trueform

Real-time geometric processing. Easy to use, robust on real-world data.

Mesh booleans, registration, remeshing and queries — at interactive speed on million-polygon meshes. Robust to non-manifold flaps, inconsistent winding, and pipeline artifacts. One engine across C++, Python, and TypeScript.

▶ Try it live — Interactive mesh booleans, collisions, isobands and more. No install needed.

Documentation and Tutorials — Booleans, remeshing, registration, topology — step by step.

Installation

trueform is a C++17 header-only library. It depends on oneTBB.

pip install trueform

The pip package includes C++ headers with cmake and conan integration modules.

Conan (handles TBB automatically):

python -m trueform.conan create

CMake (requires TBB installed):

find_package(trueform REQUIRED CONFIG)
target_link_libraries(my_target PRIVATE tf::trueform)

cmake -B build -Dtrueform_ROOT=$(python -m trueform.cmake)

For manual installation without pip (FetchContent, system install, conan from repo), see the full installation guide.

Python — the same pip package includes Python bindings:

import trueform as tf
mesh = tf.read_stl("model.stl")

TypeScript — browser and Node.js:

npm install @polydera/trueform

Integrations

• Python — NumPy in, NumPy out
• TypeScript — NDArrays in, NDArrays out. Browser and Node.js.
• VTK — Filters and functions that integrate with VTK pipelines
• Blender — Cached meshes with automatic updates for live preview

Quick Tour

#include <trueform/trueform.hpp>

// Start with your raw data—no copies, no conversions
std::vector<float> raw_points = {0, 0, 0, 1, 0, 0, 0, 1, 0};
std::vector<int> indices = {0, 1, 2};

auto points = tf::make_points<3>(raw_points);
auto faces = tf::make_faces<3>(indices);
auto triangles = tf::make_polygons(faces, points);
// or maybe faces are variable
std::vector<int> offsets = {0, 3};
auto d_faces = tf::make_faces(offsets, indices);
auto d_polygons = tf::make_polygons(d_faces, points);

auto polygons_buffer = tf::read_stl("file.stl");
auto polygons = polygons_buffer.polygons();

Primitive queries work directly on geometry:

auto polygon = polygons.front();
auto segment = tf::make_segment_between_points(points[0], points[1]);
auto ray = tf::make_ray_between_points(
    tf::make_point(0.2f, 0.2f, -1.0f),
    tf::make_point(0.2f, 0.2f, 1.0f));

auto [dist2, pt_on_poly, pt_on_seg] = tf::closest_metric_point_pair(polygon, segment);
bool contains = tf::contains_point(polygon, points[0]);
if (auto hit = tf::ray_hit(ray, polygon)) {
    auto [status, t, hit_point] = hit;
}

Mesh analysis reveals structure and defects:

auto polygons = polygons_buffer.polygons();
// Connected components
auto [n_components, labels] = tf::make_manifold_edge_connected_component_labels(polygons);
auto [components, component_ids] = tf::split_into_components(polygons, labels);

// Vertex neighborhoods
auto v_link = tf::make_vertex_link(polygons);
auto k2_ring = tf::make_k_rings(v_link, 2);
auto neighs = tf::make_neighborhoods(polygons.points() | tf::tag(v_link), 0.5f);

// Principal curvatures and directions
auto [k0, k1, d0, d1] = tf::make_principal_directions(polygons);

// Boundary curves (open edges)
auto boundary_paths = tf::make_boundary_paths(polygons);
auto boundary_curves = tf::make_curves(boundary_paths, polygons.points());

// Non-manifold edges (shared by >2 faces)
auto bad_edges = tf::make_non_manifold_edges(polygons);
auto bad_segments = tf::make_segments(bad_edges, polygons.points());

// Fix inconsistent face winding
tf::orient_faces_consistently(polygons);

Spatial acceleration enables queries on transformed geometry:

tf::aabb_tree<int, float, 3> tree(polygons, tf::config_tree(4, 4));

auto dynamic_form = polygons | tf::tag(tree)
    | tf::tag(tf::random_transformation<float, 3>());
auto static_form = polygons | tf::tag(tree);

// Collision detection
bool does_intersect = tf::intersects(static_form, dynamic_form);
float distance2 = tf::distance2(static_form, dynamic_form);

// Collect all intersecting primitive pairs
std::vector<std::pair<int, int>> collisions;
tf::gather_ids(static_form, dynamic_form, tf::intersects_f,
               std::back_inserter(collisions));

// Compute intersection curves
auto curves = tf::make_intersection_curves(static_form, dynamic_form);

Boolean operations combine meshes:

auto [result_mesh, labels] = tf::make_boolean(
    polygons0,
    polygons1 | tf::tag(tf::make_rotation(tf::deg(45.f), tf::axis<2>)),
    tf::boolean_op::merge);

// With intersection curves
auto [result, labels, curves] = tf::make_boolean(
    polygons0, polygons1, tf::boolean_op::intersection, tf::return_curves);

Scalar fields and isocontours:

// Compute distance field from a plane
auto plane = tf::make_plane(polygons.front());
tf::buffer<float> scalars;
scalars.allocate(polygons.points().size());
tf::parallel_transform(polygons.points(), scalars, tf::distance_f(plane));

// Extract isocontours embedded into the mesh
std::vector<float> cut_values = {-0.5f, 0.0f, 0.5f};
auto [contour_mesh, contour_labels, isocontours] = tf::embedded_isocurves(
    polygons, scalars, tf::make_range(cut_values), tf::return_curves);

Mesh cleanup prepares geometry for processing:

// Merge coincident vertices, remove degenerates and duplicates
auto clean_mesh = tf::cleaned(polygons, tf::epsilon<float>);

// Triangulate n-gons
auto tri_mesh = tf::triangulated(polygons);

// Ensure outward-facing normals on closed meshes
tf::ensure_positive_orientation(polygons);

→ Geometry Walkthrough — A hands-on tour from raw geometry through booleans and connected components.

→ Modules — Primitives, ranges, policies, and the patterns that connect them.

Benchmarks

Sample comparisons against VTK, CGAL, libigl, Coal, FCL, and nanoflann:

| Operation | Input | Time | Speedup | Baseline | TrueForm | |-----------|-------|------|---------|----------|----------| | Boolean Union | 2 × 1M | 28 ms | 84× | CGAL Simple_cartesian<double> | reduction diagrams, double | | Mesh–Mesh Curves | 2 × 1M | 7 ms | 233× | CGAL Simple_cartesian<double> | reduction diagrams, double | | ICP Registration | 1M | 7.7 ms | 93× | libigl | AABB tree, random subsampling | | Self-Intersection | 1M | 78 ms | 37× | libigl EPECK (GMP/MPFR) | reduction diagrams, double | | Isocontours | 1M, 16 cuts | 3.8 ms | 38× | VTK vtkContourFilter | reduction diagrams, float | | Connected Components | 1M | 15 ms | 10× | CGAL | parallel union-find | | Boundary Paths | 1M | 12 ms | 11× | CGAL | Hierholzer's algorithm | | k-NN Query | 500K | 1.7 µs | 3× | nanoflann k-d tree | AABB tree | | Mesh–Mesh Distance | 2 × 1M | 0.2 ms | 2× | Coal (FCL) OBBRSS | OBBRSS tree | | Decimation (50%) | 1M | 72 ms | 50× | CGAL edge_collapse | parallel partitioned collapse | | Principal Curvatures | 1M | 25 ms | 55× | libigl | parallel k-ring quadric fitting |

Apple M4 Max, 16 threads, Clang -O3 -march=native. Full methodology, interactive charts, source code, and datasets in benchmarks documentation.

Documentation

• Getting Started — Installation and first steps
• Modules — Primitives, trees, topology, booleans
• Benchmarks — Performance comparisons
• Examples — Workflows and library comparisons
• Python Bindings — Full API for Python
• TypeScript SDK — WASM-powered, browser and Node.js
• Research — Theory, publications, and citation

License

Dual-licensed:

• Noncommercial: PolyForm Noncommercial License 1.0.0
• Commercial: Contact info@polydera.com

Contributing

Browse open issues labeled by difficulty. See CONTRIBUTING.md for guidelines.

Citation

If you use trueform in your work, please cite:

@software{trueform2025,
    title={trueform: Real-time Geometric Processing},
    author={Sajovic, {\v{Z}}iga and {et al.}},
    organization={XLAB d.o.o.},
    year={2025},
    url={https://github.com/polydera/trueform}
}

---

Developed by XLAB Medical
