nfdump

nfdump is a powerful suite of tools for collecting, processing, and analyzing NetFlow, IPFIX, and sFlow data from network devices. It supports advanced filtering, aggregation, and enrichment (geolocation, AS, Tor) of flow data with a focus on efficiency, flexibility, and extensibility.

Features
Compatibility
Installation
Configuration Options
Basic Usage
Included Tools
Compression
How nfdump Works
Sampling
NetFlow/NSEL/NAT Support
Related Projects
Sponsorship
License

Features

Collects NetFlow (v1, v5/v7, v9, IPFIX) and sFlow data.
Converts live or file pcap traffic to flow data.
Multi-threaded for high-performance processing and sorting.
Advanced flow filtering and aggregation (filter syntax similar to tcpdump, but optimized for flow data).
Supports user-defined flow aggregation.
Enriches flow records with geolocation, AS, and Tor exit node information.
Flexible output formats (text, CSV, JSON, and user-defined).
Optionally integrates GeoDB (geolookup/Maxmind) and TorDB (torlookup) databases.
Companion tools for extending functionality and integration with monitoring stacks.
Actively maintained and compatible with NfSen.

Compatibility

nfdump-1.7.x (codename “unicorn”) is the current release series.
Fully compatible with files created by nfdump-1.6.18 or newer.
Legacy flow files from earlier versions may lack certain fields. Use nfdump-1.6.17 to update such records where necessary.

To convert old files to the new format:

./nfdump -r old-flowfile -y -w new-flowfile

Note: Only nfdump can read legacy nfdump-1.6.x files; all other programs require the new format.
NfSen Users: Upgrade NfSen to the latest GitHub version for full compatibility. Some legacy binaries (e.g., nfprofile, nftrack) are still available but may be deprecated in future releases.

Installation

Building for general use or to create a package

nfdump uses the GNU autotools 2.71 build system.

./autogen.sh
./configure
make
sudo make install

Building for the local system

If you plan to run the tools on the same system where they are built, you can enable additional optimizations:

./autogen.sh
./configure --enable-native --enable-lto
make
sudo make install

This enables CPU-specific optimizations (-march=native) and link-time optimization (-flto) for improved performance.

Building on CentOS 7.x

Make sure, you have autotools 2.71 installed.

yum install centos-release-scl
yum install devtoolset-8-gcc devtoolset-8-gcc-c++
scl enable devtoolset-8 -- bash

Building on Ubuntu 18.04 LTS

Make sure, you have autotools 2.71 installed.

sudo apt-get install clang-10
CC=clang-10 ./configure ...

Configuration Options

By default ./configure builds:

the collectors nfcapd, sfcapd
nfdump for processing flows
additional tools geolookup, and torlookup

For a full list, run ./configure --help. Options include:

--enable-nfpcapd Build nfpcapd to create NetFlow from interface or pcap traffic (default: NO)
--enable-ja4 Enable all JA4 fingerprinting modules (default: NO)
--enable-jnat Support JunOS special NAT event logging (default: NO)
--enable-readpcap Enable reading flow data from pcap files in nfcapd (default: NO)
--enable-ftconv Build the flow-tools to nfdump converter (default: NO)
--enable-nfprofile Build nfprofile and nftrack, required by NfSen (default: NO)
--enable-devel Enable debugging aqnd developer options. For developers only (default: NO)
--with-lz4=PATH, --with-zstd=PATH, --with-bz2=PATH Specify non-default library install locations for compression libraries.
--enable-lto Enable link-time optimization (LTO) if supported. This allows the compiler to optimize across all source files during the final link step, improving performance and reducing binary size.
--enable-native Use -march=native to enable CPU-specific optimizations for the build host. This enables vectorization and instruction set tuning based on the local processor. Recommended for local builds, not for portable binaries.

Compared to previous versions, the configure script has changed: many tools that previously required explicit enabling are now built automatically. The old options --enable-xxxpath=path have been replaced by the standard --with-xxx=path

Compression libraries are searched for and integrated, if found. If you want to explicitly disable a library and therefore a compression method, use the format --enable-xxx=no This disables that library.

The following options no longer exist:

--enable-nsel NSEL support is built-in by default; you only need to adjust the output format if you prefer the legacy line or long format for NSEL/NAT. Change the fmt formats accordingly in the config file nfdump.conf

Notes:

Make sure your system does provide autoconf 2.71.
Older Linux distributions may require libbsd and libbsd-dev installed.
nfprofile is a legacy binary, used by NfSen and may be moved into a separate archive in future.

Basic Usage

Exporter → nfcapd → nfdump → analysis/export (CSV, JSON, InfluxDB, Prometheus)

nfdump provides a set of collection and processing tools. Common tools and example commands:

Start NetFlow Collector

nfcapd -D -S 2 -w /flow_base_dir/router1 -p 23456

View Collected Data

nfdump -r /flow_base_dir/router1/nfcapd.202501011200

Filter and Aggregate Flows

nfdump -r flowfile 'src ip 192.0.2.1 and dst port 443' -A srcip,dstip

Enrich with Geolocation or Tor Information

Enable and configure geolookup/torlookup databases as needed. For details, see the relevant man pages (man geolookup, man torlookup).

Export Metrics

Send metrics to InfluxDB or Prometheus-compatible tools using nfinflux or nfexporter.

Included Tools

nfdump includes several related tools for extended workflows:

nfcapd NetFlow collector daemon. Collects NetFlow version v1/v5/v7/v9 and IPFIX streams from one or many exporters and stores the flow record data in nfdump binary files.
sfcapd sFlow collector daemon. Collects sflow v4/v6 (sflowtool compatible) streams from one or many exporters and stores the flow record data in nfdump binary files.
nfpcapd Converts live traffic from a host interface or pcap-captured network traffic to NetFlow records. Stores the flow record data in nfdump binary files or forwards a data stream to a running nfcapd collector on another host.
nfdump Reads nfdump binary files, filters flow records and post-processes flow records. The extensive filter language (See the available cheatsheet ) selects flows for processing. The post-processing includes:
- Flexible flow aggregation
- Flow statistics, based on any flow element
- Flow listings
- Flow enrichment with optional geo and/or tor exit node information.
geolookup Look up IP addresses for country, region, city, and optionally AS information. Requires a geo database to work. See the provided updateGeoDB.sh script in order to build the database.
torlookup Look up IP addresses for Tor exit node information. Requires a TorDB database to work. See the provided updateTorDB.sh script in order to build the database.
nfanon Anonymizes IP addresses in flow records using CryptoPAn.
nfexpire Manages expiration of old flow data.
nfreplay Replays collected NetFlow data to another collector.
ft2nfdump Converts flow-tools format to nfdump format. (optionally built)
nfprofile and nftrack

Programs required by NfSen. nfprofile filters and organizes flows by profile, and nftrack provides port tracking for the PortTracker plugin.
nfreader Framework for custom C code to process nfdump files. Not installed by default.

Compression

Collected data files can be compressed using LZO, LZ4, ZSTD, or bzip2.

LZO and LZ4 are embedded and require no external dependencies by default.
ZSTD and bzip2 require system libraries, auto-detected at build time.
To compress on the fly, use the -z option, e.g. -z=lz4.

Example:

nfcapd -z=lz4 ...

Use bzip2 for maximum compression when archiving; use LZ4 (recommended) for fast, efficient real-time compression.

How nfdump Works

nfdump is designed to analyze both historical and live NetFlow data, enabling continuous or retrospective monitoring of network traffic. The system is optimized for speed and efficiency, allowing complex filtering and aggregation of flow records with a syntax similar to tcpdump.

Data Storage and Organization

All collected data is stored to disk before analysis, separating collection from processing.
Data is organized in a time-based directory structure, typically rotating files every 5 minutes.

Example directory structure:

/flow_base_dir/router1
/flow_base_dir/router2

Each subdirectory corresponds to a different flow source.

Example file rotation:

nfcapd.YYYYMMDDhhmm (e.g., nfcapd.200907110845 contains data from July 11th 2009 08:45 onward)

With a 5-minute interval, there are 28
