JsPlot3D

I did this for the sole purpose of learning and practice three.js ages ago, there are far better and more complete solutions out there (https://plot.ly/python/3d-scatter-plots/), don't even try to use this. The code quality and everything is, due to me not having any experience back then, probably really bad.

<p align="center"><img width="32%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/title.png"/></p>

Plots functions and .csv files. Based on three.js. It is written in ES6 syntax and compiled using Webpack.

<p align="center"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/bar.png"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/polygon.png"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/line.png"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/spatial.jpg"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/barchart.png"> <img width="16%" src="https://raw.githubusercontent.com/sezanzeb/JsPlot3D/master/images/scatter.png"> </p> <br/>

Live Example

Click here for a live example:

http://hip70890b.de/JsPlot3D/examples/playground/index.html

You can uploade one of the csvs in /examples/csvFiles. Or get a .csv dataset (for example on kaggle.com). The live example also gives insight about the settings that can be handed over to plotCsvString, plotDataFrame, plotFormula and addDataPoints.

<br/>

Info

Download: http://hip70890b.de/JsPlot3D/compiled/JsPlot3D.js

How To: If you want to start using JsPlot3D, take a look at https://github.com/sezanzeb/JsPlot3D/blob/master/USAGE.md

Documentation: https://doclets.io/sezanzeb/JsPlot3D/master ("API")

Building: https://github.com/sezanzeb/JsPlot3D/blob/master/MORE.md

<br/>

Features

• scatterplots
• coloring labels
• heatmap colored datapoints
• validates and plots formulas
• barcharts
• placing autogenerated legends into the DOM
• optimized for adding/replacing datapoints quickly during runtime
• reads .csv files
• lineplots
• 2D view

<br/>

Example

You can copy the following to a file.html and open it using your browser. It should work right away and show 6 datapoints in red, blue and green and a legend below it that explainins the colors and the axes

    <div id="plot" style="width:400px; height:350px;"></div>
    <div id="legend"></div>
    <div style="display:none" id="csv">
        SepalLength,SepalWidth,PetalLength,PetalWidth,Name
        5.1,3.5,1.4,0.2,Iris-setosa
        4.9,3.0,1.4,0.2,Iris-setosa
        7.0,3.2,4.7,1.4,Iris-versicolor
        6.4,3.2,4.5,1.5,Iris-versicolor
        6.3,3.3,6.0,2.5,Iris-virginica
        5.8,2.7,5.1,1.9,Iris-virginica
    </div>
    <script src="http://threejs.org/build/three.min.js"></script>
    <script src="http://hip70890b.de/JsPlot3D/compiled/JsPlot3D.js"></script>
    <script>

        // place a canvas element inside the div with the id plot
        var plot = new JSPLOT3D.Plot(document.getElementById("plot"))

        // plot data into that canvas
        var data = document.getElementById("csv").innerHTML
        plot.plotCsvString(data, 0, 1, 2, {
            dataPointSize: 0.2,
            colorCol: 4,

            // optional, can be autodetected:
            labeled: true,
            header: true,
            separator: ","
        })

        // place the autogenerated legend somewhere
        plot.createLegend(document.getElementById("legend"))

    </script>
    <style>
        body {
            font-family: sans-serif;
        }

        .jsP3D_labelColor {
            width: 10px;
            height: 10px;
            display: inline-block;
            border-radius: 100%;
        }
    </style>
