Sublime Acme Assembler (C64)
Sublime Package for C64/CX16 6502 assembly development using the Acme Assembler, contains language configuration/syntax coloring, build system and some snippets. Support for OSX, Windows and Linux. Requires Sublime Text, version 3 is supported.
The cx16 emulator is used for development.
Below is a quick start guide.
Installation: OSX
-
install sublime text
brew cask install sublime-text
-
requires homebrew installed
brew install acme
-
download and install Commander X16 emulator extract the files copy folder to Applications folder
-
download this repo extract the files copy AcmeAssemblerC64 folder to /Users/[username]/Library/Application Support/Sublime Text 3/Packages folder, replace [username] with login name.
Installation: Windows
-
download and install Commander X16 emulator
-
download this repo extract the files copy AcmeAssemblerC64 folder to c:.../applications/Sublime Text 3/Packages folder.
Installation: Linux
-
download and install Commander X16 emulator
-
download this repo extract the files copy AcmeAssemblerC64 folder to .../applications/Sublime Text 3/Packages folder.
Develop, build and run
-
Open a Acme Assembler code file in Sublime text. Example code file
-
Press
F7key to start Build and Run (see below for more build options) -
If you get error saying java is not recognized as an internal or external command, ensure java is installed and add the path to your java binaries folder to the PATH environment variable
Details, Build System
Action | Shortcut macOS | Shortcut Windows | Description
:--|:--|:--|:--
Other build variants (listed below) | cmd+Shift+P | Ctrl+Shift+P | Shows the list of the following variants
Build | Command+Shift+P | Control+Shift+P | Compiles the current file.
Build and Run | F7 | F7 | Compiles the current file and runs it using the Vice emulator.
Build and Debug | Shift+F7 | Shift+F7 | Compiles the current file and runs it using the Vice emulator. This option allows the creation of a file containing breakpoints, which is sent to the Vice emulator for debugging.
Build Startup | Command+Shift+B | Ctrl+Shift+B | Compiles a file with name Startup.asm in the same folder as the current file. Handy if you have several code files included in a main runnable file. The filename can be configured via Acme_startup_file_path setting.
Build and Run Startup | F5 | F5 | Compiles a file with name Startup.asm in the same folder as the current file, and runs it using the Vice emulator. Handy if you have several code files included in a main runnable file. The filename can be configured via Acme_startup_file_path setting.
Build and Debug Startup | Shift+F5 | Shift+F5 | Compiles a file with name Startup.asm in the same folder as the current file, and runs it using the Vice emulator. Handy if you have several code files included in a main runnable file. This option allows the creation of a file containing breakpoints, which is sent to the Vice emulator for debugging. The filename can be configured via Acme_startup_file_path setting.
Make | F8 | F8 | Invokes a script called make.bat for Windows, make.sh for macOS (configurable through the default_make_path setting).
The following (relevant?) environment variables will be available in the make script:
Variable | Info
:--|:--
Acme_file | Filename of active file when command was triggered
Acme_file_path | Full path active file when command was triggered
Acme_prg_file | Full path for suggested prg file name, for active file when command was triggered
Acme_bin_folder | Path to current output folder (bin by default or specified by Acme_output_path setting)
"acme_emulator_run_path": "/Applications/x16emu_mac-r33/x16emu" | path to emulator
Pre/post-build
There's a way to execute custom scripts before/after the build.
Variable | Info
:--|:--
-
default_prebuild_path| Full path to the.bator.shscript file that will be executed before the build. -
default_postbuild_path| Full path to the.bator.shscript file that will be executed after the build. Useful for file compression etc.
AcmeTooltips
This plugin makes working with Acme Assembler easier by displaying various helpful tooltip information. Tooltips database can be extended to provide more c64 related info. So far rudimentary help files with Acme Assembler directives, illegal opcodes, VIC registers and SID registers are ready. This plugin was added by Roman Dobosz (Gryf/Elysium) and Krzysztof Dabrowski (Brush/Elysium)
Other documentation
Navigate to Preferences/Package Settings/AcmeAssemblerC64 and select the
-
Acme Quick Ref - this is a quick reference text on Acme Assembler.
-
65C02 Opcodes.html - right click and slect open in browser.
Configuration
Navigate to Preferences/Package Settings/AcmeAssemblerC64 and select the configuration file to edit. Currently you can configure:
"css_file": "AcmeAssemblerC64/css/default.css"
This is a file that has the css file used to style the tooltips.
"help_directories": ["AcmeAssemblerC64/helpdb"],
This defines the directory where json formatted help files are located. Feel free to drop in your own.
"scopes": ["source.assembly.AcmeAssembler"],
This definies in which scopes the plugin should work. So far it will fire up only in Acme Assembler scope.
"log_level": "warning"
For the debugging purposes you can increase the log level to info or debug, open Python console (ctrl-`) and observe what is going on and what problems the plugin has. If you report a bug, please use "debug" level and make sure you copy paste the whole output.
Contribute
Making changes
Fork repo, make changes and submit pull requests.
Local development
Just clone repo into Sublime package folder and you can test the package "live" during development.
IT Development:
p.s: I LOVE coffee! Buy me a coffee at:
This plugin was originally created by //Swoffa of Noice
