Puck.js Modules and Examples

A set of pretty APIs for some features of Puck.js.

Modules:

• :radio_button: Button
• :bulb: Lights
• :wave: Proximity
• :arrows_counterclockwise: Scroll Wheel

Examples:

• :sound: Volume/Play/Pause

Modules

:radio_button: Button

Button.on("double", ()=>console.log("I got double clicked!"));

Emits events for button presses:

• up, down - for push and release
• press - single presses
• long - long press
• double - double press
• multi - multi-press sequence, passing an argument with the number of presses

:bulb: Lights [WIP]

Lights.pulsing().color(Lights.BLUE).when(Button, "down").until(Button, "up");
Lights.blip(Lights.CYAN, 500);

Simple API for controlling the LEDs. (Currently WIP - started hitting performance limits of the board, so optimizations underway, but generally works.)

Each call adds a program to a stack. For example, the following will result in a steady red color for five seconds, with a blue light blinking at the same time.

Lights.steady().color(Lights.RED).for(5000).now();
Lights.blinking().color(Lights.BLUE).for(5000).now();

Each program must have a brightness, color, start, and end function.

Shorthand function

• blip(color,duration): same as Lights.steady().color(color).now().for(duration)

Brightness functions

• steady(): constant 100% brightness
• pulsing(speed, lower_bound): sinusoidal pulsing effect, with a adjustable speed (default 1s per cycle) and lower bound (default 0%)
• blinking(speed, lower_bound): simple blinking (high-low-high-low...) effect, with a adjustable speed (default 1s per cycle) and lower bound (default 0%)

Color function

• color(clr): single color, as an array of [R, G, B] as values from <0,1>, or constants defined on Lights (BLACK, RED, GREEN, BLUE, CYAN, MAGENTA, YELLOW)

More color functions

More functions are available in a separate LightsExtra module.

var Lights = require("https://raw.githubusercontent.com/rsmeral/puck.js/master/modules/Lights.js")();
require("https://raw.githubusercontent.com/rsmeral/puck.js/master/modules/LightsExtra.js")(Lights);

Lights.steady().rainbow(0.5).now().for(5000);

• rainbow(speed): cycle through the color spectrum, with a adjustable speed (default 1s per cycle)
• pearly(axis,transition): (Experimental) Emulates a pearlescent effect by changing colors based on device rotation

Start functions

• now(): start immediately
• after(ms): start after given number of milliseconds
• when(object,event): triggered by the given event (string) emitted by the given object

End functions

• for(ms): stop after given number of milliseconds
• until(object,event): stops when the given event (string) is emitted by the given object

:wave: Proximity

Prox.on("near", ()=>console.log("Light suddenly obstructed - some object most likely got close to me."));
Prox.on("far", ()=>console.log("Ahh, light back on - obstruction removed."));

Emulates a proximity sensor by using the light sensor. Continuously adapts to lighting conditions. (Obvious caveat - doesn't work well in dimly lit environments).

Emits two events:

• near - when an object approaches
• far - when an object moves away

:arrows_counterclockwise: Scroll Wheel

Knob.on("plus", ()=>hid.volumeUp());
Knob.on("minus", ()=>hid.volumeDown());
Knob.start();

Emulates an incremental rotary encoder (scroll wheel) using magnetometer readings. The number of notches per circle is configurable. Works horizontally and vertically (or in any other plane).

Needs calibration - during 4 seconds after calling start(), rotate the Puck 360 degrees in a single plane to make at least one full circle. If Puck is moved after calibration, it will most likely need re-calibration (stop();start()).

Emits events when Puck is rotated:

• plus - clockwise
• minus - counterclockwise
• notch - both directions, passing an argument with the number of the current notch (for detecting absolute rotation - like compass).

Also emits an event when calibration finishes:

• calibrated

Examples

:sound: Volume/Play/Pause

Rotating the Puck like a knob changes volume, pressing the button issues a Play/Pause event. Works on Mac, Linux, Android.

Demonstrates four modules: Button, Lights, Proximity, Scroll Wheel. After uploading, rotation needs to be calibrated, see Scroll Wheel.

The experimental POWER_SAVE switch, if enabled, stops the rotation detection (which consumes battery) if your hand is not near the Puck, and starts it up again when Puck is mostly covered by a hand. In power-save mode, consumption should be very low - only 2 light sensor readings per second as opposed to 10 magnetometer reading and processing cycles.
