Mapgen2

[[http://unmaintained.tech/][http://unmaintained.tech/badge.svg]]

JavaScript version of my [[https://github.com/amitp/mapgen2/][Polygon Map Generator]].

• The algorithms mostly follow [[http://www-cs-students.stanford.edu/~amitp/game-programming/polygon-map-generation/][my article about polygon map generation]]..
• The data structures are rather different from the original ActionScript 3 code.
  • The mesh connectivity (voronoi, triangles, edges, points) is stored in the =Mesh= structure.
  • The generated map (elevation, rivers, biomes, etc.) is stored in the =WorldMap= structure.
  • The original project uses an “array of struct” approach; this one uses a “[[https://en.wikipedia.org/wiki/AOS_and_SOA][struct of arrays]]” approach.
• The naming convention for the data is =x_property_y= where =x= and =y= are =r=, =s=, or =t= indicating the type of the output (=x=) and input (=y=). For example, =s_downslope_t= would be an array indexed by a =t= (triangle) id, and returning an =s= (side) id.
• The maps are created with coordinates 0 ≤ x ≤ 1000, 0 ≤ y ≤ 1000.

This repository contains the map generation algorithms and also the code for UI and rendering.

** Example

There are several steps to generate a map:

1. Choose /points/, either a [[https://www.redblobgames.com/x/1830-jittered-grid/][jittered grid]] or blue noise (poisson disc) or some other pattern.
2. Add [[https://www.redblobgames.com/x/2312-dual-mesh/#boundary][boundary points]] around the edges of the map
3. Turn the points into triangles and voronoi cells using [[https://github.com/mapbox/delaunator][Delaunator]].
4. Use my [[https://www.redblobgames.com/x/2312-dual-mesh/][dual-mesh library]] to complete and wrap the mesh structure with [[https://www.redblobgames.com/x/2312-dual-mesh/#ghosts]["ghost" elements]].
5. Use the =WorldMap= generator to assign elevation, rivers, and biomes.

#+begin_src js import SimplexNoise from 'simplex-noise'; import Delaunator from 'delaunator'; import Poisson from 'poisson-disk-sampling'; import {makeRandInt} from '@redblobgames/prng';

import {TriangleMesh} from "./dual-mesh/dist/index.js"; import {generateInteriorBoundaryPoints} from "./dual-mesh/dist/create.js"; import {WorldMap} from './map.js';

const bounds = {left: 0, top: 0, width: 1000, height: 1000}; const spacing = 100; let points = generateInteriorBoundaryPoints(bounds, spacing); let numBoundaryPoints = points.length; let generator = new Poisson({ shape: [bounds.width, bounds.height], minDistance: spacing / Math.sqrt(2), }); for (let p of points) { generator.addPoint(p); } points = generator.fill(); let init = {points, delaunator: Delaunator.from(points), numBoundaryPoints}; init = TriangleMesh.addGhostStructure(init); let mesh = new TriangleMesh(init);

let map = new WorldMap(mesh, { amplitude: 0.2, length: 4, seed: 12345 }, makeRandInt, );

map.calculate({ noise: new SimplexNoise(), shape: {round: 0.5, inflate: 0.4, amplitudes: [1/2, 1/4, 1/8, 1/16]}, numRivers: 30, drainageSeed: 0, riverSeed: 0, noisyEdge: {length: 10, amplitude: 0.2, seed: 0}, biomeBias: {north_temperature: 0, south_temperature: 0, moisture: 0}, }); #+end_src

The previous version of this library wrapped up all these steps in a convenient function. However, I used that in real projects and found it was limiting. The current version makes the caller run all the steps so that they can all be swapped out (boundary points are optional, Poisson disc is optional, ghost elements are optional, noise function can be changed, random number sequence can be changed).

The library supports seeded random numbers with my =makeRandInt= / =makeRandFloat= functions. If you don't care about seeds, you can use the built-in random number function instead:

#+begin_src js function makeRandInt (_ignoreSeed) { return N => Math.round(Math.random() * N); } #+end_src

You can pass in your own noise function instead of using the =SimplexNoise= library:

#+begin_src js noise: {noise2D(nx, ny) { return … }} #+end_src

However, the code as written doesn't have a way to pass in your own height map or a water/land assignment function. You can modify the =assign_r_water= function if you want to use your own water/land shape.

** Output

If your project needs polygon data:

#+begin_src js let polygons = []; for (let r = 0; r < map.mesh.numSolidRegions; r++) { polygons.push({ biome: map.r[r_biome], vertices: map.mesh.r_around_t(r) .map((t) => map.pos_of_t(t)) }); } #+end_src

If you want the noisy edges instead, see =map.lines_s[s]= for the line segments that should be used instead of side =s=.

If your project needs the polygons split into triangles:

#+begin_src js let triangles = []; for (let s = 0; s < map.mesh.numSolidSides; s++) { let r = map.mesh.r_begin_s(s), t1 = map.mesh.t_inner_s(s), t2 = map.mesh.t_outer_s(s); triangles.push({ biome: map.biome_r[r], indices: [ map.pos_of_r(r), map.pos_of_t(t1), map.pos_of_t(t2), ] }); } #+end_src

If your game needs the polygons split into tiles, use a polygon rasterization library like [[https://github.com/rastapasta/points-in-polygon][points-in-polygon]] to get a list of /tiles/ for each polygon. I have not tried this yet. The default coordinate space is 0 ≤ x ≤ 1000, 0 ≤ y ≤ 1000. Scale this up or down to your desired tile map size before rasterizing.
