pineapple60

ergonomic keyboard with Trackpoint

The purposes of this project.

• Install it in ThinkPad

p60P

2025-07 second project, Pineapple60-Popup, installing a Pop-up keyboard on X250. Preparing for patent application before public release. Stay tuned.

p60S

2025 new project, pineapple60s

Row-Staggered Ergonomic (Alice) keyboard with Kailh PG1316 for installing ThinkPad X13 Gen2

For this modification, I chose the target PC for the following reasons:

• It has a Trackpoint
• The keyboard can be easily replaced (the latest ThinkPads are getting difficult)
• The Trackpoint buttons should be on the case, not on the keyboard unit. Otherwise, I would need to attach the buttons to the keyboard I was making.

The following ThinkPads meet the above requirements:

• T440 to T460, and so on
• T460s and T470s
• X13 Gen2 and Gen3

X240 to X270 are also close, but we need to remove the motherboard to remove the keyboard.

Project repository: https://github.com/saoto28/pineapple60s.git

How to make (in Japanese): https://note.com/saoto28/n/n716b7ca2e1f9

p0

Extra edition. Trackpoint module installation.

2021-10 Add the Trackpoint module of ThinkPad X100 on the Microsoft Ergonomic Keyboard.

How to install the Trackpoint module in the MS ergonomic keyboard

~~## p60X~~

~~Variable key layout board for researching ergonomic keyboard layouts~~

~~< 2021-09 coming soon >~~

p50V

V-style key layout board

2021-08 installed on my T470s

p60-03

third prototype pcb

2021-05 p60-03b

how to make the ergonomic Trackpoint keyboard

p4

2021-03 key layout testing module

p60-02

2020-12 second prototype pcb

p60-01

2020-10 first prototype pcb

pre-pineapple

2020-08 I tried to make an ergonomic keyboard for my ThinkPad T470s, by disassembling and modifying the spare keyboard. But, gave up.
