Negminer: A hard negative mining tool

A tool to simplify hard negative mining process for training embeddings models:

• Embeds documents and queries, builds ANN index, retrieves top-N candidates and scores them with a cross-encoder model.
• Supports multi-GPU inference: complete MSMARCO with 8M documents embedded in 10 minutes on 2x RTX4090
• Uses FAISS HNSW index for ANN candidate retrieval
• Can run any sentence-transformers compatible embedding and cross-encoder model.

What are hard negatives?

Hard negatives are search results which are close semantically to your query, but not being relevant.

Embedding models are being trained with a contrastive approach when you need to show the difference between relevant and irrelevant document to the model. A simple way of getting negatives is to use random sampling: any random document is a negative! But this approach makes the life of the underlying ML model too simple, as it's too easy to distinguish ketchup from tractor for a tomato query.

Harder negatives make the model training much harder: it need to pick minor differences between semantics of documents to figure out what is relevant and what's not - like on a picture with Chihuahuas and muffins above. Negminer automates the job of building such hard negatives.

Install

Negminer is not yet on PyPi, so install it from GIT:

git clone https://github.com/nixiesearch/negminer
cd negminer

python -m venv .venv
source .venv/bin/activate

pip install -e .

Usage

The mining process has multiple steps:

• Create a config file.
• Preprocess and tokenize the dataset for embedding.
• Embed documents and queries
• Perform ANN search to retrieve candidates
• Preprocess the mined query-document pairs dataset for CE scoring
• Score candidates with a Cross-Encoder model
• Export negatives

Config file

A YAML file with the following syntax:

corpus: data/mteb/msmarco/corpus.jsonl
queries: data/mteb/msmarco/queries.jsonl
qrels: data/mteb/msmarco/qrels/train.tsv
embedding: intfloat/e5-base-v2 # sentence-transformers compatible model
doc_prompt: "passage: " # E5 model requires custom prompt
query_prompt: "query: "
embedding_seq_len: 512 # trim everything longer
embedding_batch_size: 1024 # depends on your GPU, start with lower number like 32
ce: BAAI/bge-reranker-v2-m3 # CE model
ce_seq_len: 512 # different max sequence length for a CE model as it might be bigger
out_dir: out/msmarco # work dir

Preprocessing data

During preprocessing, Negminer reformats the data in an Apache Arrow tables with the HF datasets, so on later stages data can be directly streamed into the GPU. To run preprocessing, run the negminer.preprocess job:

python -m negminer.embed.prepare <path-to-config.yml>

In your out_dir directory you will see a corpus, queries and qrels datasets.

Embedding documents

For large embedding models, the embedding process can take some time and you may want to run it only once and cache the results - that's why it is a separate step. For single-GPU setups, you can run it directly with Python:

python -m negminer.embed <path-to-config.yml>

For multi-GPU setup, run the embedder with the Accelerate:

accelerate launch -m negminer.embed <path-to-config.yml>

After the emedding process is done, a corpus_embed and queries_embed datasets will appear in the out_dir directory.

Retrieving candidates

After documents and queries are embedded, you can build the ANN index with the FAISS library:

python -m negminer.search <path-to-config.yml>

After the process is done, the qrels_mined dataset will appear in the out_dir.

Tokenize mined query-document pairs

As embedding and cross-encoder model might use different tokenizers, we need to reprocess the dataset again, tokenizing all the mined query-document pairs:

python -m negminer.score.prepare <path-to-config.yml>

On this step for all query-document pairs, we will tokenize each, and save them into a out_dir/ce_tokenized dir.

Scoring with cross-encoders

On the last step you need to run the CE scoring process:

accelerate launch -m negminer.score <path-to-config.yml>

It might take some time: MSMARCO train split with 16 negatives each takes ~1h on 2x 4090 to be scored. At the end of the process, you'll get a out_dir/qrels_scored dataset.

Exporting negatives

TODO

Data format

Negminer supports TREC input format in the BEIR flavor:

• a set of corpus.json, queries.json and qrels.tsv files.
• corpus.json file contains your document corpus with _id, text and optional title fields.
• queries.json file contains all your query text with _id and text fields.
• qrels.tsv TSV file has triplets of query-id, corpus-id and score columns, where score is an integer relevance label.

Check out this HotpotQA repo as an example of a well-formatted dataset.

Output format

Negminer outputs a JSONL format with the following fields:

{
    "query": "query-id",
    "docs": ["doc1", "doc2", "doc3"],
    "doc_scores": [1.0, 0.0, 0.0],
    "query_doc_cos": [0.95, 0.50, 0.10],
    "query_doc_ce": [0.84, 0.75, 0.20],
    "doc_doc_cos": [1.0, 0.1, 0.3, 0.2, 1.0, 0.3, 0.3, 0.2, 1.0]
}

Fields are:

• query: a query identifier from the queries.json TREC source dataset
• docs: a list of document ids from the corpus.json TREC source dataset. This list includes both positives from qrel, and mined negatives. You can distinguish between them by the doc_scores field, where positives will have non-zero score.
• doc_scores: a set of explicit scores taken from the qrel.tsv. All mined negatives will have score of 0.0. All documents referenced in the qrels are going to be included, both positives and negatives.
• query_doc_cos: cosine similarity between query and all documents in the docs field.
• query_doc_ce: Cross-encoder similarity score between query and all documents in the docs field.
• doc_doc_cos: a document-document cosine similarity. A square matrix of size len(docs) * len(docs) with all documents are compared to themselves. Useful for duplicate and semi-duplicate detection.

License

Apache License 2.0
