Osdev

This is a hobby OS project for learning more about low-level hardware. See the LICENSE file for details.

---

Hardware Requirements:

• Intel Ivy Bridge w/ HD Graphics 4000
• Intel 82579V Gigabit Ethernet

QEMU is also supported in text mode.

---

Setup and Installation for Windows:

• Install Cygwin (http://www.cygwin.com/) including the following packages and their dependencies:

  • bison
  • flex
  • gcc4
  • make
  • nasm
  • wget

• Build a 64-bit cross compiler for the kernel:

  • Setup

    • export PREFIX=/usr/local/cross
    • export TARGET=x86_64-elf
    • export PATH=$PATH:$PREFIX/bin
    • mkdir cross_gcc
    • cd cross_gcc
    • mkdir build_binutils build_gcc

  • Download and unpack source code

    • wget http://ftp.gnu.org/gnu/binutils/binutils-2.22.tar.bz2
    • wget http://ftp.gnu.org/gnu/gcc/gcc-4.7.0/gcc-4.7.0.tar.bz2
    • wget http://ftp.gnu.org/gnu/gmp/gmp-4.3.2.tar.bz2
    • wget http://www.mpfr.org/mpfr-2.4.2/mpfr-2.4.2.tar.bz2
    • wget http://www.multiprecision.org/mpc/download/mpc-0.8.1.tar.gz
    • tar xjf binutils-2.22.tar.bz2
    • tar xjf gcc-4.7.0.tar.bz2
    • tar xjf gmp-4.3.2.tar.bz2
    • tar xjf mpfr-2.4.2.tar.bz2
    • tar xzf mpc-0.8.1.tar.gz
    • mv gmp-4.3.2 gcc-4.7.0/gmp
    • mv mpfr-2.4.2 gcc-4.7.0/mpfr
    • mv mpc-0.8.1 gcc-4.7.0/mpc

  • Build binutils

    • cd build_binutils
    • ../binutils-2.22/configure --target=$TARGET --prefix=$PREFIX --disable-nls
    • make all
    • make install
    • cd ..

  • Build gcc

    • cd build_gcc
    • ../gcc-4.7.0/configure --target=$TARGET --prefix=$PREFIX --disable-nls --enable-languages=c --without-headers
    • make all-gcc
    • make install-gcc

• Install QEMU:

  • Precompiled Windows binaries are located at http://lassauge.free.fr/qemu/
  • Install http://lassauge.free.fr/qemu/release/Qemu-1.0.1-windows.zip
  • Copy bios.bin and vgabios-cirrus.bin from the Bios folder to QEMU's root directory.

• Install the TAP driver:

  • OpenVPN installers are located at http://openvpn.net/index.php/download.html
  • Install http://swupdate.openvpn.org/community/releases/openvpn-2.2.2-install.exe
  • Install only the "TAP Virtual Ethernet Adapter" component.
  • Modify the Network Connections:
    • Rename the TAP interface from "Local Area Connection (n)" to "tap"
    • Bridge the TAP interface with your active Local Area Connection.

• Update PATH:

  • Add QEMU and /usr/local/cross/bin to the PATH variable in .bash_profile

---

Configuration:

• g_localTimeZone in time.c

---

What to expect:

• Type 'help' to see available commands. Some examples:

  • 'http' fetches web pages
  • 'gfx' switches into graphics mode
  • 'host' performs a DNS lookup on a hostname
  • 'ping' sends an ICMP echo request to an IP address
  • 'lsroute' prints the routing table
  • 'datetime' prints the current time
  • 'synctime' sends an NTP request and updates the CMOS

• tools/os_helper.exe provides services to improve OS development. Currently this is used for remote logging via UDP.

---

Emulator steps:

$ make $ qemu.bat

---

Hardware steps:

Format a FAT16 drive, update the boot sector and copy the loader and kernel binaries.

$ make $ tools/set_boot.exe //./<drive letter>: boot/boot.bin $ cp boot/loader.bin <drive letter>:/ $ cp kernel/kernel.bin <drive letter>:/

Boot!
