Ziggurats.jl

This package contains routines for automatically constructing high-performance non-uniform random number generators for a wide variety of user defined univariate probability distributions using a variation on the Marsaglia & Tsang Ziggurat Algorithm[^1].

It's designed as a black-box algorithm, in most cases all the programmer needs to provide is a probability density function (pdf) and a list of extremal points of the pdf that divide the domain into subdomains where the pdf is monotonic.

The Ziggurat Algorithm is designed for very high marginal sampling performance at the expense of a longer setup time. It's appropriate for situations where you need a large number of samples from a fixed distribution with a known pdf.

Installation

Ziggurats.jl is a registered Julia package that can be installed using the Julia package manager. E.g., in the REPL type

julia> using Pkg; Pkg.add("Ziggurats")

Basic Usage

The ziggurat function provides the primary interface. In most cases you can pass in the pdf and a list of extremal points. That is, the boundaries of the domain and each local minimum and maximum.

julia> using Ziggurats, Plots
julia> z = ziggurat(x -> exp(-x^2/2), (-Inf, 0, Inf));
julia> histogram(rand(z, 10^5); normalize=:pdf);
julia> plot!(x->1/√(2π) * exp(-x^2/2); linewidth=2, color=:black)

julia> z = ziggurat(x -> abs(cos(x)), (-π, -π/2, 0, π/2, π));
julia> histogram(rand(z, 10^6); normalize=:pdf)
julia> plot!(x -> 1/4 * abs(cos(x)); linewidth=2, color=:black)

Discontinuous functions are okay. Points of discontinuity do not need to be specified unless it's also an extremal point.

julia> z = ziggurat(x -> x>=1 ? 2-x : 10-x, (0,2));
julia> histogram(rand(z, 10^5), normalize=:pdf);
julia> plot!(x -> (x>=1 ? 2-x : 10-x)/10; linewidth=2, color=:black)

For symmetric and unimodal pdfs (bell-shaped), a more optimized sampler can be generated using the BellZiggurat constructor. Pass in the pdf function and a pair of points that are the mode and one boundary of the domain. Either boundary is okay.

julia> z = BellZiggurat(x -> exp(-x^2/2), (0, Inf));
# Or
julia> z = BellZiggurat(x -> exp(-x^2/2), (-Inf, 0));

The available constructors for ziggurats are: ziggurat, BellZiggurat, monotonic_ziggurat, BoundedZiggurat, UnboundedZiggurat, and CompositeZiggurat. Each of them has a detailed docstring where you can find information about usage and limitations.

How it Works

For monotonic and bell-shaped distributions, the algorithm is an easy to use, robust, high performance, implementation of the Marsaglia & Tsang 2000[^1] Ziggurat Algorithm. Unlike most implementations, Ziggurats.jl is not confined to a small number of distributions. It's is a 'black-box' algorithm that automates the ziggurat construction producing fast samplers for a wide variety of user-specified distributions. Usually only a pdf function and a list of extremal points of the pdf is required. Other libraries with similar functionality require the programmer to provide an inverse pdf function, a cumulative distribution function, etc.. Ziggurats.jl by default generates those auxiliary functions using robust numerical methods. This makes the ziggurat method much more ergonomic to use.

By default, the ipdf is computed using a root finding algorithm (via Roots.jl), and the tailarea function is computed using Gauss-Kronrod quadrature (via QuadGK.jl). The fallback algorithm for samples in the tail of unbounded distributions is inverse transform sampling over the renormalized tailarea function, where the inverse is computed similarly to the ipdf.

Ziggurats.jl also extends the ziggurat algorithm to distributions with piecewise monotonic pdfs. The extension is relatively simple, ziggurats are generated for each monotonic subdomain (which are separated by extremal points), and their areas are computed by quadrature. To take a sample, first select a subdomain with the appropriate probability (proportional to area, via AliasTables.jl) and then sample within that subdomain using the corresponding ziggurat.

Performance Tips

Generally, you can expect high performance, but there are a few things you should be aware of to get the best possible performance.

First of all, if your pdf is known to be symmetric and unimodal (bell-shaped) use BellZiggurat instead of ziggurat. The specialized algorithm can be several times faster than the generic algorithm.

Second, bulk generation is faster than generating samples one at a time, so if you're filling an array with random numbers use rand(z, dims), or rand!(a, z) instead of [rand(z) for _ in 1:10^6], or

for i in eachindex(a)
    a[i] = rand(z)
end

Third, using more layers in the ziggurat may be faster because it reduces the rejection rate. Any number of layers is possible, but the fastest sampling algorithms are available when the number of layers is a power of two. I recommend benchmarking your application with different powers of two numbers of layers up to a maximum of 2^12 = 4096 for Float64 domains, 2^9 = 512 for Float32 domains and 2^6 = 64 for Float16 domains. For technical reasons, the quality of the statistical distribution can degrade if you use a power of two larger than those limits. The default number of layers is 2^8 = 256 or 2^6=64 for Float16. That's generally a good trade off between speed and memory size.

Finally, on unbounded domains, the default fallback algorithm is usually by far the slowest part. Conventional wisdom with the ziggurat algorithm is that the performance of the fallback algorithm is not particularly important because it is called very rarely. However, in this case, the fallback can be exceptionally slow. It often does have a meaningful impact on the average time to generate a sample. Fortunately, there are several ways to mitigate the problem:

Use more layers. The more layers there are, the more rarely the fallback is required, the smaller its impact on overall performance. This is probably a good choice in most situations unless your application is memory constrained (including cache memory) or sensitive to the maximum possible latency. I recommend benchmarking your application with different powers of two numbers of layers up to the limits mentioned above.
Use a bounded domain. Ziggurats on bounded domains don't use a fallback at all, so you can just pick an outer limit that's beyond the majority of the probability mass. This could cut off a portion of the tail, but you can probably always find a cutoff point that is far enough down the tail that it makes no material difference. For example, with the exponential distribution, exp(-1000) == 0 in floating point, so chances are using a domain of (0,1000) would incur no loss of precision.
Provide a function for the tail area. The default fallback is so slow because it's a numerical inverse of a numerical integral. Replacing the tail area function with a direct implementation by passing a tailarea keyword argument will greatly improve the performance of the fallback as well.
Override the fallback directly. If you happen to know a modestly performant way to sample points in the tail, you can use it by passing a fallback keyword argument. See the constructor docstrings for details on usage.

Contributing

Star this repo! This is a hobby project. If you star the repo it lets me know that people are interested and that I should keep working on it.
Start a discussion. If you need help, or have a question, click on the discussion tab on the GitHub repo and make a post. I'll do my best to help out.
Raise an issue. Any input helps. If you think something could be better, let me know! If you have a feature request, let me know! If you find a bug then please post it in the issue tracker!
Send a pull request. If you can contribute code or documentation (even small edits) then please do so. I want this project to be as good as it can be, so I'm happy to take outside contributions.

[^1]: Marsaglia, G., & Tsang, W. W. (2000). The Ziggurat Method for Generating Random Variables. Journal of Statistical Software, 5(8), 1–7. https://doi.org/10.18637/jss.v005.i08
