Unofficial EGG Mouse Config

This is an unofficial configuration tool for EGG XM2 and OP1 8k gaming mice.

Features

Configure CPI (50-26000 in 50 CPI steps)
Toggle angle snapping and ripple control
Adjust lift-off distance (1-2mm)
Set polling rate (1000Hz, 2000Hz, 4000Hz, 8000Hz or custom)
Enable/disable motion sync (when available)
Configure button debounce settings
Set SPDT modes (for left/right buttons)
Enable/disable slamclick and motion jitter filters
Backup/restore mouse configuration
Factory reset capability

Supported Mice

Currently supported models:

EGG XM2 8k (PID: 0x1966)
EGG OP1 8k Purple Frost (PID: 0x1976)
EGG OP1 8k v2 (PID: 0x1978)

Compilation

Prerequisites

CMake (≥3.16)
C++20 compatible compiler
HIDAPI library (libhidapi-hidraw on Linux)
OpenGL
Git (for version detection)

For Linux desktop builds:

GLFW
Freetype (for font rendering)

For Emscripten builds:

Emscripten SDK
SDL2

Build Instructions

Preparation

git clone https://github.com/niansa/UnofficialEGGMouseConfig.git
cd UnofficialEGGMouseConfig
git submodule update --init --depth 1 --recursive
mkdir build
cd build

Linux Build

cmake -DCMAKE_BUILD_TYPE=Release ..
make -j$(nproc)
sudo cp EGGMouseConfig /usr/local/bin/

Linux Static Build (Portable but bigger)

cmake -DCMAKE_BUILD_TYPE=MinSizeRel -DBUILD_STATIC=ON ..
make StripAndCompress

Web Build (Emscripten)

emsdk activate latest
emcmake cmake -DCMAKE_BUILD_TYPE=Release ..
emmake make -j$(nproc)
python3 -m http.server 8000

Access via http://localhost:8000 in Chrome/Edge

Usage

Linux Desktop Version

Run the application:

EGGMouseConfig

If you encounter permission issues, run as root (avoid):

sudo EGGMouseConfig

The application will automatically detect connected compatible mice.

Web/EMSCRIPTEN Version

Build the application as described above
Serve the generated HTML/JS files through a web server
Open in a modern browser

Note: The web version requires browser support for WebHID.

Udev rule

You can add the following udev rules to grant members of plugdev group and users physically present on the PC full access to the mouse configuration:

/etc/udev/rules.d/30-egg.rules

SUBSYSTEM=="usb", ATTRS{idVendor}=="3367", GROUP="plugdev", MODE="0660", TAG+="uaccess"
SUBSYSTEM=="hidraw", ATTRS{idVendor}=="3367", GROUP="plugdev", MODE="0660", TAG+="uaccess"

Then apply new rules:

sudo udevadm control --reload-rules && sudo udevadm trigger

Troubleshooting

If the mouse isn't detected:
- Ensure you have proper permissions (add udev rule or try running as root or add user to input group)
- Check that the mouse is connected via USB
- Verify your mouse model is supported
For build issues:
- Ensure all dependencies are installed
- Check your compiler supports C++20
- Verify CMake version is ≥3.16

Safety Notice

Experimental features can potentially brick your mouse! In this case, factory reset using the official application might be required.

Credits

Main developer: niansa (@tuxifan)
Contributor: elin_lyze
HIDAPI library for cross-platform HID access: libusb team
Dear ImGui for the UI framework: ocornut
