XCoder

No Longer Maintained

Unfortuantely, I just don't have the time to maintain Xcoder, and given there are so many other tools that do bits and peices of what xcoder does, it doesnt feel as needed any more.

Perhaps parts of xcoder (keychain, profile management) could be extracted into stand-along tools - take a more unix-y approach to managing tools.

If anyone wants to more actively maintain Xcoder, please contact me.

Description

Taking the pain out of scripting and automating xcode builds.

Xcoder is a ruby wrapper around various Xcode tools as well as providing project and workspace parsing and partial write support. Xcoder also supports manipulation of keychains, packaging and uploading artifacts to Testflight and provisioning profile management.

Full documentation can be found here: http://rayh.github.com/xcoder/

Requirements

Xcoder assumes you are using XCode 4.6 on Mountain Lion and ruby 1.9. You may have some degree of success with lesser versions, but they are not intentionally supported.

Example Usage

You will need to install the gem:

gem install xcoder

and then require the gem in your project/rakefile/etc

require 'xcoder'

Load a project

project = Xcode.project('MyProject')  # Can be the name, the file (e.g. MyProject.xcodeproj) or the path

Finding all projects from the current directory down

Xcode.find_projects.each {|p| puts p.name }

Find a configuration for a target on a project

config = Xcode.project(:MyProject).target(:Target).config(:Debug)	# returns an Xcode::Configuration object

Building a configuration

config = Xcode.project(:MyProject).target(:Target).config(:Debug)
builder = config.builder
builder.profile = 'Profiles/MyAdHoc.mobileprovision'	# This will remove old profiles and install the profile
builder.identity = 'iPhone Developer: Ray Hilton'		# The name of the identity to use to sign the IPA (optional)
builder.clean
builder.build
# Building uses the targets's default sdk, which you can override:
builder.build :sdk => :iphonesimulator

Working with Keychains

You will not normally need to worry about manipulating keychains unless you want to automate importing of certificates (in a CI system with many clients) or opening of specific keychains for different builds (the old two-certs-with-same-identity-name workaround).

You can either use the user's login keychain, another named keychain, or simply use a temporary keychain that will be blown away after the build.

Creating a temporary keychain

Xcode::Keychain.temp do |keychain|
	# import certs into the keychain
	# perform builds within this keychain's context
end	# Keychain is deleted

Or, you can create a temporary keychain that will be deleted when the process exits:

keychain = Xcode::Keychain.temp

Importing a certificate

You can import a certificate from a .p12 file into a keychain. Here we simply create a temporary keychain, import a certificate, set the identity onto the builder and then perform a build.

keychain.import 'Certs/MyCert.p12', 'mycertpassword'
builder.keychain = keychain						# Tell the builder to use the temp keychain
builder.identity = keychain.identities.first	# Get the first (only) identity name from the keychain

Packaging a built .app

After performing the above build, you can create a versioned, well named .ipa and .dSYM.zip

builder.package

This will produce something like: MyProject-Debug-1.0.ipa and MyProject-Debug-1.0.dSYM.zip

Incrementing the build number

config.info_plist do |info|
  info.version = info.version.to_i + 1
  info.save
end

Managing build numbers more efficiently

Based on our experience we suggest Versionomy to manage version numbers. Although the marketing version is usually set by hand on release, there are situations where it could be nice to have an incremental build number in the marketing version number as well. The following is an example that takes a marketing version number in the x.y.z format and increments the last part of it.

config.info_plist do |info|
  info.version = info.version.to_i + 1
  marketing_version = Versionomy.parse(info.marketing_version)
  info.marketing_version = marketing_version.bump(:tiny).to_s
  info.save
end

You can read more about Versionomy at their site

Working with workspaces

Loading workspaces can be done in a similar way to projects:

Xcode.workspaces.each do |w|
  w.describe								# prints a recursive description of the
											# structure of the workspace and its projects
end

Or, if you know the name:

workspace = Xcode.workspace('MyWorkspace')  # Can be the name, the file (e.g. MyWorkspace.xcworkspace) or the path

Schemes

There is basic support for schemes, you can enumerate them from a project like so:

project.schemes.each do |s|
  s.builder.build
end

Or, access them by name:

builder = project.scheme('MyScheme').builder

Note: The builder behaves the same as the builder for the target/config approach and will force xcodebuild to use the local build/ directory (as per xcode3) rather than a generated temporary directory in DerivedData. This may or may not be a good thing.

Note: Shared schemes and user (current logged in user) specific schemes are both loaded. They may share names and other similarities that make them hard to distinguish. Currently the priority loading order is shared schemes and then user specific schemes.

Provisioning profiles

The library provides a mechanism to install/uninstall a provisioning profile. This normally happens as part of a build (if a profile is provided to the builder, see above), but you can do this manually:

# installs profile into ~/Library
Xcode::ProvisioningProfile.new("Myprofile.mobileprovision").install

Or enumerate installed profiles:

Xcode::ProvisioningProfile.installed_profiles.each do |p|
	p.uninstall		# Removes the profile from ~/Library/
end

Deployment

Testflight

The common output of this build/package process is to upload to Testflight. This is pretty simple with Xcoder:

# Optionally do this, saves doing it again and again
Xcode::Deploy::Testflight.defaults :api_token => 'some api token', :team_token => 'team token'

builder.deploy :testflight,
	:api_token 	=> API_TOKEN,
	:team_token => TEAM_TOKEN,
	:notes 		=> "some release notes",
  	:notify 	=> true,		# Whether to send a notification to users, default is true
  	:lists 		=> ["AList"]  	# The lists to distribute the build to

You can also optionally set the HTTP_PROXY environment variable.

Deploying to Amazon S3

You can upload the output ipa to an arbitrary buckey on S3

builder.deploy :s3,
	:bucket => "mybucket",
	:access_key_id => "access id",
	:secret_access_key => "access key",
	:dir => "options/path/within/bucket"

Deploying to a web server (SSH)

The output of the build/package process can be deployed to a remote web server. You can use SSH with the following syntax:

builder.deploy :ssh,
	:host => "mywebserver.com",
	:username => "myusername",
	:password => "mypassword",
	:dir => "/var/www/mywebserverpath",
	:base_url => "http://mywebserver.com/"

Deploying to a web server (FTP)

The output of the build/package process can be deployed to a remote web server. You can upload the files through FTP with the following syntax:

builder.deploy :ftp,
	:host => "ftp.mywebserver.com",
	:username => "myusername",
	:password => "mypassword",
	:dir => "/mywebserverpath",
	:base_url => "http://mywebserver.com/"

OCUnit to JUnit reports

You can invoke your test target/bundle from the builder

builder.test do |report|
	report.debug = false	# default false, set to true to see raw output from xcodebuild

	# The following is the default setup, you wouldnt normally need to do this unless
	# you want to add new formatters
	report.formatters = []
	report.add_formatter :junit, 'test-reports'	# Output JUnit format results to test-reports/
	report.add_formatter :stdout				# Output a simplified output to STDOUT
end

This will invoke the test target, capture the output and write the junit reports to the test-reports directory. Currently only junit is supported, although you can write your own formatter quite easily (for an example, look at Xcode::Test::Formatters::JunitFormatter).

Rake Tasks

Xcoder provides a rake task to assist with make it easier to perform common Xcode project actions from the command-line.

Within your Rakefile add the following:

require 'xcoder/rake_task'

Then define your Rake Task:

Xcode::RakeTask.new

By default this will generate rake tasks within the 'xcode' namespace for all the projects (within the current working directory), all their targets, and all their configs. This will also generate tasks for all of a projects schemes as well.

All names from the project, schemes, targets, and configs are remove
the camel-casing and replacing the cameling with underscores. Spaces
are replaced with dashes (-)

This will generate rake tasks that appear similar to the following:

  rake xcode:project-name:targetname:debug:build
  rake xcode:project-name:targetname:debug:clean
  # ...

You can specify a parameter to change the root rake namespace:

 Xcode::RakeTask.new :apple

 # Resulting Rake Tasks:
 # rake apple:project-name:targetname:debug:build
 # rake apple:project-name:targetname:debug:clean
 # ...

You can also supply a block to provide additional configuration to specify the folder to search for projects and the projects that should generate tasks for:

 Xcode::RakeTask.new :hudson do |xcoder|
   xcoder.directory = "projects"
   xcoder.projects = [ "Project Alpha", "Project Beta" ]
 end

 rake hudson:project-alpha:targetname:debug:build
 # ...
