SikuliX1

<div align="center"> <br>

<br> <h3>Visual Automation Framework powered by Computer Vision</h3> <p> <strong>If you can see it, you can automate it.</strong> </p> <p> <a href="https://github.com/oculix-org/SikuliX1/releases"><img src="https://img.shields.io/badge/version-2.0.5-blue?style=flat-square" alt="Version"></a> <a href="https://github.com/oculix-org/SikuliX1/blob/master/LICENSE"><img src="https://img.shields.io/badge/license-MIT-green?style=flat-square" alt="License"></a> <a href="https://github.com/oculix-org/SikuliX1/issues"><img src="https://img.shields.io/github/issues/oculix-org/SikuliX1?style=flat-square&color=orange" alt="Issues"></a> <a href="https://github.com/oculix-org/SikuliX1/stargazers"><img src="https://img.shields.io/github/stars/oculix-org/SikuliX1?style=flat-square&color=yellow" alt="Stars"></a> </p> <p> <code>OpenCV</code> &middot; <code>Image Recognition</code> &middot; <code>GUI Automation</code> &middot; <code>Cross-Platform</code> &middot; <code>Java / Python / Ruby</code> </p> </div>

---

<br>

SikuliX is alive again

SikuliX is now actively maintained under oculix-org, with the full agreement of its original creator RaiMan.

A huge thank you to RaiMan for building and maintaining SikuliX for years, and for laying the foundations of visual automation as we know it today.

The goal is simple: stabilize, modernize and extend SikuliX while preserving what made it powerful from the start.

<br>

What is SikuliX

SikuliX uses computer vision (powered by OpenCV) to identify and interact with anything visible on your screen — across Windows, macOS and Linux.

It locates GUI elements through image recognition, then drives them with simulated mouse and keyboard actions. No access to source code, DOM or internal APIs required.

<br> <table> <tr> <td width="50%"> <h4>When to use SikuliX</h4> <ul> <li>No access to the application's internals</li> <li>The UI is not DOM-based (desktop, legacy, embedded)</li> <li>Source code is unavailable or closed</li> <li>Visual regression testing is needed</li> <li>RPA on any visible interface</li> </ul> </td> <td width="50%"> <h4>How it works</h4> <ol> <li><strong>Capture</strong> — screenshot a GUI element</li> <li><strong>Find</strong> — OpenCV locates it on screen</li> <li><strong>Act</strong> — click, type, drag, wait</li> <li><strong>Verify</strong> — assert visual state</li> </ol> </td> </tr> </table> <br>

Project Status

| | Status | |---|---| | Maintenance | Actively maintained | | Issues & PRs | Reviewed and triaged | | CI/CD | Automated builds for Windows, macOS, Linux | | macOS Apple Silicon | Supported (M1 / M2 / M4) |

<br>

Current Version

Latest stable: 2.0.5

| Platform | Support | |---|---| | Windows (x86_64) | Supported | | macOS Intel | Supported | | macOS Apple Silicon (M1+) | Supported | | Linux (x86_64) | Supported | | Java | 8+ (17 recommended) |

Resources:

• Changes, issues and enhancements
• List of fixes
• Get SikuliX ready to use
• SikuliX Documentation

<br>

OculiX 3.0.1 — Development Build

The next evolution of SikuliX. 511 files changed, 123,728 insertions over SikuliX 2.0.5.

<table> <tr> <td><strong>Windows</strong></td> <td>Available</td> <td><a href="https://github.com/julienmerconsulting/Oculix/releases/tag/v3.0.1">Download</a></td> </tr> <tr> <td><strong>Linux</strong></td> <td>Available</td> <td><a href="https://github.com/julienmerconsulting/Oculix/releases/tag/v3.0.1">Download</a></td> </tr> <tr> <td><strong>macOS</strong></td> <td>Validation in progress</td> <td><a href="https://github.com/julienmerconsulting/Oculix/releases/tag/v3.0.1">Download (beta)</a></td> </tr> </table>

What's new in 3.0.1:

| Category | Details | |---|---| | macOS fix | Fixed ASM class conflict (cglib/rococoa) that crashed Jython on macOS — the IDE now starts on Apple Silicon (M1/M2/M4) | | IDE fix | -v (verbose) flag no longer blocks GUI display | | VNC stack | Full VNC integration — VNCScreen, VNCRobot, VNCClient, VNCFrameBuffer, VNCClipboard, XKeySym (2200+ key mappings) | | SSH | Native SSH tunnels via embedded jcraft/jsch — no external tools required | | Android ADB | ADBClient, ADBDevice, ADBRobot, ADBScreen — control Android 12+ devices via WiFi or USB, no Appium needed | | PaddleOCR | Neural OCR engine integration — PaddleOCREngine, PaddleOCRClient — text detection with confidence scoring on any screen | | OpenCV | Upgraded to OpenCV 4.10.0 via Apertix | | Script runners | Jython, JRuby, PowerShell, AppleScript, Robot Framework | | Java | Java 17 recommended (Java 8+ still supported) | | CI/CD | Automated builds for Windows, macOS, Linux via GitHub Actions |

<br>

Quick Start

# Requires Java 8+ (Java 17 recommended)
java -version

# SikuliX 2.0.5 (legacy stable)
java -jar sikulixide.jar

# OculiX 3.0.1 (latest development build)
java -jar oculixide-3.0.1-windows.jar   # Windows
java -jar oculixide-3.0.1-macos.jar     # macOS
java -jar oculixide-3.0.1-linux.jar     # Linux

Maven dependency (SikuliX 2.0.5):

<dependency>
  <groupId>com.sikulix</groupId>
  <artifactId>sikulixapi</artifactId>
  <version>2.0.5</version>
</dependency>

<br>

Scripting Languages

SikuliX scripts can be written in:

| Language | Extension | Engine | |---|---|---| | Python | .py | Jython 2.7 | | Ruby | .rb | JRuby 9.2 | | Java | .java | Native | | PowerShell | .ps1 | OculiX 3.0.1+ | | AppleScript | .scpt | OculiX 3.0.1+ (macOS) |

<br>

The Vision Pipeline

Screen Capture ──► OpenCV Match ──► Region Located ──► Mouse / Keyboard Action
                      │                                        │
                      ▼                                        ▼
               Confidence Score                        Visual Verification

SikuliX captures the screen, runs template matching via OpenCV to find target regions, and performs pixel-accurate interactions. The entire pipeline runs locally — no cloud, no external API, no data leaves your machine.

<br>

---
