VIBESegmentator:  Full Body MRI Segmentation for the NAKO and UK Biobank

Versions

You can select older versions with --dataset_id [ID]

|ID | NAME | Version |Modality | Resolution |Link| |--- | ---------------- | ------------------------------|-------- | --------------------|----| |100 |VIBESegmentator | current | MRI/CT | axial 1.41 mm, S=3mm|preprint| |99 |VIBESegmentator | current (sagittal resolution) | MRI/CT | sagittal 1.41 mm, R=3mm|preprint| |278 |Splits the body in 11 regions |current | NAKO VIBE-only| iso 4 mm | | |282 |Torso Water-Fat-swap detection|current (use script from linked repo) | multi-echo-Vibe VIBE | axial 1.41 mm, S=3mm|preprint; Other Repo| |511 |Spine Vertebra instance |Fast, but may produce off-by-one errors. Use SPINEPS if this method fails.| VIBE-only | axial 1.41 mm, S=3mm|See also | |512 |Spine Vertebra subregion |incorporated in SPINEPS | VIBE-only | axial 1.41 mm, S=3mm|See also | |520 | CT Bone segmentations | preliminary | CT | iso 0.8 mm | |

Outdated/deprecated

|ID | NAME | Version |Modality | Resolution |Link| |--- | ---------------- | ------------------------------|-------- | --------------------|----| |98 |VIBESegmentator| (deprecated-spinal channel bugged in CT)| MRI| axial 1.41 mm, S=3mm| | |80 |VIBESegmentator | preprint (deprecated)| MRI | axial 1.41 mm, S=3mm| | |85-87|VIBESegmentator | early preprint (deprecated) | MRI | axial 1.41 mm, S=3mm| |

Installation Guide

System Requirements

• Python 3.10 or higher.
• Tested on Ubuntu and Windows.
• One of the following:
  • Nvidia-GPU with 4 GB of RAM or more.
  • A mps device (like a newer Mac with M2/M3 , but we could not test this.) (--ddevice mps)
  • A strong CPU (--ddevice cpu)

Installation Guide

1. Open a command line (search for Terminal on Mac or cmd on Windows in your OS search).
2. Ensure you have Anaconda (Python) installed.
3. Navigate to the folder where you want to download the script using cd [FOLDER PATH].

# Run this commands by coping in to the Terminal
# Recommended: make a virtual Python environment (example shows Anaconda)
conda create -n "VIBESegmentator" python=3.11.0
conda activate VIBESegmentator

# Install PyTorch that works with your GPU (follow instructions at https://pytorch.org/get-started/locally/)
pip install torch torchvision torchaudio

# Install required Python packages
pip install TPTBox ruamel.yaml configargparse
pip install nnunetv2
# We recommend the newest versions. Tested versions: TPTBox==1.6, ruamel.yaml==0.18.6, configargparse==1.7, nnunetv2==2.4.2

# If e. g. nnunetv2 does not work, try version 2.4.2
# Uninstall the current version and reinstall with the specified version
#pip uninstall nnunetv2
#pip install nnunetv2==2.4.2

# Download the scripts (they will be downloaded to your current folder)
git clone https://github.com/robert-graf/VIBESegmentator.git
cd VIBESegmentator

It should take less than 30 minutes to install, excluding installing conda/python. The longest time takes to install pytroch.

Download

Download the nnUNet weights automatically. They are put in [Path to this project]/nnUNet/nnUNet_results/.

Run

# Run this commands in a Terminal where you navigate to the folder where `run_VIBESegmentator.py` is
conda activate VIBESegmentator

# Total Segmentation
python run_VIBESegmentator.py --img [IMAGE-PATH] --out_path [OUTPATH] --ddevice [cpu|cuda|mpu (optional)]

# Total Segmentation with postprocessing and combining of masks
python run_VIBESegmentator_multi.py --img_inphase [IMAGE-PATH] --img_water [IMAGE-PATH] --img_outphase [IMAGE-PATH]  --out_path [OUTPATH] --ddevice [cpu|cuda|mpu (optional)]

# Spine Instance
python run_instance_spine_segmentation.py --img [IMAGE-PATH] --out_path [OUTPATH] --ddevice [cpu|cuda|mpu (optional)]

# Spine Semantic
python run_semantic_spine_segmentation.py --img [IMAGE-PATH] --out_path [OUTPATH] --ddevice [cpu|cuda|mpu (optional)]

Running an Example

conda activate VIBESegmentator
#cd to the folder where you downloaded the GitHub files (the folder where the run_VIBESegmentator.py is located)

Let's run some examples that were never seen during training. You can download all four examples from here

(Source: link Number s0284, s0286, s0287, s0288)

Unzip the file. For this example, we copied all files to a folder called 'example' where the run_VIBESegmentator.py is located.

python run_VIBESegmentator.py --img example/mri1.nii.gz --out_path  example/seg1.nii.gz

python run_VIBESegmentator.py --img example/mri2.nii.gz --out_path  example/seg2.nii.gz

python run_VIBESegmentator.py --img example/mri3.nii.gz --out_path  example/seg3.nii.gz

python run_VIBESegmentator.py --img example/mri4.nii.gz --out_path  example/seg4.nii.gz

The segmentation is stored in "example/segX.nii.gz." You can view the results with ITKSnap by first drag-and-drop the mriX.nii.gz and then drag-and-drop the segX.nii.gz (with X is a number from before) and click on "Open as Segmentation"

To run this script on your data, update the paths.

Label overview

|ID | NAME| | -------- | --------| |1|spleen| |2|kidney_right| |3|kidney_left| |4|gallbladder| |5|liver| |6|stomach| |7|pancreas| |8|adrenal_gland_right| |9|adrenal_gland_left| |10|lung_upper_lobe_left| |11|lung_lower_lobe_left| |12|lung_upper_lobe_right| |13|lung_middle_lobe_right| |14|lung_lower_lobe_right| |15|esophagus| |16|trachea| |17|thyroid_gland| |18|intestine| |19|duodenum| |20|unused| |21|urinary_bladder| |22|prostate| |23|sacrum| |24|heart| |25|aorta| |26|pulmonary_vein| |27|brachiocephalic_trunk| |28|subclavian_artery_right| |29|subclavian_artery_left| |30|common_carotid_artery_right| |31|common_carotid_artery_left| |32|brachiocephalic_vein_left| |33|brachiocephalic_vein_right| |34|atrial_appendage_left| |35|superior_vena_cava| |36|inferior_vena_cava| |37|portal_vein_and_splenic_vein| |38|iliac_artery_left| |39|iliac_artery_right| |40|iliac_vena_left| |41|iliac_vena_right| |42|humerus_left| |43|humerus_right| |44|scapula_left| |45|scapula_right| |46|clavicula_left| |47|clavicula_right| |48|femur_left| |49|femur_right| |50|hip_left| |51|hip_right| |52|spinal_cord| |53|gluteus_maximus_left| |54|gluteus_maximus_right| |55|gluteus_medius_left| |56|gluteus_medius_right| |57|gluteus_minimus_left| |58|gluteus_minimus_right| |59|autochthon_left| |60|autochthon_right| |61|iliopsoas_left| |62|iliopsoas_right| |63|sternum| |64|costal_cartilages| |65|subcutaneous_fat| |66|muscle| |67|inner_fat| |68|IVD| |69|vertebra_body| |70|vertebra_posterior_elements| |71|spinal_channel| |72|bone_other|

How to Cite

Open access paper: doi:10.1007/s00330-025-12035-9

The related paper is available as preprint: arXiv:2406.00125

@article{graf2025vibesegmentator,
  title={VIBESegmentator: full body MRI segmentation for the NAKO and UK Biobank},
  author={Graf, Robert and Platzek, Paul and Riedel, Evamaria Olga and Ramsch{\"u}tz, Constanze and Starck, Sophie and M{\"o}ller, Hendrik K and Atad, Matan and V{\"o}lzke, Henry and B{\"u}low, Robin and Schmidt, Carsten Oliver and others},
  journal={European Radiology},
  pages={1--15},
  year={2025},
  publisher={Springer}
}

Other networks

run_VIBESegmentator.py [...] --dataset_id 278
