RevDedup

Welcome

This is the source code for RevDedup described in our paper presented in TOS. The system is tested on Ubuntu 12.04 64 bit. - Dec 2014

Setup

The program can be compiled using Linux make. There are three required libraries that users need to download separately. Brackets denote the package names in Debian and Ubuntu platforms. Users can use apt-get to install the required libraries.

openssl (libssl-dev)
libcurl (libcurl4-openssl-dev)
Kyoto Cabinet (libkyotocabinet-dev)

Storage Structure

data
 |--/bucket
 |--/image

Usage

Chunking

Perform chunking on input file (Segment and Chunk) and output a metadata file

./chunking <input file> <output chunking metafile>

Inline Deduplication

Perform segment level deduplication and store the file

./convdedup <input file> <input chunking metafile> <instanceID>

Out-of-line Reverse Deduplication

Perform batch reverse deduplication for all instances at certain version

./revdedup <number of instances> <version number>

Restore Backup

Restore backups have undergone reverse deduplication (Reference Chain)

./restoreo <instanceID> <version number> <output file>

Restore backups have undergone inline deduplication only ./restore <instanceID> <version number> <output file>

Delete Backup

Delete backups have undergone reverse deduplication (Fast Deletion)

./deleteo <number of instances> <version number>

Perform deletion with conventional deduplication (Mark & Sweep) ./remove <instanceID> <version number> ./delete

Usage Example

Assuming there are three versions of two VM image series, named vm0-0, vm0-1, vm0-2 and vm1-0, vm1-1, vm1-2

1. Chunking

./chunking vm0-0 meta0-0
./chunking vm1-0 meta1-0
./chunking vm0-1 meta0-1
./chunking vm1-1 meta1-1
./chunking vm0-2 meta0-2
./chunking vm1-2 meta1-2

Perform chunking on the VM images, result in a metadata file for each image.

2. Segment Level Deduplication

./convdedup vm0-0 meta0-0 0
./convdedup vm1-0 meta1-0 1
./convdedup vm0-1 meta0-1 0
./convdedup vm1-1 meta1-1 1
./convdedup vm0-2 meta0-2 0
./convdedup vm1-2 meta1-2 1

Perform segment level global deduplication on the VM images. Images are stored in RevDedup as two backup instance series 0 and 1

3. Chunk Level Reverse Deduplication

./revdedup 2 0
./revdedup 2 1

Perform chunk level reverse deduplcation on the two series, the process is triggered in a batch, images having the specified version number from the both series are reverse deduplicated against corrsponding next version one.

4. Restore

./restoreo 0 0 restore0-0
./restoreo 1 0 restore1-0
./restoreo 0 1 restore0-1
./restoreo 1 1 restore1-1
./restore 0 2 restore0-2
./restore 1 2 restore1-2

To restore backups those have been reverse deduplicated, ./restoreo is used. For those have been only deduplicated in segment level, ./restore is used.

5. Delete

./deleteo 2 0
./deleteo 2 1
./remove 0 2; ./remove 1 2; ./delete

Reverse deduplicated backups could be batch deleted with the program ./deleteo. It would delete all backups having version number at or before the specified one. For those only undergone segment deduplication, a mark-and-sweep approach is used.

Configuration

Parameters are set in include/revdedup.h Queue Length (Memory Usage) are set in include/queue.h
