rBoot - An open source boot loader for the ESP8266

by Richard A Burton, richardaburton@gmail.com http://richard.burtons.org/

rBoot is designed to be a flexible open source boot loader, a replacement for the binary blob supplied with the SDK. It has the following advantages over the Espressif loader:

Open source (written in C).
Supports up to 256 roms.
Roms can be variable size.
Able to test multiple roms to find a valid backup (without resetting).
Flash layout can be changed on the fly (with care and appropriately linked rom images).
GPIO support for rom selection.
Wastes no stack space (SDK boot loader uses 144 bytes).
Documented config structure to allow easy editing from user code.
Can validate .irom0.text section with checksum.
Temporary next-boot rom selection.

Limitations

The ESP8266 can only map 8Mbits (1MB) of flash to memory, but which 8Mbits to map is selectable. This allows individual roms to be up to 1MB in size, so long as they do not straddle an 8Mbit boundary on the flash. This means you could have four 1MB roms or 8 512KB roms on a 32Mbit flash (such as on the ESP-12), or a combination. Note, however, that you could not have, for example, a 512KB rom followed immediately by a 1MB rom because the 2nd rom would then straddle an 8MBit boundary. By default support for using more than the first 8Mbit of the flash is disabled, because it requires several steps to get it working. See below for instructions.

Building

A Makefile is included, which should work with the gcc xtensa cross compiler. There are two source files, the first is compiled and included as data in the second. When run this code is copied to memory and executed (there is a good reason for this, see my blog for an explanation). The make file will handle this for you, but you'll need my esptool2 (see github).

To use the Makefile set SDK_BASE to point to the root of the Espressif SDK and either set XTENSA_BINDIR to the gcc xtensa bin directory or include it in your PATH. These can be set as environment variables or by editing the Makefile.

Two small assembler stub functions allow the bootloader to launch the user code without reserving any space on the stack (while the SDK boot loader uses 144 bytes). This compiles fine with GCC, but if you use another compiler and it will not compile/work for you then uncomment the #define BOOT_NO_ASM in rboot.h to use a C version of these functions (this uses 32 bytes).

Tested with SDK v2.2 and GCC v4.8.5.

Installation

Simply write rboot.bin to the first sector of the flash. Remember to set your flash size correctly with your chosen flash tool (e.g. for esptool.py use the -fs option). When run rBoot will create it's own config at the start of sector two for a simple two rom system. You can can then write your two roms to flash addresses 0x2000 and (half chip size + 0x2000). E.g. for 8Mbit flash: esptool.py write_flash -fs 8m 0x0000 rboot.bin 0x2000 user1.bin 0x82000 user2.bin

Note: your device may need other options specified. E.g. The nodemcu devkit v1.0 (commonly, but incorrectly, sold as v2) also needs the -fm dio option.

For more interesting rom layouts you'll need to write an rBoot config sector manually, see next step.

The two testload bin files can be flashed in place of normal user roms for testing rBoot. You do not need these for normal use.

rBoot Config

typedef struct {
	uint8_t magic;           // our magic
	uint8_t version;         // config struct version
	uint8_t mode;            // boot loader mode
	uint8_t current_rom;     // currently selected rom
	uint8_t gpio_rom;        // rom to use for gpio boot
	uint8_t count;           // number of roms in use
	uint8_t unused[2];       // padding
	uint32_t roms[MAX_ROMS]; // flash addresses of the roms
#ifdef BOOT_CONFIG_CHKSUM
	uint8_t chksum;          // boot config chksum
#endif
} rboot_config;

Write a config structure as above to address 0x1000 on the flash. If you want more than 4 roms (default) just increase MAX_ROMS when you compile rBoot. Think about how you intend to layout your flash before you start! Rom addresses must be sector aligned i.e start on a multiple of 4096.

magic should have value 0xe1 (defined as BOOT_CONFIG_MAGIC).
version is used in case the config structure changes after deployment. It is defined as 0x01 (BOOT_CONFIG_VERSION). I don't intend to increase this, but you should if you choose to reflash the bootloader after deployment and the config structure has changed.
mode can be 0x00 (MODE_STANDARD) or 0x01 (MODE_GPIO_ROM). See below for an explanation of MODE_GPIO_ROM. There is also an optional extra mode flag 0x04 (MODE_GPIO_ERASES_SDKCONFIG), see below for details.
current_rom is the rom to boot, numbered 0 to count-1.
gpio_rom is the rom to boot when the GPIO is triggered at boot.
count is the number of roms available (may be less than MAX_ROMS, but not more).
unused[2] is padding so the uint32_t rom addresses are 4 bytes aligned.
roms is the array of flash address for the roms. The default generated config will contain two entries: 0x00002000 and 0x00082000.
chksum (if enabled, not by deafult) should be the xor of 0xef followed by each of the bytes of the config structure up to (but obviously not including) the chksum byte itself.

Default config

A default config sector will be created on boot if one does not exists, or if an existing config is corrupted, and the default rom will be set to rom 0. If you want to have a very customised config for which the default would not be suitable, you can override the implementation in the rboot.h header file. See the comments and example code in rboot.h for more information.

GPIO boot mode

If rBoot is compiled with BOOT_GPIO_ENABLED set in rboot.h (or RBOOT_GPIO_ENABLED set in the Makefile), then GPIO boot functionality will be included in the rBoot binary. The feature can then be enabled by setting the rboot_config mode field to MODE_GPIO_ROM. You must also set gpio_rom in the config to indicate which rom to boot when the GPIO is activated at boot.

If the GPIO input pin reads high at boot then rBoot will start the currently selected normal or temp rom (as appropriate). However if the GPIO is pulled low then the rom indicated in config option gpio_rom is started instead.

The default GPIO is 16, but this can be overriden in the Makefile (RBOOT_GPIO_NUMBER) or rboot.h (BOOT_GPIO_NUM). If GPIOs other than 16 are used, the internal pullup resistor is enabled before the pin is read and disabled immediately afterwards. For pins that default on reset to configuration other than GPIO input, the pin mode is changed to input when reading but changed back before rboot continues.

After a GPIO boot the current_rom field will be updated in the config, so the GPIO booted rom should change this again if required.

GPIO boot skip mode

If rBoot is compiled with BOOT_GPIO_SKIP_ENABLED set in rboot.h (or RBOOT_GPIO_SKIP_ENABLED set in the Makefile), then a GPIO can be used to skip to the next rom at boot. The feature must then be enabled by setting the rboot_config 'mode' field to MODE_GPIO_SKIP. This means you do not need to have a dedicated GPIO boot rom. If you have a rom that is technically good (valid checksum, etc.) but has operational problems, e.g. wifi doesn't work or it crashes on boot, rBoot will not be able to detect that and switch rom automatically. In this scenario rebooting the device while pulling the GPIO low will force rBoot to skip this rom and try the next one instead. In a simple two rom setup this simply toggles booting of the other rom.

RBOOT_GPIO_SKIP_ENABLED and RBOOT_GPIO_ENABLED cannot be used at the same time. BOOT_GPIO_NUM is used to select the GPIO pin, as with RBOOT_GPIO_ENABLED.

Erasing SDK configuration on GPIO boot (rom or skip mode)

If you set the MODE_GPIO_ERASES_SDKCONFIG flag in the configuration like this: conf.mode = MODE_GPIO_ROM|MODE_GPIO_ERASES_SDKCONFIG; then a GPIO boot will also the erase the Espressif SDK persistent settings store in the final 16KB of flash. This includes removing calibration constants, saved SSIDs, etc.

Note that MODE_GPIO_ERASES_SDKCONFIG is a flag, so it has to be set as well as MODE_GPIO_ROM to take effect.

Linking user code

Each rom will need to be linked with an appropriate linker file, specifying where it will reside on the flash. If you are only flashing one rom to multiple places on the flash it must be linked multiple times to produce the set of rom images. This is the same as with the SDK loader.

Because there are endless possibilities for layout with this loader I don't supply sample linker files. Instead I'll tell you how to make them.

For each rom slot on the flash take a copy of the eagle.app.v6.ld linker script from the sdk. You then need to modify just one line in it for each rom: irom0_0_seg : org = 0x40240000, len = 0x3C000

Change the org address to be 0x40200000 (base memory mapped location of the flash) + flash address + 0x10 (offset of data after the header). The logical place for your first rom is the third sector, address 0x2000. 0x40200000 + 0x2000 + 0x10 = 0x40202010 If you use the default generated config the loader will expect to find the second rom at flash address half-chip-size + 0x2000 (e.g. 0x82000 on an 8MBit flash) so the irom0_0_seg should be: 0x40200000 + 0x82000 + 0x10 = 0x40282010 Due to the limitation of mapped flash (max 8MBit) if you use a larger chip and do not have big flash support enabled the second rom in the default config will still
