Go-Flow

A Golang based high performance, scalable and distributed workflow framework

It allows to programmatically author distributed workflow as Directed Acyclic Graph (DAG) of tasks. GoFlow executes your tasks on an array of workers by uniformly distributing the loads

Stability and Compatibility

Status: The library is currently undergoing heavy development with frequent, breaking API changes.

☝️ Important Note: Current major version is zero (v0.x.x) to accommodate rapid development and fast iteration. The public API could change without a major version update before v1.0.0 release.

Install It

Install GoFlow

go mod init myflow
go get github.com/s8sg/goflow@master

Write First Flow

Library to Build Flow github.com/s8sg/goflow/flow/v1

Make a flow.go file

package main

import (
	"fmt"
	goflow "github.com/s8sg/goflow/v1"
	flow "github.com/s8sg/goflow/flow/v1"
)

// Workload function
func doSomething(data []byte, option map[string][]string) ([]byte, error) {
	return []byte(fmt.Sprintf("you said \"%s\"", string(data))), nil
}

// Define provide definition of the workflow
func DefineWorkflow(workflow *flow.Workflow, context *flow.Context) error {
    dag := workflow.Dag()
    dag.Node("test", doSomething)
    return nil
}

func main() {
    fs := &goflow.FlowService{
        Port:                8080,
        RedisURL:            "localhost:6379",
        OpenTraceUrl:        "localhost:5775",
        WorkerConcurrency:   5,
        EnableMonitoring:    true,
    }
    fs.Register("myflow", DefineWorkflow)
    fs.Start()
}

Start() runs a HTTP Server that listen on the provided Port. It also runs a flow worker that handles the workload

Run It

Start goflow stack

docker-compose up

This will start the required services

• redis
• jaeger
• dashboard

Run the Flow

go build -o goflow
./goflow

Invoke It

Using curl

curl -d hallo localhost:8080/flow/myflow

Using Client

Using the goflow client you can request the flow directly. The requests are always async and gets queued for the workers to pick up

fs := &goflow.FlowService{
    RedisURL: "localhost:6379",
}
fs.Execute("myflow", &goflow.Request{
    Body: []byte("hallo")
})

Using Dashboard

Dashboard visualize the flow and provides observability

Scale It

GoFlow scale horizontally, you can distribute the load by just adding more instances

Worker Mode

Alternatively you can start your GoFlow in worker mode. As a worker, GoFlow only handles the workload instead of running an HTTP server. If required you can only scale the workers

fs := &goflow.FlowService{
    RedisURL:            "localhost:6379",
    OpenTraceUrl:        "localhost:5775",
    WorkerConcurrency:   5,
}
fs.Register("myflow", DefineWorkflow)
fs.StartWorker()

Register Multiple Flow

Register() allows user to bind multiple flows onto single flow service. This way one instance of server/worker can be used for more than one flows

fs.Register("createUser", DefineCreateUserFlow)
fs.Register("deleteUser", DefineDeleteUserFlow)

<br />

Creating More Complex DAG

The initial example is a single vertex DAG. Single vertex DAG are great for synchronous task

Using GoFlow's DAG construct one can achieve more complex compositions with multiple vertexes and connect them using edges.

Multi Nodes

A multi-vertex flow is always asynchronous in nature where each nodes gets distributed across the workers

Below is an example of a simple multi vertex flow to validate a KYC image of a user and mark the user according to the result. This is a asynchronous flow with three steps

func DefineWorkflow(f *flow.Workflow, context *flow.Context) error {
    dag := f.Dag()
    dag.Node("get-kyc-image", getPresignedURLForImage)
    dag.Node("face-detect", detectFace)
    dag.Node("mark-profile", markProfileBasedOnStatus)
    dag.Edge("get-kyc-image", "face-detect")
    dag.Edge("face-detect", "mark-profile")
    return nil
}

Branching

Branching are great for parallelizing independent workloads in separate branches

Branching can be achieved with simple vertex and edges. GoFlow provides a special operator Aggregator to aggregate result of multiple branch on a converging node

We are extending our earlier example to include a new requirement to match the face with existing data and we are performing the operation in parallel to reduce time

func DefineWorkflow(f *flow.Workflow, context *flow.Context) error {
    dag := f.Dag()
    dag.Node("get-kyc-image", getPresignedURLForImage)
    dag.Node("face-detect", detectFace)
    dag.Node("face-match", matchFace)
    // Here mark-profile depends on the result from face-detect and face-match,
    // we are using a aggregator to create unified results
    dag.Node("mark-profile", markProfileBasedOnStatus, flow.Aggregator(func(responses map[string][]byte) ([]byte, error) {
       status := validateResults(responses["face-detect"],  responses["face-match"])
       return []byte(status), nil
    }))
    dag.Edge("get-kyc-image", "face-detect")
    dag.Edge("get-kyc-image", "face-match")
    dag.Edge("face-detect", "mark-profile")
    dag.Edge("face-match", "mark-profile")
    return nil
}

Subdag

Subdag allows to reuse existing DAG by embedding it into DAG with wider functionality

SubDag is available as a GoFlow DAG construct which takes a separate DAG as an input and composite it within a vertex, where the vertex completion depends on the embedded DAG's completion

func (currentDag *Dag) SubDag(vertex string, dag *Dag)

Say we have a separate flow that needs the same set of steps to validate a user. With our earlier example we can separate out the validation process into subdag and put it in a library that can be shared across different flows

func KycImageValidationDag() *flow.Dag {
    dag := flow.NewDag()
    dag.Node("verify-url", s3DocExists)
    dag.Node("face-detect", detectFace)
    dag.Node("face-match", matchFace)
    dag.Node("generate-result", func(data []byte, option map[string][]string) ([]byte, error) {
                 return data, nil
            },
            flow.Aggregator(func(responses map[string][]byte) ([]byte, error) {
                status := validateResults(responses["face-detect"],  responses["face-match"])
                status = "failure"
                if status {
                   status = "success"
                }
                return []byte(status), nil
            }
    ))
    dag.Edge("verify-url", "face-detect")
    dag.Edge("verify-url", "face-match")
    dag.Edge("face-detect", "generate-result")
    dag.Edge("face-match", "generate-result")
    return dag
}

Our existing flow embeds the KycImageValidation DAG

func DefineWorkflow(f *flow.Workflow, context *flow.Context) error {
    dag := f.Dag()
    dag.Node("get-image", getPresignedURLForImage)
    dag.SubDag("verify-image", common.KycImageValidationDag)
    dag.Node("mark-profile", markProfileBasedOnStatus)
    dag.Edge("get-image", "verify-image")
    dag.Edge("verify-image", "mark-profile")
    return nil
}

Conditional Branching

Conditional branching is a great way to choose different execution path dynamically

GoFlow provides a DAG component called ConditionalBranch. ConditionalBranch creates a vertex that composites different conditional branches as an individual subdags, each identified with a unique key resemble the condition

func (currentDag *Dag) ConditionalBranch(vertex string, conditions []string, condition sdk.Condition,
    options ...BranchOption) (conditiondags map[string]*Dag)

Condition is a special handler that allows user to dynamically choose one or more execution path based on the result from earlier node and return a set of condition Keys

User gets the condition branches as a response where each branch specific dags are mapped against the specific condition. User can farther define each branch using the DAG constructs

Below is the updated example with a conditional Branch where we are trying to call face-match only when face-detect passes

func KycImageValidationDag() *flow.Dag {
    dag := flow.NewDag()
    dag.Node("verify-url", s3DocExists)
    dag.Node("face-detect", detectFace)
    // here face match happen only when face-detect is success
    branches = dag.ConditionalBranch("handle-face-detect-response", []string{"pass"}, func(response []byte) []string {
        response := ParseFaceDetectResponse(response)
        if response[0] ==
