This repository contains:

• mstan, a compiler that implements a "swappable module" system for Stan. See this blog post or paper Multi-Model Probabilistic Programming for an introduction and check out the website for interactive visualizations of modular programs.
• model_search.py, a simple proof-of-concept model search for the network of models.
• mstan-server, the backend server for the Modular Stan website.

Please keep in mind that this is a research prototype. You are likely to encounter bugs and unimplemented features.

Installation

1. Install stack.

2. Make sure Graphviz is installed.

3. Run stack install. This should build mstan and mstan-server and copy them to your PATH.

4. To use model_search.py with ELPD evaluation, you'll need Rscript, python, cmdstan, and the following R dependencies: tidyverse, loo, abind, distributional, tensorA, jsonlite, data_table, cmdstanr, posterior.

   You can use nix to manage these dependencies with the nix-shell command. nix-shell will default to the appropriate environment specified by the default.nix file. You may still need to install cmdstan separately from nix.

The mstan command-line interface

You can explore mstan usage by running mstan --help:

Usage: mstan (-f|--modular-stan-file FILE) [-v|--debug-parse]
             [-o|--output-file FILE] COMMAND
  Execute model network command

Available options:
  -f,--modular-stan-file FILE
                           File path of the input modular Stan file
  -v,--debug-parse         Show parsed modular program data structure
  -o,--output-file FILE    Output file path
  -h,--help                Show this help text

Available commands:
  concrete-model           Return the concrete Stan model given a model ID
  model-graph              Produce Graphviz image and text files of the model
                           graph of the modular Stan program.
  module-graph             Produce Graphviz image and text files of the module
                           graph of the modular Stan program.
  model-neighbors          Return the model IDs of the neighbors of the given
                           model
  any-model                Return an arbitrary model ID
  list-all-models          Return all model IDs

You can also use --help for individual commands, like mstan concrete-model --help.

Model IDs

Model IDs are strings that are used to uniquely reference individual models in a network. For example, the following string is the ID of a model from the "simple" example network:

Mean:standard,Stddev:lognormal,StddevInformative:yes

Model IDs are comma-separated lists of the module selections that make up that model; in this case Mean is implemented by standard and so on.

You can also find model ID of a selected model on the website in the text box above the module tree.

Usage examples

These command-line examples will use the "simple" example modular program.

Get an arbitrary model ID:

> mstan -f examples/simple.m.stan any-model
Mean:standard,Stddev:standard

Get the concrete Stan program for the model ID Mean:standard,Stddev:standard:

> mstan -f examples/simple.m.stan concrete-model -s Mean:standard,Stddev:standard
data {
  int N;
  vector[N] x;
}
model {
  x ~ normal(0, 1);
}

Get IDs of the models that neighbor Mean:standard,Stddev:standard:

> mstan -f examples/simple.m.stan model-neighbors -s Mean:standard,Stddev:standard
Mean:normal,Stddev:standard
Mean:standard,Stddev:lognormal,StddevInformative:no
Mean:standard,Stddev:lognormal,StddevInformative:yes

Get all model IDs and write them to "models.txt":

> mstan -f examples/simple.m.stan list-all-models -o models.txt
> cat models.txt
Mean:normal,Stddev:lognormal,StddevInformative:no
Mean:normal,Stddev:lognormal,StddevInformative:yes
Mean:normal,Stddev:standard
Mean:standard,Stddev:lognormal,StddevInformative:no
Mean:standard,Stddev:lognormal,StddevInformative:yes
Mean:standard,Stddev:standard

Produce an image of the model graph:

> mstan -f examples/simple.m.stan model-graph
model_graph.svg

Produce an image of the module tree:

> mstan -f examples/simple.m.stan module-tree
module_tree.svg

Print out diagnostics and produce an image of the module tree:

> mstan -f examples/simple.m.stan module-tree -v
============== Parsed program: ===============
signatures: ...
...
============== Modular tree:     ===============
(root)
  [Mean]
    (normal)
    (standard)
  [Stddev]
    (lognormal)
      [StddevInformative]
        (no)
        (yes)
    (standard)
============== Results:      ===============
module_tree.svg

Using graph_search.py

Basic example: "Bernoulli problem"

This small modular Stan program can be found at example/bernoulli.m.stan:

data {
  int<lower=0> N;
  array[N] int<lower=0,upper=1> y; // or int<lower=0,upper=1> y[N];
}
parameters {
  real<lower=0,upper=1> theta;
}
model {
  theta ~ ThetaPrior();  // uniform prior on interval 0,1
  y ~ bernoulli(theta);
}
generated quantities {
  vector[N] log_lik;
  for (i in 1:N) {
    log_lik[i] = bernoulli_lpmf(y[i] | theta);
  }
}

module "informative" ThetaPrior(theta) {
  // Bias theta towards zero
  theta ~ beta(1, 4);
}
module "uninformative" ThetaPrior(theta) {
  theta ~ beta(1, 1);
}

To run a greedy ELPD-maximizing graph search, from the project root directory run python graph_search.py examples/bernoulli.m.stan examples/bernoulli_data.json.

The first argument to graph_search.py is the modular stan file and the second is input data.

Running the "Birthday" example

My translation of the birthday case study into a modular Stan program for can be found at: examples/birthday/birthday.m.stan.

The data for the birthday problem has been pre-processed. You can replicate the pre-processing by running Rscript prepare_birthday_data.R inside examples/birthday. This converts the original .csv file into a .json file and adds all of the extra information expected by the Stan models (e.g. holidays).

There is also a simpler translation of the birthday problem at examples/birthday/birthday-trivial-translation.m.stan To run the graph search on this trivial example, execute python graph_search.py examples/birthday/birthday-trivial-translation.m.stan examples/birthday/births_usa_1969.json.

Here are example results:

Visiting:
	Model ID:	 Model:model1
	Score:		 6718.1204643854
	Push neighbor:	 Model:model2 5298.35671164131
	Push neighbor:	 Model:model3 13127.6477332358
	Push neighbor:	 Model:model4 13586.8301927714
	Push neighbor:	 Model:model5 -167840.2708031
	Push neighbor:	 Model:model6 13973.7607351042
	Push neighbor:	 Model:model7 10402.3775114932
	Push neighbor:	 Model:model8 15306.1033233817
	Push neighbor:	 Model:model8rhs 15391.7673968433
Visiting:
	Model ID:	 Model:model8rhs
	Score:		 15391.7673968433
Visiting:
	Model ID:	 Model:model8
	Score:		 15306.1033233817

Winner:
	Model ID:	 Model:model8rhs
	Score:		 15391.7673968433

9 scores
2 expands

The search selected the model with ID Model:model8rhs. To get the concrete Stan program with this ID, run mstan exec -f examples/birthday/birthday-trivial-translation.m.stan get-model -s Model:model8rhs.

Troubleshooting

• To see the command line calls that are being made to elpd.R and mstan, set DEBUG_IO in graph_search.py to True
