Peregrine: A Pattern-Aware Graph Mining System

Peregrine is an efficient, single-machine system for performing data mining tasks on large graphs. Some graph mining applications include:

• Finding frequent subgraphs
• Generating the motif/graphlet distribution
• Finding all occurrences of a subgraph

Peregrine is highly programmable, so you can easily develop your own graph mining applications using its novel, declarative, graph-pattern-centric API. To write a Peregrine program, you describe which graph patterns you are interested in mining, and what to do with each occurrence of those patterns. You provide the what and the runtime handles the how.

For full details, you can read our paper published in EuroSys 2020 or the longer version on arXiv. For a deeper look at optimizations under the hood, check out our article in the 2021 ACM Operating Systems Review.

For an in-depth summary, watch the video presentation:

TL;DR: compared to other state-of-the-art open-source graph mining systems, Peregrine:

• executes up to 700x faster
• consumes up to 100x less memory
• scales to 100x larger data sets
• on 8x fewer machines
• with a simpler, more expressive API

Table of Contents

1. Quick start
2. Writing your own programs
3. Data graphs
4. Reproducing our EuroSys 2020 paper results
5. Contributing
6. Acknowledgements
7. Resources

1. Quick start

Peregrine has been tested on Ubuntu 18.04 and Arch Linux but should work on any POSIX-y OS. It requires C++20 support (GCC version >= 10.1). Additionally, the tests require UnitTest++.

Ubuntu 18.04 prerequisites:

sudo add-apt-repository ppa:ubuntu-toolchain-r/test
sudo apt-get update
sudo apt install g++-10 libunittest++-dev

To build Peregrine:

$ git clone https://github.com/pdclab/Peregrine.git
$ cd Peregrine
$ source tbb2020/bin/tbbvars.sh intel64
$ make -j CC=g++-10
$ bin/test

Several sample applications, query patterns, and a sample dataset are released with the code. Calling any of the applications without arguments will show you what they expect:

$ bin/count
USAGE: bin/count <data graph> <pattern | #-motifs | #-clique> [# threads]

These applications print their results in <pattern>: <aggregation value> format.

For example, motif-counting:

$ bin/count data/citeseer 3-motifs 8
Counting 3-motifs
Finished reading datagraph: |V| = 3264 |E| = 4536
[...]
All patterns finished after 0.030265s
[2-3][1-3]: 23380
[1-2][1-3][2-3]: 1166

The string [2-3][1-3] encodes the pattern consisting of edges (1, 3), (2, 3), and 23380 is the number of unique occurrences Peregrine found in the citeseer graph.

Other applications give similar output:

$ bin/count data/citeseer 4-clique 8
[...]
All patterns finished after 0.030265s
[3-4][1-2][1-3][1-4][2-3][2-4]: 255
$
$ bin/count data/citeseer query/p1.graph 8
[...]
All patterns finished after 0.003368s
[3-4][1-2][1-3][1-4][2-3]: 3730

FSM provides support values instead of counts:

$ bin/fsm data/citeseer 3 300 8 # size 3 FSM with support 300
[...]
Frequent patterns:
[1,0-2,0][1,0-3,0][2,0-4,0]: 303
[1,1-2,1][1,1-3,1][2,1-4,1]: 335
Finished in 0.078629s

The sample FSM app performs edge-induced FSM by default. For vertex-induced FSM, simply call it as

$ bin/fsm data/citeseer 3 300 8 v # vertex-induced

The existence-query application simply states whether the desired pattern exists or not:

$ bin/existence-query data/citeseer 14-clique 8
[...]
All patterns finished after 0.005509s
[pattern omitted due to length] doesn't exist in data/citeseer

The output application stores matches grouped by pattern in either CSV or packed binary format:

$ bin/output data/citeseer 3-motifs results bin 8
[...]
all patterns finished after 0.002905s
[1-3](1~2)[2-3]: 23380 matches stored in "results/[1-3](1~2)[2-3]"
[1-2][1-3][2-3]: 1166 matches stored in "results/[1-2][1-3][2-3]"

In the CSV format, for a pattern with n vertices each line will contain a match written in the form:

v1,v2,...,vn
...

In the binary format, matches are written as sequences of n 4-byte vertex IDs in binary, with no delimiters:

bits(v1)bits(v2)...bits(vn)...

2. Writing your own programs

In Peregrine's programming model, you provide a data graph, a set of patterns you're interested in, and a callback the system will apply to each occurrence of these patterns in your data graph. We present a brief overview of the API here, beginning with constructing patterns.

For all of the following code snippets, assume we are using namespace Peregrine.

We have not released support for directed graphs yet; the code currently assumes all graphs are undirected.

2.1 Constructing patterns directly

Pattern graphs can constructed in two ways using the SmallGraph data structure:

2.1.1 Statically, from a file

Given a file in the following edge-list format:

<vertex-id> [label] <vertex-id> [label]

where the label's are optional 32-bit integers and vertex ids are contiguous integers starting from 1. To indicate a vertex is unlabelled in a partially-labelled pattern, assign it label -1. To indicate an anti-edge, any extra integer can be placed at the end of the line.

For example, a triangle:

1 2
1 3
2 3

A vertex-induced 3-star, notice the last edge is an anti-edge:

1 2
1 3
2 3 1

A partially-labelled triangle (vertex 3 is unlabelled):

1 100 2 101
1 100 3 -1
2 101 3 -1

Then, construct the SmallGraph:

SmallGraph p("pattern_graph.txt");

2.1.2 Dynamically, using the builder methods

Construct an empty graph and add edges/anti-edges one by one:

SmallGraph p
  .add_edge(1, 2)
  .add_edge(1, 3)
  .add_anti_edge(2, 3)
  .set_label(1, 100)
  .set_label(2, 101)
  .set_label(3, -1);

2.2 Constructing patterns using the PatternGenerator

The PatternGenerator class is useful for

Quickly generating common patterns:

SmallGraph triangle = PatternGenerator::clique(3);
SmallGraph wedge = PatternGenerator::star(3);

Quickly generating many patterns:

int size = 4;
std::vector<SmallGraph> vertex_induced = PatternGenerator::all(size,
        PatternGenerator::VERTEX_BASED,        // 4 vertices
        PatternGenerator::INCLUDE_ANTI_EDGES); // anti-edges are inserted between all unadjacent vertices

std::vector<SmallGraph> vertex_induced_edge_based = PatternGenerator::all(size,
        PatternGenerator::EDGE_BASED,          // 4 edges
        PatternGenerator::INCLUDE_ANTI_EDGES); // anti-edges are inserted between all unadjacent vertices

std::vector<SmallGraph> edge_induced = PatternGenerator::all(size,
        PatternGenerator::EDGE_BASED,          // 4 edges
        PatternGenerator::EXCLUDE_ANTI_EDGES); // no extra anti-edges are inserted

std::vector<SmallGraph> edge_induced_vertex_based = PatternGenerator::all(size,
        PatternGenerator::VERTEX_BASED,        // 4 vertices
        PatternGenerator::EXCLUDE_ANTI_EDGES); // no extra anti-edges are inserted

Extending existing patterns:

std::vector<SmallGraph> vertex_extensions = PatternGenerator::extend({triangle}, PatternGenerator::VERTEX_BASED);
std::vector<SmallGraph> edge_extensions = PatternGenerator::extend({triangle}, PatternGenerator::EDGE_BASED);

2.3 Importing data graphs

Data graphs can be constructed from a preprocessed edge-list (see Data graphs) or a SmallGraph.

DataGraph dg("preprocessed_data/");

SmallGraph g("small_data_graph.txt");
DataGraph dg(g);

2.4 Matching patterns

Pattern matching is done through the match, count, and output functions.

Counting instances of patterns is very simple. Consider the following minimal motifs program:

#include "Peregrine.hh"
using namespace Peregrine;
void motifs(int size)
{
  int nthreads = 16;
  DataGraph g("data/citeseer/");

  auto patterns = PatternGenerator::all(size, PatternGenerator::VERTEX_BASED, PatternGenerator::INCLUDE_ANTI_EDGES);

  auto results = count(g, patterns, nthreads);

  for (const auto &[pattern, count] : results)
  {
    std::cout << pattern << ": " << count << std::endl;
  }
}

The arguments to count are straightforward: the data graph you wish to use, the patterns whose instances you wish to count, and the number of worker threads to use.

For arbitrary aggregations, use the match or output template functions. For example, you could replace count above with this snippet (note that using count will be faster):

  const auto callback = [](auto &&handle, auto &&match) { handle.map(match.pattern, 1); };
  auto results = match<Pattern, uint64_t, AT_THE_END, UNSTOPPABLE>(g, patterns, nthreads, callback);

First, let's explain the template arguments to match:

• Peregrine::Pattern is the aggregation key type
• uint64_t is the aggregation value type
• AT_THE_END describes when aggregation happens: either AT_THE_END of execution or ON_THE_FLY
• UNSTOPPABLE indicates that you will not be using early termination

The regular parameters are the same as the count example except for callback. This is a function that will be called on each match for a patter
