MessageKit for Android

中文README, Download APK

About

Introduction

MessageKit is an open-source repository about chat messages, it shows how to design and develop elegant, useful layouts on displaying messages.

Pull requests to fix mistakes or improve performance are welcome.

Feature

• Repository contains layouts of some staple messages, read the form below for more details.
• Automatically scales the size of thumbnail according to the loading image.
• The style of message draws using paint instead of 9-Patch-PNG to achieve the smaller apk size.
• The layout has been abstracted from incoming or outgoing messages.
• Base message model has been abstracted as IMessage to decouple data model from business.
• The mask of the long pressing is at the foreground of the views instead of background for the best visual effects.
• Loader for loading avatars and images is decoupled, so you can use your favourite framwork.
• Multiple selection of message items is supported, but needs further develpoment.
• Except using LayoutInflator, layouts implemented by Anko(Experimental) are included to avoid blocking the main thread when inflating views with reflection.
• Using design patterns to reduce the complexity when maintaining the project.

Precautions

• The requirements are variable, this repository does not have the feature of out-of-the-box. The migration of source code to your project is highly recommended. Also, no maven dependency is provided.
• To fix mistakes, please read the update list regularly.
• Further development to satisfy reqeriments after migrating code may take a long time, think twice before using in business project.
• Please implement features base on the migrated code.

Supported types

Max Scrap on screen resolution: 1920*1080. The bigger screen, the larger max scrap.

| Type | Message Name | Layout Type | Max Scrap | | :------: | :-------------------: | :-----------------: | :-------: | | Text | MESSAGE_TYPE_TEXT | layout_msg_text | 15 | | Url | MESSAGE_TYPE_URL | layout_msg_url | 10 | | Notice | MESSAGE_TYPE_NOTICE | layout_msg_notice | 8 | | Location | MESSAGE_TYPE_LOCATION | layout_msg_location | 8 | | Image | MESSAGE_TYPE_IMAGE | layout_msg_media | 8 | | Video | MESSAGE_TYPE_VIDEO | layout_msg_media | 8 | | Audio | MESSAGE_TYPE_AUDIO | layout_msg_audio | 14 | | File | MESSAGE_TYPE_FILE | layout_msg_file | 11 |

Usage

Migrate the base source code to your project, includes layout resource, string resource, classes and gradle dependencies.

Model

This shows how the class implemented IMessage provides data.

public abstract class Message implements IMessage {
    /**
     * Message type, required.
     */
    private String type;

    /**
     * Message id, required.
     */
    private String messageId;

    /**
     * Message body, required.
     */
    private String body;

    /**
     * Message sender, required;
     */
    private String sender;

    /**
     * Message comes from roomId, required.
     */
    private String roomId;

    /**
     * Message timestamp, required.
     */
    private long timestamp;

    public Message(@NonNull String type, @NonNull String body) {
        this.type = type;
        this.body = body;
    }

    public Message(String type, String messageId,
                   String body, String sender,
                   String roomId, long timestamp) {
        this.type = type;
        this.messageId = messageId;
        this.body = body;
        this.sender = sender;
        this.roomId = roomId;
        this.timestamp = timestamp;
    }
}

View binding

Implement your view holder based on BaseViewHolder or AbstractViewHolder.

BaseViewHolder extends AbstractViewHolder, contains the instance of image loader and etc.

class LocationViewHolder(itemView: View) : BaseViewHolder(itemView) {
    /**
     * The name of the location, required.
     */
    private val mName: TextView = itemView.findViewById(R.id.name)

    /**
     * The address of the location, required.
     */
    private val mAddress: TextView = itemView.findViewById(R.id.address)

    /**
     * The map image of the location, optional.
     */
    private val mImage: ImageView = itemView.findViewById(R.id.image)

    override fun onBind(activity: Activity, message: IMessage) {
        super.onBind(activity, message)
        val msg = message as LocationMessage
        mName.text = msg.name
        mAddress.text = msg.address
        mResLoader.loadImage(activity, message.image ?: "", mImage)
    }
}

Use AbstractViewHolder as super class for simpler implements, refer to NoticeViewHolder for more detail.

class NoticeViewHolder(itemView: View) : AbstractViewHolder(itemView) {
    /**
     * Notice text.
     */
    private val mText: TextView = itemView.notice

    /**
     * Override as an empty implementation.
     */
    override fun onHolderCreated() {
    }

    override fun onBind(activity: Activity, message: IMessage) {
        mText.text = message.getBody()
    }
}

Register views to HolderRegister.

object HolderRegister {
    private const val HOLDER_TEXT = 2
    private val sViewType = HashMap<String, Int>()
    private val sContentTypes = SparseArray<HolderConfig>()

    init {
        sViewType.put(Message.MESSAGE_TYPE_TEXT, HOLDER_TEXT)
        val textConfig = HolderConfig(R.layout.vkit_layout_msg_text, ::TextViewHolder, 15)
        sContentTypes.put(HOLDER_TEXT, textConfig)
    }
}

RecyclerView

RecyclerView from android or custom class that conflicts fixed are both acceptable.

<androidx.recyclerview.widget.RecyclerView
    android:id="@+id/messageView"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="@android:color/white"
    android:overScrollMode="never"
    android:scrollbars="vertical"
    tools:listitem="@layout/vkit_layout_msg_text"/>

Adapter

Extends and implements the abstract method of AbstractMessageAdapter<RecyclerView.ViewHolder>.

open class MessageAdapter(private val mActivity: Activity,
                          private val mItemListener: IMessageItemListener,
                          resLoader: IMessageResLoader)
    :AbstractMessageAdapter<RecyclerView.ViewHolder>() {

    // Some abstract methods must to implement here.
}

Initialization

Instantiate the class which extends AbstractMessageAdapter.

• MessageItemListener processes the action of click and long click.

• MessageResLoader is the subclass of IMessageResLoader to load images.

class MessagesActivity : AppCompatActivity() {
    private lateinit var mAdapter: MessageAdapter

    /**
     * LinearLayoutManager for MessageAdapter.
     */
    private val mLayoutManager = LinearLayoutManager(this, RecyclerView.VERTICAL, false)

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_message)

        // MessageResLoader is a Kotlin singleton.
        mAdapter = MessageAdapter(this, MessageItemListener(), MessageResLoader)
        mAdapter.setHasStableIds(true)

        mLayoutManager.isSmoothScrollbarEnabled = true
        messageView.layoutManager = mLayoutManager
        messageView.adapter = mAdapter
        messageView.setHasFixedSize(true)
        MessageHolders.setMaxScrap(messageView)
    }
}

Refresh

Refresh UI with Adapter.notifyItemInserted.

val msg = TextMessage("Hello")
msg.setSender("Austin")
msg.setTimestamp(1548518400) // millisecond.
mAdapter.add(msg)
mAdapter.notifyDataSetChanged()
