Hubris

Hubris is a microcontroller operating environment designed for deeply-embedded systems with reliability requirements. Its design was initially proposed in RFD41, but has evolved considerably since then.

Learning

Developer documentation is in Asciidoc in the doc/ directory. It gets rendered via GitHub pages, and is available at https://oxidecomputer.github.io/hubris .

Navigating

The repo is laid out as follows.

• app/ is where the top-level binary crates for applications live, e.g. app/gimlet contains the firmware crate for Gimlet. Generally speaking, if you want to build an image for something, look here.

• build/ contains the build system and supporting crates.

• chips/ contains peripheral definitions and debugging support files for individual microcontrollers.

• doc/ contains developer documentation.

• drv/ contains drivers, a mix of simple driver lib crates and fully-fledged server bin crates. Current convention is that drv/SYSTEM-DEVICE is the driver for DEVICE on SYSTEM (where SYSTEM is usually an SoC name), whereas drv/SYSTEM-DEVICE-server is the server bin crate.

• idl/ contains interface definitions written in Idol

• lib/ contains assorted utility libraries we've written. If you need to make a reusable crate that doesn't fit into one of the other directories, it probably belongs here.

• support/ contains some interface and programming support files, like fake certificates and programmer firmware images.

• sys/ contains the "system" bits of Hubris, namely the kernel (sys/kern), the shared crate defining the ABI (sys/abi), and the user library used by tasks (sys/userlib).

• task/ contains reusable tasks that aren't drivers. The distinction between things that live in task vs in drv/something-server is fuzzy. Use your judgement.

• test/ contains the test framework and binary crates for building it for various boards.

• website/ contains the source code for the hubris website

Developing

We currently support Linux and Windows as first-tier platforms. Because of some inconsistency in linker behavior across platforms, images may not match across platforms, so we recommend choosing one as your "official" build platform for producing blessed images. macOS and Illumos are both used as informal build platforms by Oxide employees, though they are not currently tested in CI. (Oxide blessed images are produced on Linux.)

To submit changes for review, push them to a branch in a fork and submit a pull request to merge that branch into master. For details, see CONTRIBUTING.md.

Prereqs

You will need:

• A rustup-based toolchain install. rustup will take care of automatically installing our pinned toolchain version, and the cross-compilation targets, when you first try to build.

• libusb, typically found from your system's package manager as libusb-1.0.0 or similar.

• libfdti1, found as libftdi1-dev or similar.

• If you will be running GDB, you should install arm-none-eabi-gdb. This is typically from your system's package manager with a package name like arm-none-eabi-gdb or gdb-multiarch. macOS users can run brew install --cask gcc-arm-embedded to install the official ARM binaries.

• The Hubris debugger, Humility. Note that cargo install interacts strangely with the rust-toolchain.toml file present in the root of this repository; if you run the following command verbatim to install Humility, do so from a different directory:

  • cargo install --git https://github.com/oxidecomputer/humility.git --locked humility-bin
    • Requires cargo-readme as a dependency: cargo install cargo-readme

Windows

There are three alternative ways to install OpenOCD:

See here for getting the source of openocd or get unofficial binaries.

Alternatively, you can install with chocolatey:

> choco install openocd

Lastly, you could install openocd with scoop:

> scoop bucket add extras
> scoop install openocd

Note: openocd installed via scoop has proven problematic for some users. If you experience problems, try installing via choco or from source (see above).

To use the ST-Link programmer, you'll probably need to install this driver.

It's not necessary to build and run Hubris, but if you want to communicate over a serial link (and that's not supported by your terminal), you'll want to use PuTTY; this guide does a good job of explaining how.

Build

We do not use cargo build or cargo run directly because they are too inflexible for our purposes. We have a complex multi-architecture build, which is a bit beyond them.

Instead, the repo includes a Cargo extension called xtask that namespaces our custom build commands.

cargo xtask dist TOMLFILE builds a distribution image for the application described by the TOML file.

• cargo xtask dist app/demo-stm32f4-discovery/app.toml - stm32f4-discovery
• cargo xtask dist app/demo-stm32f4-discovery/app-f3.toml - stm32f3-discovery
• cargo xtask dist app/lpc55xpresso/app.toml - lpcxpresso55s69
• cargo xtask dist app/demo-stm32g0-nucleo/app-g031.toml - stm32g031-nucleo
• cargo xtask dist app/demo-stm32g0-nucleo/app-g070.toml - stm32g070-nucleo
• cargo xtask dist app/demo-stm32h7-nucleo/app-h743.toml - nucleo-ih743zi2
• cargo xtask dist app/demo-stm32h7-nucleo/app-h753.toml - nucleo-ih753zi
• cargo xtask dist app/gemini-bu/app.toml - Gemini bringup board

Iterating

Because a full image build can take 10 seconds or more, depending on what you've changed, when you're iterating on a task or kernel you'll probably want to build it separately. This is what cargo xtask build is for.

For instance, to build task-ping as it would be built in one of the images, but without building the rest of the demo, run:

$ cargo xtask build app/gimletlet/app.toml ping

Running clippy

The cargo xtask clippy subcommand can be used to run clippy against one or more tasks in the context of a particular image:

$ cargo xtask clippy app/gimletlet/app.toml ping pong

Integrating with rust-analyzer

The Hubris build system will not work with rust-analyzer out of the box.

However, cargo xtask lsp is here to help: it takes as its argument a Rust file, and returns JSON-encoded configuration for how to set up rust-analyzer.

To use this data, some editor configuration is required!

(we haven't made plugins yet, but it would certainly be possible)

Using Neovim and rust-tools, here's an example configuration:

-- monkeypatch rust-tools to correctly detect our custom rust-analyzer
require'rust-tools.utils.utils'.is_ra_server = function (client)
  local name = client.name
  local target = "rust_analyzer"
  return string.sub(client.name, 1, string.len(target)) == target
    or client.name == "rust_analyzer-standalone"
end

-- Configure LSP through rust-tools.nvim plugin, with lots of bonus
-- content for Hubris compatibility
local cache = {}
local clients = {}
require'rust-tools'.setup{
  tools = { -- rust-tools options
    autoSetHints = true,
    inlay_hints = {
      show_parameter_hints = false,
      parameter_hints_prefix = "",
      other_hints_prefix = "",
      -- do other configuration here as desired
    },
  },

  server = {
    on_new_config = function(new_config, new_root_dir)
      local bufnr = vim.api.nvim_get_current_buf()
      local bufname = vim.api.nvim_buf_get_name(bufnr)
      local dir = new_config.root_dir()
      if string.find(dir, "hubris") then
        -- Run `xtask lsp` for the target file, which gives us a JSON
        -- dictionary with bonus configuration.
        local prev_cwd = vim.fn.getcwd()
        vim.cmd("cd " .. dir)
        local cmd = dir .. "/target/debug/xtask lsp "
        -- Notify `xtask lsp` of existing clients in the CLI invocation,
        -- so it can check against them first (which would mean a faster
        -- attach)
        for _,v in pairs(clients) do
          local c = vim.fn.escape(vim.json.encode(v), '"')
          cmd = cmd .. '-c"' .. c .. '" '
        end
        local handle = io.popen(cmd .. bufname)
        handle:flush()
        local result = handle:read("*a")
        handle:close()
        vim.cmd("cd " .. prev_cwd)

        -- If `xtask` doesn't know about `lsp`, then it will print an error to
        -- stderr and return nothing on stdout.
        if result == "" then
          vim.notify("recompile `xtask` for `lsp` support", vim.log.levels.WARN)
        end

        -- If the given file should be handled with special care, then
        -- we give the rust-analyzer client a custom name (to prevent
        -- multiple buffers from attaching to it), then cache the JSON in
        -- a local variable for use in `on_attach`
        local json = vim.json.decode(result)
        if json["Ok"] ~= nil then
          new_config.name = "rust_analyzer_" .. json.Ok.hash
          cache[bufnr] = json
          table.insert(clients, {toml = json.Ok.app, task = json.Ok.task})
        else
          -- TODO:
          -- vim.notify(vim.inspect(json.Err), vim.log.levels.ERROR)
        end
      end
    end,

    on_attach = function(client, bufnr)
      local json = cache[bufnr]
      if json ~= nil then
        loc
