyze kernel code (static analysis) to understand the problem. In crash_report.txt there is the report from KASan which says this is a use-after-free bug. It means an object is allocated in heap (and we have a reference to it), then we freed the object from the heap and then we erroneously called it by a reference. In this report the stack trace of these three stages is printed.

If you remember from above, we used 'trigger.cpp' in the PoC.

Here is main code of trigger.cpp:

int main() {
	//1
	int fd, epfd;
	//2
	struct epoll_event event = {.events = EPOLLIN};
	//3
	fd = open("/dev/binder", O_RDONLY);
	//4
	epfd = epoll_create(1000);
	//5
	epoll_ctl(epfd, EPOLL_CTL_ADD, fd, &event);
	//6
	ioctl(fd, BINDER_THREAD_EXIT, NULL);
}

Let's see what 'trigger.cpp' is doing.

In Android (like other Unix-based operating systems) we have some processes. Every program that we run creates one (or more) processes and these processes are handled by OS. OS may switch between them (multi-tasking) or terminate a process, etc. For security reasons, processes are isolated from each other by default.

In some cases, one process may need to exchange data with another process. It is called Interprocess Communication (IPC). There are several ways for processes to communicate in linux. Android introduced a specific IPC mechanism called 'Binder'. Binder is a kernel driver to facilitate inter-process communication.

In android, IPC can be done by directly calling some kernel methods (most of them are in drivers/binder.c) or using high-level implementations (for example in java).

For using binder, we should open the kernel binder module. It is done using line 3 of trigger.cpp. Then we have a file descriptor pointer, By using this fd kernel initiator and recipients of the IPC can be identified.

All interactions with the driver will happen through a small set of 'ioctl' commands (BINDER_THREAD_EXIT, BINDER_WRITE_READ, ...).

More about binder: link1, link2

In linux, we have a concept called 'event polling'. 'epoll' API is used when we want to monitor multiple file descriptors (file descriptors are what we have when opening a driver or working with IO, etc).

epoll is a kernel struct which has two important field.

• interest list = list of file descriptors we want to monitor.
• ready list = list of file descriptors that are ready for I/O.

Inorder to use event polling, we first create an epoll (line 4), then add or delete (EPOLL_CTL_ADD) an event (&event) associated with a file descriptor (fd) to our created epoll (epfd) by calling epoll_ctl method of kernel.

=> epoll_event event is an event, triggered when the associated file (fd) is available for read operation.

Now we understand what trigger.cpp is doing (no need to go deep!). It opens the binder module, creates an epoll to listen to it when it is ready. Then at line 6, we exit from the binder that we started in line 3.

Allocate:

By calling open(), we actually call open_binder() ( open() implementation in binder.c ), in open_binder(), a new 'binder_proc' struct will be created and:

fd->pricate_data = binder_proc

By calling epoll_create(), a new epoll struct will be created and added to a queue structure.

By calling epoll_ctrl(epdf, ADD, fd, event), a new ep_item is created, associate fd (file descriptor to listen) to this ep_item, and it is inserted to event_poll's red black tree ( a data structure in ep to save ep_items ). It also calls ep_item_poll(), this method handles the call back function association to ep_item.

It creates new binder_thread struct (allocation happens here), links it to the binder_proc (created above), then an epoll_entry struct is created, it has two lists, epoll_entry->wait and epoll_entry->whead, both of these lists have a pointer to binder_thread created before.

Then epoll_entry is linked to ep_item (ep_item->pwqlist is a list that contains this epoll_entry).

Free:

By calling ioctl(fd, ...), binder_proc is accessed through fd->private_data, then the binder_thread struct will be freed from the memory.

Use:

When our current process exits, epoll_ctl(epfd, DEL, fd, event) will be called.

It calls ep_remove(event_poll, ep_item). This method gets the epoll_entry from ep_item->pwqlist, then gets the wait list of ep_item (ep_tem->wait), it is a linked list, it wants to remove one of this wait list's items.

It uses following code (pseudo code is used):

entry = wait->entry;
entry.next.prev = entry.prev;
entry.prev.next = entry.next;

Here wait->entry is a pointer to binder_thread which was removed from memory! So it is a use after free and causes a bug!!

• In above, we used codes similar to actual kernel codes, they may be different in some details. (some cases binder_thread is used instead of binder_thread->wait)

Summary:

We created an event_poll that has a red_black_tree, each node is an ep_item that has a field which is a list of epoll_entry, each epoll_entry has two pointers to binder_thread struct (wait, whead).

By calling ioctl() we freed the binder_thread from memory, Then while exiting this struct is accessed through a pointer which was still available!

Dynamic analysis

Dynamic analysis is the testing and evaluation of a program by executing data in real-time ; to find errors in a program while it is running.

steps:

1. Build Android Kernel without KASan

   We build it without KASAN to monitor write and unlink operations and what is really happening after unlink operation.

2. Boot emulator with the newly built kernel

3. Launch emulator

4. Use GDB to attach to the QEMU instance

5. Build the vulnerability trigger and push it to the virtual device

6. Break in GDB

   Load the custom python script(dynamic-analysis.py in repo) : To trace function calls and dump the binder_thread structure chunk before and after it's freed. Also dump the same binder_thread structure before and after the unlink operation has been done.

   In this file we first [delete all bre
