TacDiffusion: Force-domain Diffusion Policy for Precise Tactile Manipulation

Overview

This repository is the official implementation of the paper TacDiffusion: Force-domain Diffusion Policy for Precise Tactile Manipulation by Wu et al. (full citation below).

In this work, we present a novel framework leveraging diffusion models to generate 6D wrench for tactile manipulation in high-precision robotic assembly tasks. Our approach, being the first force-domain diffusion policy, demonstrated excellent improved zero-shot transferability compared to prior work, by achieving an overall 95.7% success rate in zero-shot transfer in experimental evaluations. Additionally, we investigate the trade-off between accuracy and inference speed and provide a practical guideline for optimal model selection. Further, we address the frequency misalignment between the diffusion policy and the real-time control loop with a dynamic system-based filter, significantly improving the task success rate by 9.15%. Extensive experimental studies in our work underscore the effectiveness of our framework in real-world settings, showcasing a promising approach tackling high-precision tactile manipulation by learning diffusion-based transferable skills from expert policies containing primitive-switching logic.

Installation

The code was tested on Pop!_OS 22.04 LTS, which is equivalent to Ubuntu 22.04 LTS, with Anaconda Python 3.9 and PyTorch 2.3.1. Higher versions should be possible with some accuracy difference. NVIDIA GPUs are needed for both training and testing.

Clone this repo:

TacDiffusion_ROOT=/path/to/clone/TacDiffusion
git clone https://github.com/popnut123/TacDiffusion.git $TacDiffusion_ROOT

Create an Anaconda environment or create your own virtual environment

conda create -n TacDiffusion python=3.9
conda activate TacDiffusion
pip install -r requirements.txt
conda install -c conda-forge eigenpy

Prepare training/testing data

All training and testing data should be stored under $TacDiffusion_ROOT/dataset/.

You can download the prepared datasets using the following link: TacDiffusion Dataset.

Training

To start a new training job with the default parameter settings, simply run the following:
```
cd $TacDiffusion_ROOT
python 1_model_train.py
```
The result will be saved in $TacDiffusion_ROOT/output/, e.g., TacDiffusion_model_512.pth.

You could then use tensorboard to visualize the training process via
```
cd $TacDiffusion_ROOT
tensorboard --logdir=logs --host=XX.XX.XX.XX
```
To optimize the inference speed, we recommend exporting models to the ONNX format. Simply modify the model name in the script $TacDiffusion_ROOT/2_model_trans_pth_to_onnx.py and run the following command:
```
cd $TacDiffusion_ROOT
python 2_model_trans_pth_to_onnx.py
```
The converted model would be stored in $TacDiffusion_ROOT/output/, e.g., TacDiffusion_model_512.onnx.

NOTE

The four trained models, each with different neuron configurations as discussed in our paper, are already provided in the folder $TacDiffusion_ROOT/output/.
The implemented Diffusion Model (DDPM) in $TacDiffusion_ROOT/helper_functions/models.py is adapted from Imitating-Human-Behaviour-w-Diffusion.
The network architecture of the noise estimator is contructed as:

Testing

To test the model's theoretical performacne on recorded datasets, simply do the following:

cd $TacDiffusion_ROOT
python 3_model_test.py

The testing results would be ploted in $TacDiffusion_ROOT/figures/.

Deploying

Due to compatibility issues between the real-time kernel and the NVIDIA CUDA Toolkit, TacDiffusion should be implemented on a separate PC. The Franka Emika Panda robot manipulator can then be controlled via UDP communication by running the following command:

CUDA PC side

cd $TacDiffusion_ROOT
python 4_model_remote_control.py

real-time kernal PC side

step 1: install the real-timer kernal
step 2: install the docker https://docs.docker.com/engine/install/ubuntu/
step 3: start the docker

cd $TacDiffusion_ROOT/controller_in_docker
docker compose up

step 4: install the MongoDB service & connect to the local MongoDB database with the address "localhost:27017"
step 5: using the query assistant of MongoDB with the command

db.getCollection("parameters").find({"name": "system"})

step 6: update the "robot_ip", "desk_name" and "desk_pwd" based on your own configuration
step 7: close all the docker containers & boot your robot and lock the joint and release control in the robot desk
step 8: restart the docker (detailed in step 3)
step 9: homing the gripper, grasp the object and teach the peg-in-hole poses after pressing the user button (Note that: The 5_manipualtor_remote_control.py and the dependent bbo folder and mios folder should be placed in the real-time PC.)

ipython3 -i 5_manipualtor_remote_control.py
call_method("localhost", 12000, "home_gripper") # code for homing the gripper
move_gripper(0.05) # code for releasing the gripper
grasp(0.01) # code for grasping the object

teach_location("localhost","peg_IL_test") # give the exp name
teach_location("localhost","peg_IL_test_app") # record approach position
teach_location("localhost","peg_IL_test_hole") # record hole position
ctrl+z # finish the peg-in-hole poses teaching process

step 10: remote implement peg-in-hole experiments after changing the experiments name peg_name_all within the function insert_auto_IL() in 5_manipualtor_remote_control.py with the releasing of the user button

ipython3 -i 5_manipualtor_remote_control.py
insert_auto_IL() # the manipulator would repeat insertion 3 times with the TacDiffusion_model_512.

Additional note about getting realtime kernel and cuda working on a single PC

It is possible to resolve the compatability issue of realtime kernel and nvidia driver. Simply following the guide here if you have to deploy everything on a single GPU PC.

Citation

Please cite the following if you use this repository in your publications:

@article{wu2024tacdiffusion,
  title={TacDiffusion: Force-domain Diffusion Policy for Precise Tactile Manipulation},
  author={Wu, Yansong and Chen, Zongxie and Wu, Fan and Chen, Lingyun and Zhang, Liding and Bing, Zhenshan and Swikir, Abdalla and Knoll, Alois and Haddadin, Sami},
  journal={arXiv preprint arXiv:2409.11047},
  year={2024}
}

License

No commercial use!

Contact

For questions, please contact Yansong Wu.
